Brokk ACP

Brokk ACP is an open-source Agent Client Protocol client for Visual Studio Code. It provides a session-first coding interface for:

• Anvil, bundled as the zero-configuration default;
• agents published in the official ACP Registry; and
• arbitrary custom ACP servers launched over stdio.

The goal is to make agentic coding in VS Code portable across ACP-compatible agents instead of coupling the editor to one provider.

Brokk ACP in action

Choose from the ACP registry

Work in a persistent coding session

Choose bundled Anvil, a custom stdio server, or an agent from the official ACP registry. Sessions keep configuration, structured agent activity, rendered Markdown, and the prompt composer together in the VS Code sidebar.

Current capabilities

Agents

• Platform-specific VSIX packages bundle Anvil and the native Rust ACP host.
• The official registry is refreshed live and cached for offline startup.
• Registry binaries are selected by platform, checksum-verified, and extracted with path-traversal protection.
• Registry agents launched through npx or uvx are supported when the corresponding runner is available on PATH.
• Multiple custom stdio agents can be defined in user or workspace settings.
• ACP terminal and environment-variable authentication are surfaced through VS Code; entered secrets are retained in Secret Storage.

Sessions and chat

• Create, browse, reopen, and delete sessions when the selected agent advertises the corresponding ACP session capabilities.
• Session metadata and structured transcripts are cached per workspace and restored after a VS Code reload.
• New sessions can use the current workspace, create a detached checkout under .brokk/worktrees/, or reuse any registered Git worktree. Nested workspace paths are preserved, and the chosen checkout becomes the ACP process, filesystem, and terminal boundary. The new-session screen in Git workspaces defaults to an isolated checkout; choosing a worktree also opens that exact folder in a new VS Code window so the editor and agent operate on the same files.
• Saved worktree sessions reopen in their recorded checkout. If that checkout disappears, Brokk ACP asks for an explicit replacement instead of silently falling back to the main workspace.
• Reopening a remote session prefers session/load for an authoritative transcript replay and falls back to session/resume when load is unavailable.
• Connection startup, authentication, session loading, cancellation, errors, and agent switching have visible progress in the chat interface.
• Messages, thoughts, tool calls, permissions, usage, and errors remain grouped into coherent turns rather than a raw output stream.
• Standard ACP plans stay visible in a collapsible progress dock with live status, priority, and completion updates.
• Agent-advertised configuration values stay visible in a compact session status line, with the full controls available from a dedicated editor.
• Typing / opens autocomplete for the session's live ACP available_commands_update list, including descriptions and input hints. Use Up/Down to navigate, Enter or Tab to insert, and Escape to close.
• Attach, paste, or drag and drop images when the connected agent advertises the standard ACP image prompt capability. Select or drop several at once, or use the visible add-another control beside the previews. Brokk ACP forwards the attachments without imposing its own format, count, or byte limits. Attachments are previewed before sending and remain identified in the transcript.

ACP client surface

• ACP v1 initialization and prompt streaming.
• Agent-requested permission choices.
• Workspace-scoped text-file reads and writes.
• Client-owned terminal creation, output, waiting, termination, and release.
• Prompt cancellation.
• Interruptible connection startup, so replacing a hung launch does not wedge the host.

The ACP Registry contains agents (servers). Brokk ACP is the client that installs, launches, and presents them.

Install

Brokk ACP is packaged as platform-specific VSIX files. To build and install one from this checkout:

npm ci
npm run package -- --target darwin-arm64
code --install-extension artifacts/brokk-vscode-acp-*-darwin-arm64.vsix

Replace darwin-arm64 with the target for the machine running the VS Code extension host:

• darwin-arm64
• darwin-x64
• linux-arm64
• linux-x64
• win32-x64

Packaging requires Node.js 20 or newer and Rust. The packaging script downloads the pinned Anvil release, verifies its digest, builds the matching Rust host, and includes the required license notices and complete corresponding source.

After publication, install from the VS Code Marketplace with:

code --install-extension brokk.brokk-vscode-acp

Use

1. Open a trusted folder or workspace in VS Code.
2. Open Brokk ACP from the Activity Bar.
3. Choose bundled Anvil, an installed registry agent, or a custom agent.
4. Use the recommended new isolated worktree, choose an existing registered worktree, or explicitly opt into the shared current workspace. Starting a worktree session opens the selected checkout in a new VS Code window and runs the agent against that same path. You can also open Sessions to discover and resume sessions exposed by that agent.
5. Prompt the agent from the composer. Use / to discover commands advertised for the active session. For image-capable agents, use the attachment button, paste an image, or drag image files directly onto the composer. Select several files at once or add them one at a time for a multi-image prompt.
6. Review permission requests and agent activity in the structured transcript. Stop cancels the active prompt.

Registry binary agents are installed into the extension's global-storage directory. Package agents use the package and arguments from their registry entry through npx --yes or uvx.

Custom ACP agents

Add custom stdio servers to user or workspace settings. Each key becomes a stable agent ID:

{
  "brokkAcp.customAgents": {
    "my-agent": {
      "name": "My ACP Agent",
      "command": "/absolute/path/to/my-agent",
      "args": ["--acp"],
      "env": {
        "MY_AGENT_PROFILE": "work"
      }
    }
  }
}

The agent appears as custom:my-agent. name, args, and env are optional; command is required. The older brokkAcp.agent.command and brokkAcp.agent.args settings remain readable for compatibility but are deprecated.

Settings

Current scope

• One ACP agent connection and one active session run at a time in each VS Code window. Starting or opening another session cleanly replaces the current connection.
• The first folder in a multi-root workspace supplies the Git project context. The current folder or explicitly selected worktree is the ACP working directory and file-access boundary.
• Session listing, deletion, loading, and resuming depend on capabilities advertised by the selected agent.
• Resource attachments, elicitation forms, and session forking are not yet exposed in the UI.
• Untrusted workspaces are not supported because coding agents can request file edits and terminal commands.

Security boundary

ACP agents are coding agents and may request file edits or commands. Brokk ACP:

• asks using the exact permission choices supplied by the agent;
• advertises file access only within the active workspace folder or selected worktree;
• resolves existing paths and write ancestors before allowing access;
• runs client-owned terminal commands inside that workspace folder;
• caps retained terminal output;
• validates that image payloads carry an image MIME type and valid base64 before forwarding them without additional client policy;
• stores environment-authentication secrets in VS Code Secret Storage; and
• verifies registry checksums before installing binary distributions.

Only use custom registry URLs and custom agent commands that you trust.

Architecture

VS Code extension
  ├─ webview, workspace session cache, settings, and Secret Storage
  └─ newline-delimited JSON commands/events
       └─ brokk-acp-host (Rust sidecar)
            ├─ ACP connection and session lifecycle
            ├─ registry and verified installer
            ├─ permissions, workspace files, and terminals
            └─ ACP v1 JSON-RPC over stdio
                 └─ Anvil, registry agent, or custom ACP server

Rust owns the ACP state machine, agent processes, registry, installation, permissions, filesystem boundary, and terminal lifecycle. TypeScript owns the VS Code APIs, webview, workspace-local session cache, Secret Storage prompts, authentication terminal, and sidecar process relay. Keeping the ACP connection in a native sidecar isolates agent or protocol failures from the extension host.

Development

Requirements are Rust, Node.js 20 or newer, and a local Anvil checkout next to this repository for the default development agent.

npm install
npm run check
npm run compile

Open this directory in VS Code and run the Run Extension launch configuration. Development mode looks for Anvil at ../anvil/target/{debug,release}/anvil; brokkAcp.anvil.path overrides it.

Validation commands:

npm test
npm run coverage
npm run license:check
npm run package -- --target <platform>

npm test enforces at least 80% coverage on every TypeScript module and every Rust production module. TypeScript uses per-file statement, branch, function, and line thresholds; Rust uses production line coverage and excludes inline test bodies from the calculation. Install cargo-llvm-cov 0.8.7 to run the Rust gate locally. HTML TypeScript results are written to coverage/typescript/index.html.

cargo-about version 0.9.1 is required for npm run license:check.

Merging a synchronized version bump to master starts the release workflow. It validates the complete suite, builds all five supported platform VSIX files, creates the annotated v<version> tag, publishes the platform packages to the Visual Studio Marketplace, and creates a GitHub release with every VSIX attached. A matching tag can also start a release, and a manual workflow run builds the packages without publishing them.

Repository administrators must configure VSCE_PAT for the Visual Studio Marketplace as a GitHub Actions secret.

Corresponding source

Every VSIX carries the exact TypeScript and Rust source, locked dependency manifests, and build scripts used for that package under extension/source/. This keeps the GPL source available to every recipient independently of repository visibility. See SOURCE.md.

License

Brokk ACP is licensed under the GNU General Public License, version 3 only. See LICENSE. Bundled and installed agents retain their own licenses; see THIRD_PARTY_NOTICES.md. The tracked native-host dependency inventory and license texts are available directly at legal/host/THIRD_PARTY_LICENSES.html.
