COBOL SLA Guardian — CI/CD Performance Impact Agent

A static performance analysis agent that integrates directly into the CI/CD pipeline. It analyzes COBOL code changes without running them on a test LPAR, predicts their resource consumption using trained ML models, and fails the build if the predicted impact would breach production SLAs.

What it does

When a developer raises a Pull Request with COBOL changes, the pipeline automatically:

1. Detects which .cbl / .cob files changed
2. Parses and validates the COBOL syntax statically
3. Extracts performance features (loop depth, I/O operations, arithmetic, control flow)
4. Feeds those features into a trained Random Forest ML model to predict cpu_time and session_time
5. Identifies the hottest (most CPU-intensive) statements line by line
6. Calls a GROQ LLM (Llama 3.3 70B) for AI-generated optimization suggestions
7. Fails the Jenkins build if the predicted CPU time exceeds the SLA threshold
8. Posts the full analysis summary as a comment on the GitHub Pull Request

Architecture

Developer PR (COBOL change)
        │
        ▼
  Jenkins Pipeline
        │
        ├── git diff → detect .cbl/.cob changes
        │
        ├── node ci/runAnalysis.js
        │       │
        │       ├── CobolAnalyzer       → syntax validation + feature extraction
        │       ├── ML Model (Python)   → predict cpu_time, session_time
        │       ├── FeatureExtractor    → line-by-line statement rows
        │       └── GROQ LLM            → AI optimization suggestions
        │
        ├── ci-result.json
        │
        ├── SLA check → PASS or FAIL build
        │
        └── GitHub API → PR comment with full SLA report

Additionally, a VS Code Extension gives developers the same analysis locally before pushing — with a live dashboard, inline diagnostics, and dead-code detection.

Tech stack

Project structure

ci-sla-guardian/
├── Jenkinsfile                  # Multibranch pipeline definition
├── ci/
│   └── runAnalysis.js           # CI entry point — orchestrates full analysis
├── src/
│   ├── extension.js             # VS Code extension activation
│   ├── cobolAnalyzer.js         # COBOL static parser & feature extractor (1100+ lines)
│   ├── featureExtractor.js      # Statement-level row builder for ML input
│   ├── cpuPredictor.js          # Calls Python ML model via execFile
│   ├── aiOptimizer.js           # GROQ / BMC LLM integration
│   └── dashboardPanel.js        # VS Code webview dashboard
├── backend/
│   └── predict.py               # Python ML inference script
├── models/
│   ├── cobol_model.pkl          # Trained COBOL program-level model
│   ├── random_forest_model.pkl  # Statement-level Random Forest model
│   ├── scaler.pkl               # Feature scaler
│   ├── scaler_X.pkl             # Input scaler for statement model
│   └── label_encoder.pkl        # COBOL statement type encoder
├── sample-data/
│   ├── loop1.cbl                # Heavy nested loop (SLA breach demo)
│   ├── loop2.cbl                # Multi-level loop test
│   └── loop4–6.cbl              # Additional test programs
├── output/
│   └── sla_features/            # Feature extraction output files
├── requirement.txt              # Python dependencies
└── package.json                 # Node.js dependencies + VS Code manifest

Setup & installation

Prerequisites

• Jenkins with the Multibranch Pipeline and GitHub Branch Source plugins
• Node.js 18+
• Python 3.9+
• A GROQ API key (free tier at console.groq.com)

Jenkins credentials required

Local development (VS Code extension)

git clone https://github.com/Tanvi-vilaskar/ci-sla-guardian.git
cd ci-sla-guardian
npm install
pip install -r requirement.txt

Open in VS Code → press F5 to launch the Extension Development Host → open any .cbl file → save to trigger analysis.

Running CI analysis manually

node ci/runAnalysis.js sample-data/loop2.cbl

Pipeline configuration

The Jenkinsfile uses these environment variables — all configurable per branch or globally in Jenkins:

SLA breach output example

When the pipeline detects a breach, it posts this to the PR:

SLA analysis for PR:

- `sample-data/loop2.cbl` -> CPU=12.4s, Session=45.2s, Status=BREACHED
  - Hottest stmt: line 19, type PERFORM, combined CPU=8.3
  - AI Summary: The MAIN-LOOP contains 7 levels of nested PERFORM loops
    with combined iteration count exceeding 375 billion operations.
  - Suggestion: Replace innermost loops with set-based COMPUTE operations
  - Reason: Reduces O(n^7) complexity to O(n^4)
  - Safety: Safe to apply — no file I/O or external calls in inner loop

Thresholds: SLA_THRESHOLD=5.0s, SESSION_THRESHOLD=20.0s

SLA Guardian: BUILD FAILED (Static Performance Analysis)

VS Code extension commands

Analysis runs automatically on every file save (configurable via slaGuardian.enableOnSave).

Branch strategy

25+ Pull Requests have been raised and merged across branches during development, with the Jenkins pipeline running on each one.

ML model details

Two models are trained and used:

Program-level model (cobol_model.pkl) — predicts overall cpu_time and session_time for the full program based on aggregated features: max loop depth, nested loop count, total PERFORMs, file I/O count, IF statements, function calls, and arithmetic operations.

Statement-level model (random_forest_model.pkl) — predicts per-statement combined, attributed, and executed CPU % for each COBOL statement type (PERFORM, COMPUTE, MOVE, READ, WRITE, etc.), enabling line-by-line hotspot identification.

Training data source: Historical RMF/SMF performance monitoring logs correlated with COBOL program structure.

Known limitations

• Analysis is static — actual runtime can vary based on data volumes and system load
• COBOL dialect support is tuned for IBM Enterprise COBOL (fixed-format); free-format COBOL has partial support
• ML models were trained on a specific workload profile — predictions are estimates, not guarantees
• GROQ API requires internet access from the Jenkins agent

License

VIIT — see LICENSE for details.
