CarbonMate - VS Code Extension
A VS Code extension that provides Carbon Design System token suggestions for SCSS files. Automatically detects SCSS files and suggests Carbon spacing tokens when writing CSS properties like margin and padding.

Features
- SCSS File Detection: Automatically activates when editing SCSS files
- Carbon Spacing Tokens: Provides suggestions for all Carbon Design System spacing tokens
- Smart Suggestions: Only shows spacing token suggestions when writing margin or padding properties
- Rich Documentation: Each token includes rem and px values with descriptions
- Hardcoded Value Detection: Detects hardcoded spacing values and suggests Carbon token replacements
- Import Awareness: Ensures proper
@use '@carbon/layout';
import is present
- Performance Optimized: Only processes active SCSS files for better performance
Carbon Spacing Tokens
The extension provides suggestions for all 13 Carbon spacing tokens:
Token |
rem |
px |
Description |
layout.$spacing-01 |
0.125rem |
2px |
Smallest spacing increment |
layout.$spacing-02 |
0.25rem |
4px |
Small spacing increment |
layout.$spacing-03 |
0.5rem |
8px |
Extra small spacing |
layout.$spacing-04 |
0.75rem |
12px |
Small spacing |
layout.$spacing-05 |
1rem |
16px |
Medium spacing |
layout.$spacing-06 |
1.5rem |
24px |
Large spacing |
layout.$spacing-07 |
2rem |
32px |
Extra large spacing |
layout.$spacing-08 |
2.5rem |
40px |
2XL spacing |
layout.$spacing-09 |
3rem |
48px |
3XL spacing |
layout.$spacing-10 |
4rem |
64px |
4XL spacing |
layout.$spacing-11 |
5rem |
80px |
5XL spacing |
layout.$spacing-12 |
6rem |
96px |
6XL spacing |
layout.$spacing-13 |
10rem |
160px |
7XL spacing |
Installation
From VSIX (Local Installation)
- Download the latest
.vsix
file from the Releases page
- In VS Code, go to Extensions (
Ctrl+Shift+X
)
- Click the "..." menu and select "Install from VSIX..."
- Choose the downloaded
.vsix
file
From Source
- Clone this repository
- Run
npm install
- Run
npm run compile
- Press
F5
to run the extension in a new VS Code window
Usage
1. Token Suggestions
- Open a SCSS file in VS Code
- Add
@use '@carbon/layout';
at the top of the file
- Start typing a spacing property (margin, padding, etc.)
- Type
$
to trigger the suggestions
- Select a Carbon spacing token from the dropdown
2. Magic Number Replacement
- Open a SCSS file with
@use '@carbon/layout';
import
- Notice CarbonMate underlines hardcoded spacing values (e.g.,
16px
, 1rem
, 2em
)
- Use
Ctrl+.
(Windows/Linux) or Cmd+.
(Mac) to quick fix one of the selected value - the extension will suggest the closest Carbon token
- Alternatively:
- Press
Ctrl+Shift+P
(Windows/Linux) or Cmd+Shift+P
(Mac)
- Type
CarbonMate
- Select
Fix all hardcoded spacing values
- The extension will automatically replace all hardcoded values with their closest matching Carbon tokens in the file
Example
@use '@carbon/layout';
.my-component {
// Manual token usage
margin: layout.$spacing-05; // ✅ Correct Carbon syntax
padding: layout.$spacing-03; // ✅ Correct Carbon syntax
// Hardcoded values that can be replaced
margin: 16px; // 🔄 Can be replaced with layout.$spacing-05
padding: 24px; // 🔄 Can be replaced with layout.$spacing-06
}
Hardcoded Value Detection
The extension can detect and suggest replacements for:
- Pixel values:
16px
, 24px
, 32px
, etc.
- Rem values:
1rem
, 1.5rem
, 2rem
, etc.
- Em values:
1em
, 1.5em
, 2em
, etc.
Replacement Logic
- Exact matches: Direct replacement with corresponding Carbon token
- Close matches: Suggests the closest Carbon token (within 8px difference)
- Far matches: No suggestion (values too far from Carbon tokens)
Examples
Original Value |
Suggested Carbon Token |
Difference |
16px |
layout.$spacing-05 |
0px (exact) |
18px |
layout.$spacing-05 |
2px |
24px |
layout.$spacing-06 |
0px (exact) |
1rem |
layout.$spacing-05 |
0px (exact) |
2em |
layout.$spacing-07 |
0px (exact) |
Commands
CarbonMate: Fix All Hardcoded Spacing Values
- Replace all hardcoded spacing values in the current file
CarbonMate: Refresh Code Check
- Manually refresh the code analysis
Development
Prerequisites
- Node.js (v16 or higher)
- VS Code
Setup
Clone the repository
git clone https://github.com/your-username/vscode-CarbonMate.git
cd vscode-CarbonMate
Install dependencies
npm install
Compile the extension
npm run compile
Press F5
to run the extension in a new VS Code window
Build Commands
npm run compile # Compile TypeScript
npm run watch # Watch for changes and recompile
npm run lint # Run ESLint
Creating a VSIX Package
npm install -g vsce
vsce package
This will create a .vsix
file that can be installed in VS Code.
Configuration
The extension can be configured through VS Code settings:
carbonmate.enable
: Enable/disable the extension (default: true)
Dependencies
@carbon/layout
: Carbon Design System layout tokens
@types/vscode
: VS Code extension API types
typescript
: TypeScript compiler
Contributing
- Fork the repository
- Create a feature branch (
git checkout -b feature/amazing-feature
)
- Commit your changes (
git commit -m 'Add some amazing feature'
)
- Push to the branch (
git push origin feature/amazing-feature
)
- Open a Pull Request
Issues
If you find any issues or have suggestions, please open an issue on GitHub.
License
This project is licensed under the ISC License - see the LICENSE file for details.
Acknowledgments
