OpenFOAM Language Support for VS Code

A comprehensive VS Code extension providing syntax highlighting and IntelliSense for OpenFOAM dictionary files.

Features

🎨 Syntax Highlighting

• Color-coded tokens for keywords, values, comments, strings, and numbers
• Support for OpenFOAM dictionary syntax including:
  • FoamFile headers
  • Dictionary blocks with braces
  • Include directives (#include, #includeEtc, etc.)
  • Comments (C++ style // and /* */)
  • Scientific notation numbers

🧠 IntelliSense

Hover Information

Hover over any OpenFOAM keyword to see:

• Concise description of the keyword
• Required and optional parameters
• Parameter types and default values
• Usage examples
• Source file reference (where extracted from)

Auto-Completion

• Context-aware keyword suggestions
• Snippet-style completions with tab stops
• Parameter templates for complex keywords
• Prioritized suggestions based on file context

Signature Help

• Parameter information while typing
• Shows parameter names, types, and descriptions
• Indicates required vs. optional parameters

Supported File Types

The extension automatically activates for:

File Extensions

• .foam - OpenFOAM case files
• .dict - Dictionary files

Specific Filenames

• controlDict - Simulation control parameters
• fvSchemes - Discretization schemes
• fvSolution - Linear solver settings
• blockMeshDict - Mesh generation
• snappyHexMeshDict - Advanced meshing
• decomposeParDict - Parallel decomposition
• transportProperties - Physical properties
• turbulenceProperties - Turbulence model settings
• thermophysicalProperties - Thermophysical properties
• And many more...

Installation

From Source

1. Clone or copy the extension to your workspace:

   cd /path/to/OpenFOAM-13-master/openfoam-vscode-extension


2. Install dependencies:

   npm install


3. Extract OpenFOAM keywords (important!):

   npm run compile
   npm run extract-keywords


   Or specify a custom OpenFOAM source directory:

   node out/extractor/extractKeywords.js /path/to/OpenFOAM-source


4. Compile the extension:

   npm run compile


5. Package the extension (optional):

   npm install -g vsce
   vsce package


   This creates a .vsix file you can install.

6. Install in VS Code:

   • Method 1: Copy the extension folder to ~/.vscode/extensions/
   • Method 2: In VS Code, press F5 to launch Extension Development Host
   • Method 3: Install the .vsix file via Extensions panel → "..." → Install from VSIX

Usage

Basic Usage

1. Open any OpenFOAM dictionary file (controlDict, fvSchemes, etc.)
2. The extension activates automatically
3. Start typing to see completions
4. Hover over keywords for documentation
5. Use Ctrl+Space to trigger completions manually

Refreshing the Keyword Database

If you update your OpenFOAM source or want to extract from a different version:

1. Via Command Palette:

   • Press Cmd+Shift+P (Mac) or Ctrl+Shift+P (Windows/Linux)
   • Type "OpenFOAM: Refresh Keyword Database"
   • Enter your OpenFOAM source directory path
   • Wait for extraction to complete
   • Reload VS Code window

2. Via Terminal:

   cd /path/to/openfoam-vscode-extension
   node out/extractor/extractKeywords.js /path/to/OpenFOAM-source
   # Then reload VS Code


Development

Project Structure

openfoam-vscode-extension/
├── package.json                    # Extension manifest
├── tsconfig.json                   # TypeScript configuration
├── language-configuration.json     # Language configuration
├── src/
│   ├── extension.ts               # Extension entry point
│   ├── language-server/
│   │   └── server.ts              # Language server implementation
│   └── extractor/
│       └── extractKeywords.ts     # Keyword extraction script
├── syntaxes/
│   └── openfoam.tmLanguage.json   # TextMate grammar
├── data/
│   └── openfoam-keywords.json     # Generated keyword database
├── examples/
│   ├── controlDict                # Example OpenFOAM files
│   ├── fvSchemes
│   ├── fvSolution
│   └── U
└── README.md                       # This file

Building and Debugging

Compile TypeScript:

npm run compile

Watch mode (auto-recompile on changes):

npm run watch

Debug the extension:

1. Open the extension folder in VS Code
2. Press F5 to launch Extension Development Host
3. Open an OpenFOAM file in the new window
4. Set breakpoints in the TypeScript source

Debug the language server: The language server runs in a separate process. To debug:

1. Uncomment the --inspect line in src/extension.ts
2. Launch the extension with F5
3. Attach a debugger to the language server process (port 6009)

Keyword Extraction Process

The keyword extractor (src/extractor/extractKeywords.ts) performs the following:

1. Hardcoded Keywords: Adds ~100 essential OpenFOAM keywords with detailed documentation
2. Source Scanning:
   • Walks the OpenFOAM source tree (src/, applications/, etc/)
   • Extracts keywords from C++ files using regex patterns:
     • dict.lookup() and lookupOrDefault() calls
     • String literals in dictionary access patterns
   • Extracts keywords from OpenFOAM dictionary templates
3. Documentation Extraction:
   • Searches for Doxygen-style comments (//!, ///, /* */)
   • Extracts inline comments near keyword usage
4. Categorization: Automatically categorizes keywords:
   • control - Time and simulation control
   • solver - Linear solver settings
   • scheme - Discretization schemes
   • boundary - Boundary conditions
   • function - Function objects
   • property - Physical properties
   • utility - Mesh utilities
5. Output: Generates data/openfoam-keywords.json with structured data

Keyword Database Format

{
  "version": "1.0.0",
  "generatedAt": "2025-10-22T...",
  "sourceRoot": "/path/to/OpenFOAM",
  "keywordCount": 150,
  "keywords": [
    {
      "name": "deltaT",
      "description": "Time step size (seconds)",
      "category": "control",
      "parameters": [
        {
          "name": "value",
          "type": "scalar",
          "required": true,
          "description": "Time step in seconds"
        }
      ],
      "examples": [
        "deltaT          0.001;"
      ],
      "sourceFile": "src/OpenFOAM/..."
    }
  ]
}

Coverage

Implemented Keywords (~100+ essential keywords)

Control Keywords:

• application, startFrom, startTime, stopAt, endTime
• deltaT, writeControl, writeInterval, writeFormat
• adjustTimeStep, maxCo, maxAlphaCo, runTimeModifiable

Solver Keywords:

• solver, preconditioner, tolerance, relTol
• minIter, maxIter, smoother, nSweeps
• GAMG, PCG, PBiCG, smoothSolver

Scheme Keywords:

• ddtSchemes, gradSchemes, divSchemes, laplacianSchemes
• Euler, backward, CrankNicolson, steadyState
• Gauss, linear, upwind, linearUpwind, vanLeer, LUST

Boundary Conditions:

• fixedValue, zeroGradient, calculated, mixed
• inletOutlet, slip, noSlip, symmetry, empty
• type, value, boundaryField, internalField

Additional keywords are extracted from your OpenFOAM source during the extraction process.

Known Limitations

Current Implementation

1. Regex-based extraction: The keyword extractor uses regular expressions rather than full C++ AST parsing. This means:

   • Some complex keyword patterns may be missed
   • False positives may occur for generic string literals
   • Nested namespace and class context is not fully captured

2. Documentation quality: Documentation quality depends on:

   • Presence of comments in the source code
   • Proximity of comments to keyword usage
   • Doxygen-style documentation availability

3. No diagnostics: The current version does not provide:

   • Syntax error checking
   • Value validation
   • Required parameter verification
   • Type checking

4. Limited signature help: Signature help is basic and doesn't track cursor position within parameter lists

5. Static database: The keyword database must be manually regenerated when:

   • Switching OpenFOAM versions
   • Updating the OpenFOAM source
   • Adding custom keywords

Future Improvements

High Priority

• [ ] Add proper C++ AST parsing for keyword extraction (using libclang or tree-sitter)
• [ ] Implement diagnostics for syntax errors
• [ ] Add value validation based on parameter types
• [ ] Improve signature help with active parameter tracking
• [ ] Support for OpenFOAM dictionary inheritance and #include resolution

Medium Priority

• [ ] Add code actions (quick fixes) for common issues
• [ ] Implement document formatting
• [ ] Add snippets for common dictionary patterns
• [ ] Support for field file templates
• [ ] Integration with OpenFOAM version detection

Low Priority

• [ ] Go-to-definition for included files
• [ ] Find references for dictionary keys
• [ ] Workspace-wide symbol search
• [ ] Integration with OpenFOAM case validation tools
• [ ] Support for foam file system links

Contributing

This is a first-draft extension skeleton. Contributions are welcome!

Areas for Contribution

1. Keyword coverage: Add more keywords and better documentation
2. Parser improvements: Replace regex with proper parsing
3. Diagnostics: Add syntax and semantic checking
4. Testing: Add unit and integration tests
5. Documentation: Improve user and developer documentation

Development TODO Comments

The code contains TODO comments marking areas needing improvement:

• TODO: Enhance with proper C++ AST parsing
• TODO: Add support for parsing OpenFOAM dictionary files directly
• TODO: Replace regex-based extraction with proper C++ AST parsing
• TODO: Handle nested class definitions and namespaces better

Testing

Manual Testing

1. Open the example files in examples/
2. Verify syntax highlighting appears correctly
3. Hover over keywords like deltaT, solver, type
4. Start typing in a dictionary and check completions
5. Test with your own OpenFOAM cases

Test Checklist

• [ ] Syntax highlighting works for all token types
• [ ] Hover shows information for essential keywords
• [ ] Completions appear when typing
• [ ] Completions insert correct snippet format
• [ ] Extension activates for all specified file patterns
• [ ] Keyword refresh command works
• [ ] No errors in Developer Tools console

Troubleshooting

Extension doesn't activate

• Check that your file matches one of the supported patterns
• Look for errors in Developer Tools (Help → Toggle Developer Tools)
• Ensure the extension is installed and enabled

No IntelliSense suggestions

• Verify keyword database exists: data/openfoam-keywords.json
• Run keyword extraction if database is missing
• Check language server is running (look for "OpenFOAM Language Server" in Output panel)
• Reload VS Code window

Keyword extraction fails

• Ensure you have the correct path to OpenFOAM source
• Check you have read permissions for the source directory
• Verify Node.js and TypeScript are installed
• Check terminal output for specific error messages

Performance issues

• The keyword database loading is done once at startup
• If you have performance issues, check the size of openfoam-keywords.json
• Consider reducing the source scanning scope in extractKeywords.ts

License

This extension is provided as-is for use with OpenFOAM. OpenFOAM is licensed under the GNU General Public License v3.0.

Credits

• OpenFOAM: The OpenFOAM Foundation (https://openfoam.org)
• VS Code Extension API: Microsoft
• Language Server Protocol: Microsoft

Version History

0.1.0 (Initial Release)

• Basic syntax highlighting for OpenFOAM dictionary files
• Hover information for ~100 essential keywords
• Auto-completion with snippets
• Signature help for parameters
• Keyword extraction from OpenFOAM source
• Support for common OpenFOAM file types

Note: This is a first-draft extension skeleton designed to be extended and improved. The extraction process uses heuristics and may not capture all keywords or documentation perfectly. Contributions to improve coverage and accuracy are welcome!
