Chartographer

Initially based on Call Graph

vscode extension to generate call graph using Cytoscape.js based on vscode call hierarchy language feature.

Features

• works on any language with a language server
• show functions and methods grouped by file
• Hover + E to expand a node one level
• Hover + Shift+E to expand recursively
• Hover + Del to remove a node
• Ctrl/Cmd+Click to jump to function location
• Right-click context menu with remove, expand, and go to function
• ignore files by glob pattern (test files, etc)
• trim function names with user-configurable regex
• add a function to an existing graph
• search for functions by name
• configurable layout algorithm (klay, dagre, elk)
• panel state persists across VS Code restarts
• supports color themes

Quick start

1. Move your editor cursor over a function name
2. Run Chartographer: Show Call Graph via Ctrl+Shift+P or right-click context menu
3. Pick direction (Both/Incoming/Outgoing) and enter max depth (blank = unlimited)
4. Hover a node + press E to expand, Del to remove, or right-click for context menu

Requirements

Chartographer relies on the "call hierarchy" feature of an LSP server. So, to use Chartographer for your project analysis, you must have a language server extension that supports "call hierarchy."

Development

Prerequisites

• Node.js 18+
• npm

Build

npm install
npm run build       # esbuild → out/extension.js + out/webview.js
npm run typecheck   # tsc --noEmit
npm run test:unit   # 25 unit tests

Package

npm run package     # produces chartographer-<version>.vsix

Release

1. Update version in package.json
2. Update CHANGELOG.md
3. Build: npm run build && npm run package
4. Install the VSIX locally to verify: code --install-extension chartographer-<version>.vsix --force
5. Publish to marketplace: vsce publish
6. Create a GitHub release with the VSIX attached

For more information

• GitHub

Enjoy!
