SpekAi - OpenAPI Testing Extension for VS Code

A VS Code extension that provides a React-based UI for validating OpenAPI specifications.

Screenshots

Main Interface with OpenAPI Testing

Response Handling and Test Data Management

Fallback Mode and Manual Testing

Features

Core OpenAPI Testing

• URL Input: Enter any OpenAPI specification URL for validating
• Local File Support: Browse and load OpenAPI specifications from local files with file:// support
• Multi-format Support: Supports both JSON and YAML OpenAPI specification formats
• Dynamic UI Generation: Automatically generates UI components for each API operation from the spec
• Smart Parameter Handling:
  • Path parameters with automatic URL substitution
  • Query parameters with proper encoding
  • Header parameters with custom header support
• Request Body Editor: Full-featured JSON editor for request payloads
• Test Execution: Execute API calls directly from the UI with real-time results
• Response Display: View API responses with status codes, headers, and formatted JSON
• Raw Response Support: Automatically displays raw text responses when APIs return non-JSON content (HTML, plain text, XML, etc.)

Advanced Testing Features

• Claude LLM Integration: Cloud-based AI generation using Anthropic's Claude for high-quality test data
• Intelligent Fallback: Seamless fallback between providers when one is unavailable or fails
• Multi-Language Support: Generate test data appropriate for 20+ locales when using Claude (English, Spanish, French, German, Japanese, etc.)
• Global Headers Support: Configure HTTP headers that apply to all operations and OpenAPI spec loading
• Custom Headers Management: Add, edit, and remove custom HTTP headers per operation
• Schema-Based Examples: Automatically generate example values from OpenAPI schemas with intelligent JSON generation using OpenAPI spec examples
• Parameter Validation: Real-time validation against OpenAPI parameter constraints

Fallback Testing Mode

• Manual API Testing: When OpenAPI spec loading fails, automatically switches to manual testing mode
• HTTP Method Buttons: Direct testing with GET, POST, PUT, DELETE operations
• Flexible JSON Input: Manual JSON request body editing for any API endpoint

Security & Authentication

• Client Certificate Authentication: Full mTLS (mutual TLS) support with:
  • Client certificate file configuration (.crt, .pem)
  • Private key file support (.key, .pem)
  • Optional passphrase protection
  • CA certificate chain support
  • Global certificate settings for all operations

Data Management

• Smart File Naming: Automatically includes server name from URL in saved test data filenames for easy organization
• Save/Load Test Data: Persistent storage of test configurations including:
  • Input JSON and parameters
  • Custom headers and global headers
  • Client certificate settings
  • API base URL configuration
  • Operation metadata
• Cross-Session Persistence: Reload test data across VS Code sessions
• Flexible Data Loading: Load test data for any compatible operation
• Fallback Mode Persistence: Save/load functionality works in both normal and fallback modes

Developer Experience

• VS Code Integration: Seamless integration with VS Code's webview system
• Real-Time Updates: Live editing of JSON with syntax validation
• Always-Visible UI: Global headers and client certificate sections are always visible for immediate access
• Improved Button Layout: Centered, well-spaced action buttons for better usability
• Error Handling: Comprehensive error messages and recovery suggestions
• URL Management: Editable API base URL with automatic extraction from OpenAPI specs
• Operation Organization: Clean list view of all available API operations with filtering

Technical Capabilities

• OpenAPI 3.0 Support: Full compatibility with modern OpenAPI specifications
• Multiple File Formats: Native support for JSON and YAML OpenAPI specification files
• Local File Access: Direct file system access with cross-platform file path handling
• Reference Resolution: Automatic resolution of $ref references in schemas
• Schema Validation: Request validation against OpenAPI schemas
• Multiple Content Types: Support for various request/response content types
• Concurrent Operations: Handle multiple API calls simultaneously
• Cross-platform Compatibility: Works on Windows, macOS, and Linux with native file dialogs

Recent Improvements

Enhanced User Interface

• Immediate UI Access: Global headers and client certificate sections are now visible immediately when the extension loads, before any OpenAPI specification is loaded
• Always-Visible Response Window: Response section is always visible with appropriate placeholder text, ensuring consistent UI layout
• Improved Button Layout: Action buttons (Test Operation, Save Test Data, Load Test Data) are now centered with consistent spacing for better usability

Enhanced Response Handling

• Raw Text Support: When APIs return non-JSON responses (HTML, plain text, XML, etc.), the extension now displays them as raw text instead of attempting to wrap them in JSON structure
• Smart Response Detection: Automatically detects and formats valid JSON responses while preserving raw text for non-JSON content

Better Test Data Management

• Smart File Naming: Saved test data files now automatically include the server hostname from the API URL in the filename for easy organization (e.g., spekai-test-api-example-com-GET-users-20241203_143052.json)
• Global Headers Integration: Global headers are properly included in saved test data and applied to all operations including OpenAPI spec loading

Improved JSON Generation

• OpenAPI Spec Examples: Manual JSON generation now prioritizes examples from the OpenAPI specification itself, providing more accurate and relevant test data that conforms to the actual API schema
• Schema Conformance: Generated JSON now better conforms to the selected operation's parameter and request body schemas

Bug Fixes

• Fixed Test Button Functionality: Resolved issue where test operation buttons were not responding due to missing function references
• Fixed UI Structure: Corrected JSX syntax errors and structural issues that were preventing the UI from loading properly
• Enhanced Error Handling: Improved error messages and graceful fallback handling for various edge cases

Usage

Basic OpenAPI Testing

1. Open the command palette (Ctrl+Shift+P / Cmd+Shift+P)
2. Run the command "Open SpekAi Tester"
3. Load OpenAPI Specification:
   • Remote: Enter an OpenAPI specification URL (e.g., https://petstore3.swagger.io/api/v3/openapi.json)
   • Local File: Click "Browse" to select a local OpenAPI file (.json, .yaml, .yml)
4. Click "Load" to fetch and parse the specification
5. Select an operation from the left panel
6. Edit parameters and request body in the JSON editor
7. Click "Test Operation" to execute and view responses

Advanced Features

• Click "Generate with AI" to create realistic test data for any locale
• Global Headers: Configure HTTP headers that apply to all operations and OpenAPI spec loading (visible immediately on load)
• Custom Headers: Use the headers editor to add authentication tokens or custom headers per operation
• Client Certificates: Enable mTLS authentication by configuring client certificate paths using Browse buttons (visible immediately on load)
• File Browsing: Use Browse buttons throughout the interface to select files with native OS dialogs
• Save/Load: Save test configurations with smart filenames (including server name) and reload them later for consistent testing
• Manual Testing: If OpenAPI spec fails to load, use the fallback mode with HTTP method buttons

Fallback Mode (Manual Testing)

When OpenAPI specification loading fails, the extension automatically switches to manual testing mode:

1. Enter JSON request data in the editor
2. Configure custom headers if needed
3. Click GET, POST, PUT, or DELETE buttons to test endpoints directly
4. View responses and save/load test configurations

Configuration

Accessing Settings

1. Open VS Code Settings (Ctrl+, / Cmd+,)
2. Search for "SpekAi"
3. Configure the AI provider preferences under the SpekAi section

Development

Prerequisites

• Node.js (v16 or higher)
• npm

Setup

# Install dependencies
npm install
cd ui && npm install && cd ..

# Build the extension
npm run compile
cd ui && npm run build && cd ..

Running

1. Open this folder in VS Code
2. Make sure all dependencies are installed: Run npm install and cd ui && npm install
3. Build the project: Run npm run compile and cd ui && npm run build
4. Press F5 to run the extension in a new Extension Development Host window
5. In the new window, open Command Palette (Ctrl+Shift+P) and run "Open SpekAi Tester"

Troubleshooting

If you get "Cannot find module 'vscode'" error:

• This error is normal when testing the extension outside VSCode
• The vscode module is only available inside VSCode's extension host environment
• Make sure to run the extension using F5 from within VSCode, not from command line
• Ensure you have built both the extension (npm run compile) and UI (cd ui && npm run build)

Project Structure

├── src/                 # Extension TypeScript source
│   ├── extension.ts     # Main extension entry point
│   └── SpekAiPanel.ts   # Webview panel management
├── ui/                  # React UI source
│   ├── src/
│   │   ├── App.tsx      # Main React component
│   │   ├── index.tsx    # React entry point
│   │   └── index.css    # Styles
│   ├── dist/            # Built UI files
│   └── package.json     # UI dependencies
├── out/                 # Compiled extension
└── package.json         # Extension manifest

Building for Distribution

npm run vscode:prepublish

This will compile the extension and build the UI for production.
