CAPDAG Machine Notation

VS Code extension for .machine files — the bracket-delimited DAG wiring notation used by the CAPDAG system.

Features

• Syntax highlighting — brackets, cap URNs, media URNs, arrows, LOOP keyword, aliases
• Diagnostics — parse errors, undefined aliases, duplicate aliases, invalid URNs with precise positions
• Hover info — cap URN details, media spec types, registry-enriched metadata
• Autocomplete — registry-backed suggestions for cap URNs, media URNs, ops, node names, and aliases
• Live graph — Mermaid flowchart that renders beside the editor and updates as you type

.machine File Format

[extract_metadata cap:in=media:pdf;op=extract_metadata;out="media:file-metadata;textable;record"]
[extract_outline cap:in=media:pdf;op=extract_outline;out="media:document-outline;textable;record"]
[generate_thumbnail cap:in=media:pdf;op=generate_thumbnail;out="media:image;png;thumbnail"]

[pdf_input -> extract_metadata -> metadata]
[pdf_input -> extract_outline -> outline]
[pdf_input -> generate_thumbnail -> thumbnail]

Each statement is enclosed in brackets. Headers bind an alias to a cap URN. Wirings connect nodes through capabilities using -> arrows. Fan-in uses parenthesized groups: [(a, b) -> cap -> target]. ForEach uses the LOOP keyword: [items -> LOOP cap -> results].

Commands

The graph icon also appears in the editor title bar for .machine files.

Settings

Requirements

• VS Code 1.85.0 or later
• Internet connection for registry-backed completions and hover enrichment (diagnostics and graph work offline)
