ModelSight 📊

Local-First Machine Learning Training Monitor & Interactive Error Explainer for VS Code

ModelSight is a lightweight, local-first Visual Studio Code extension that turns your editor into a real-time interactive machine learning dashboard. Track loss, accuracy, and system hardware metrics (RAM & GPU) directly inside VS Code, and let ModelSight instantly decode runtime training crashes into plain-English troubleshooting checklists.

[!IMPORTANT] 100% Local & Private: ModelSight has zero external Node or Python dependencies. Telemetry is streamed entirely offline via standard output parsing or local loopback connection (127.0.0.1:9824). Your training data, logs, and model configurations never leave your machine.

✨ Features

📈 Real-Time Telemetry Dashboard

Keep track of critical metrics as your training runs progress. The metrics row displays:

• Loss Tracker: Real-time training loss with change indicators showing variance relative to the initial value.
• Accuracy Meter: Visual progress bar tracking accuracy growth.
• Learning Rate (LR): Support for scientific exponential notations for learning rate scheduling.
• GPU Core Utilization: Auto-queries NVIDIA GPU usage using standard diagnostic tools.
• System RAM Monitor: Tracks cross-platform memory footprints (using native OS bindings) to help prevent out-of-memory crashes.
• Overfitting Risk: Real-time detector highlighting validation anomalies.

📉 Live Vector Charts & Dual-Curves

• Plots training metrics (solid curves) and validation metrics (dashed curves) on the same graph.
• Implements requestAnimationFrame update batching to eliminate browser reflow lag for silky-smooth rendering.
• Downsamples data points using a 100-point filter to keep your VS Code window highly responsive even over millions of training steps.

🚨 Smart Overfitting Detection

• Automatically detects validation anomalies in real time.
• If validation loss increases consecutively 3 times while training loss is decreasing, the dashboard updates the Overfitting Risk card to High ⚠️ (complete with a glowing amber/red pulse indicator) and provides context-specific suggestions like adding dropout, early stopping, or weight decay.

🔍 Interactive Error Explainer

• If your training script crashes, ModelSight captures standard Python tracebacks.
• Translates complex ML runtime issues (such as PyTorch shape mismatches, CUDA out-of-memory errors, index bounds, and file path errors) into human-friendly explanations and checklists.

🗃️ Run History Overlays & Export

• Stores the metadata and summary of your last 10 training runs in your workspace state.
• Select checkboxes in the Run History drawer to overlay past run curves as dimmed, dotted lines for direct comparison.
• Export training summaries, charts, and console logs into a single, self-contained HTML report.

🚀 Quick Start

Step 1: Install the Extension

Install ModelSight from the VS Code Extensions Marketplace (Ctrl+Shift+X) or install the packaged .vsix file manually.

Step 2: Use the Python Helper (Zero Configuration)

You do not need to do any manual copying or installation! The extension automatically copies the modelsight.py helper to your active workspace root folders and script directories.

Simply import and use the helper directly in your Python code:

1. Standard PyTorch/Custom Training Loop

import modelsight
import time

# Initialize parameters
total_epochs = 10
total_steps = 100

for epoch in range(1, total_epochs + 1):
    for step in range(1, total_steps + 1):
        # ... Your Model Training Code Here ...
        time.sleep(0.01) # Simulate training step

        # Log telemetry metrics to the dashboard
        modelsight.log(
            epoch=epoch,
            total_epochs=total_epochs,
            step=step,
            total_steps=total_steps,
            loss=0.8 - (epoch * 0.05),
            accuracy=0.2 + (epoch * 0.07),
            lr=0.001
        )

2. Keras / TensorFlow Integration

ModelSight includes a built-in Keras callback:

from modelsight import ModelSightKerasCallback

# Pass the callback to model.fit()
callback = ModelSightKerasCallback(total_epochs=10)
model.fit(
    x_train, y_train,
    epochs=10,
    callbacks=[callback],
    validation_data=(x_val, y_val)
)

3. PyTorch Lightning Integration

Stream metrics automatically using the PyTorch Lightning callback:

import pytorch_lightning as pl
from modelsight import ModelSightLightningCallback

# Instantiate callback and pass to Trainer
trainer = pl.Trainer(
    max_epochs=10,
    callbacks=[ModelSightLightningCallback()]
)

Step 3: Run the Monitored Script

1. Open your training script (e.g. train.py) in VS Code.
2. Click the ModelSight Play Icon at the top right of the editor, or right-click inside the file editor and choose ModelSight: Run Python Script with Monitor.
3. The dashboard opens automatically to show live plots and system stats.

📓 Jupyter Notebook Integration

ModelSight starts a local telemetry HTTP server in VS Code on port 9824. This allows you to stream metrics from Jupyter Notebooks, Google Colab (when running locally), or external processes.

Simply copy modelsight.py into your notebook's folder and call modelsight.log() within any execution cell:

import modelsight

# Telemetry will be posted to the active VS Code dashboard automatically
modelsight.log(
    epoch=2,
    loss=0.34,
    accuracy=0.85,
    val_loss=0.41,
    val_accuracy=0.82
)

📋 API Reference

modelsight.log(...)

Prints structured metrics and posts them to the local Webview receiver. All arguments are optional.

⚙️ Extension Settings

Configure ModelSight settings by opening VS Code Settings (Ctrl+,) and searching for ModelSight:

🛠️ Development & Local Packaging

To build and package the extension locally:

1. Install Node.js dependencies:

   npm install


2. Install vsce (VS Code Extension Manager):

   npm install -g @vscode/vsce


3. Compile the extension package:

   vsce package


   This will generate a .vsix archive file in your directory root (e.g. modelsight-1.0.0.vsix).
4. Install locally: Open VS Code, run Ctrl+Shift+P -> Developer: Install Extension from VSIX..., and select the generated file.

📄 License

This extension is licensed under the MIT License. Developed and maintained by the CODExGAMERZ team.
