ArchSetu

Understand any JavaScript or TypeScript codebase instantly — without AI.

ArchSetu is a VS Code extension that gives developers deep structural insight into their code. It answers the questions every developer asks when they open an unfamiliar project:

Where does this app even start?
If I change this function, what breaks?
Which functions are dead and can be safely deleted?
How healthy is this codebase overall?
Which files are the most complex?

No internet connection. No API keys. No AI. Just fast, accurate, offline analysis of your JavaScript and TypeScript files.

Why ArchSetu is Different

Tools like Cursor, Copilot, and Cline are built for writing code. ArchSetu is built for understanding code.

What you want to know	Cursor / Copilot	ArchSetu
Write new code faster	✅	❌
Understand an unfamiliar codebase	❌	✅
See all callers of a function across every file	❌	✅
Find dead (unused) functions project-wide	❌	✅
Know the blast radius before refactoring	❌	✅
Visualize the health of the entire project	❌	✅
See cross-file call relationships	❌	✅
Works offline with no API key	❌	✅

All Commands

Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P) and type ArchSetu to see every command.

Command	What it does
`ArchSetu: Explain File`	File stats: lines, functions, classes, imports, most complex function
`ArchSetu: Show Functions (Jump)`	Searchable list of all functions — pick one to jump to it
`ArchSetu: List Functions`	All functions with line numbers, lengths, and complexity scores
`ArchSetu: Function Graph (This File)`	Call graph within the current file
`ArchSetu: Cross-File Call Graph`	Call graph across the ENTIRE project
`ArchSetu: Find Dead Code`	Functions defined but never called anywhere in the project
`ArchSetu: Blast Radius Analysis`	Everything that depends on the function under your cursor
`ArchSetu: Detect Entry Points`	Routes, exports, event listeners, main() — where the app starts
`ArchSetu: Codebase Health Dashboard`	Visual panel: health score, hotspots, largest files, coupling
`ArchSetu: Change Impact Simulator`	Before you change a symbol — see risk score, every call site, routes, components, and test recommendations

Feature Explanations

1. Explain File

Command: ArchSetu: Explain File Works on: The file currently open in your editor

Gives you a one-glance summary of any JS/TS file. Useful when you open a file for the first time and want to know what you're dealing with before reading any code.

What it shows:

File name
Total number of lines
Number of functions detected
Number of classes
Number of import / require statements
Name and complexity score of the most complex function in the file

Example output:

╔═══════════════════════════════════════════════╗
║           ArchSetu — File Analysis            ║
╚═══════════════════════════════════════════════╝

  File          :  auth.ts
  Total Lines   :  284
  Functions     :  11
  Classes       :  1
  Imports       :  6
  Most Complex  :  validateTokenPayload()  — score 13  (High — consider splitting)

═══════════════════════════════════════════════════

When to use it:

First time opening a file
Code review — quickly gauge file complexity
Onboarding to a new project

2. Show Functions (Jump)

Command: ArchSetu: Show Functions (Jump) Works on: The file currently open in your editor

Opens a searchable dropdown (VS Code QuickPick) listing every function in the file. Type any part of the function name to filter. Press Enter to jump the cursor directly to that function.

What it shows in the dropdown:

Function icon + name
Line number
The actual source code line (so you can see the signature)

When to use it:

Navigating large files with many functions
Faster than scrolling or using Ctrl+F to search for a function name
Works better than the built-in "Go to Symbol" for complex files

3. List Functions

Command: ArchSetu: List Functions Works on: The file currently open in your editor

Prints a table of every function in the file to the ArchSetu output panel. Unlike "Show Functions", this stays visible as a reference while you work.

What it shows for each function:

Sequential number
Function name
Starting line number
Length in lines
Complexity score with label (Low / Med / HIGH)

Example output:

  #    Name                            Line    Length   Complexity
  ─────────────────────────────────────────────────────────────────
    1  activate                          381    14 lines   2 Low
    2  deactivate                        396     4 lines   1 Low
    3  validateUser                       45    38 lines   9 Med
    4  createToken                        84    12 lines   3 Low
    5  refreshToken                       97    61 lines  14 HIGH

When to use it:

Getting a full inventory of what's in a file
Identifying which functions are too long or too complex
Audit before a refactor

4. Function Graph (This File)

Command: ArchSetu: Function Graph (This File) Works on: The file currently open in your editor

Shows a text-based tree of which functions call which other functions — within this one file. Each function is shown as a root node, with lines below it showing what it calls.

Example output:

  login()  —  line 23
  ├── validateUser()
  └── createSession()

  validateUser()  —  line 45
  ├── hashPassword()
  └── queryDatabase()

  hashPassword()  —  line 78
  └── (does not call any other function in this file)

When to use it:

Understanding how functions relate to each other before editing
Finding long call chains that might be simplified
Understanding the flow of logic in a file

Note: This only shows calls within the current file. For cross-file connections, use "Cross-File Call Graph."

5. Cross-File Call Graph

Command: ArchSetu: Cross-File Call Graph Scope: Entire workspace (all JS/TS files)

This is ArchSetu's most powerful feature. It scans every JavaScript and TypeScript file in your project and maps out which files call functions defined in which other files. The result is a full picture of how your entire codebase is connected.

How it works:

Reads every .js, .ts, .jsx, .tsx file (skipping node_modules)
Detects all function definitions across all files
For each function, searches all OTHER files for calls to it
Groups results by the file that defines the function

Example output:

📁  src/utils/auth.ts
────────────────────────────────────────────────────
  validateUser()
    → src/routes/login.ts  :  line 45
      const result = validateUser(req.body, options)
    → src/middleware/guard.ts  :  line 12
      if (!validateUser(ctx.user)) return 401

  createToken()
    → src/routes/login.ts  :  line 67
      const token = createToken(userId, expiry)

Files scanned             : 24
Files with connections    : 8
Total cross-file calls    : 31

When to use it:

Starting on a new codebase — see the full picture in one command
Before a major refactor — understand all dependencies
Architecture review — spot which files are most heavily used

6. Find Dead Code

Command: ArchSetu: Find Dead Code Scope: Entire workspace (all JS/TS files)

Scans the entire project for functions that are defined somewhere but never called from anywhere. These are "dead" — they exist in the code but nothing uses them.

Why dead code is a problem:

Confuses developers ("is this actually used somewhere?")
Takes up space and adds maintenance burden
Can mask bugs that nobody notices because the code never runs

How it works:

Collects every function definition across all files
Searches the entire codebase for calls to each function name
If a function has no callers (or only the definition itself), it's flagged as dead

Example output:

  Found 3 potentially dead function(s):

  📁 src/utils/helpers.ts
       ⚠  formatDate()   —   line 12
       ⚠  parseCSV()     —   line 45

  📁 src/routes/admin.ts
       ⚠  legacyLogin()  —   line 89

  Total functions found    : 47
  Live (called somewhere)  : 44
  Dead (never called)      : 3

Important: This is static analysis. It cannot detect functions called via:

String names (e.g. obj[funcName]())
eval()
Dynamic require() or import()

Always review before deleting anything.

When to use it:

Before a release — clean up leftover code
After a big refactor — find functions that are no longer needed
Reducing bundle size — less code = faster load

7. Blast Radius Analysis

Command: ArchSetu: Blast Radius Analysis Works on: The word under your cursor (place cursor on any function name)

"Blast radius" is the term for how much of your codebase is affected if you change one thing. Before you rename, modify, or delete a function, run this command to see exactly what will break.

How to use it:

Open any file that contains (or calls) the function you're about to change
Click on the function's name so your cursor is on it
Run ArchSetu: Blast Radius Analysis from the Command Palette
Read the full list of every file and line that calls this function

Example output (cursor was on validateUser):

╔═══════════════════════════════════════════════════╗
║         ArchSetu — Blast Radius Analysis         ║
║  Everything that depends on this function        ║
╚═══════════════════════════════════════════════════╝

  Function        :  validateUser()
  Affected files  :  3
  Total call sites:  5

  All of the following will need attention if you change this function:

  📁 src/routes/auth.ts  (2 call site(s))
      line   45 :  const ok = validateUser(req.body)
      line   89 :  if (!validateUser(token)) throw new Error(...)

  📁 src/middleware/guard.ts  (2 call site(s))
      line   12 :  validateUser(ctx.user)
      line   34 :  return validateUser(payload)

  📁 tests/auth.test.ts  (1 call site(s))
      line   23 :  expect(validateUser(mockData)).toBe(true)

When to use it:

Before renaming a function
Before changing a function's parameters
Before deleting a function
During code review to understand impact of proposed changes

NEW — Change Impact Simulator

Command: ArchSetu: Change Impact Simulator Works on: The word under your cursor (function, class, or any exported symbol)

The most comprehensive pre-change analysis in ArchSetu. Before you touch a symbol, run this to see a full interactive panel showing everything that will be affected.

How to use it:

Place your cursor on any function name, class name, or exported identifier
Run ArchSetu: Change Impact Simulator from the Command Palette
A panel opens beside your editor with the full impact report

What the panel shows:

Section	Description
Risk Score (0–100)	A calculated score — the higher the number, the riskier the change
Risk Level	LOW / MEDIUM / HIGH / CRITICAL badge
Call Sites	Total number of times this symbol is called across the project
Files Affected	How many distinct files contain a call site
Importing Modules	Files that directly import the source file
API Routes	HTTP routes (GET/POST/etc.) in the affected files
Frontend Components	React/JSX component files (.tsx/.jsx) that use this symbol
Recommended Tests	Test files that should be run after this change
Circular Dependencies	Detected circular imports between the source file and its callers

Risk Score Algorithm:

Factor	Max Points
Number of call sites (the more callers, the riskier)	25
Number of distinct files affected	20
Number of modules that import the source file	15
Symbol touches live API routes	10
Symbol is used by frontend components	8
High function complexity	10
Circular dependencies detected	12
Symbol is exported (part of public API)	5
No test file found	5
Total	100

Risk Levels:

Score	Level	Meaning
0–25	LOW	Safe to change. Limited impact, well contained.
26–50	MEDIUM	Review callers before changing. Run the recommended tests.
51–75	HIGH	High blast radius. Coordinate with your team.
76–100	CRITICAL	Dangerous change. Touches API routes, many files, or has circular deps.

Example panel (cursor was on calculateInvoice):

⚡ Change Impact Simulator

calculateInvoice()
src/billing/invoice.ts                                              [HIGH]

┌────────────┬──────────────┬──────────────┬────────────┬──────────────┐
│  17        │  8           │  4           │  2         │  3           │
│  Call Sites│  Files       │  Modules     │  API Routes│  UI Components│
└────────────┴──────────────┴──────────────┴────────────┴──────────────┘

Risk Score  84 / 100
████████████████████████████████████████████████████░░░░░░░░░░

▶ API Routes (2)
▶ Frontend Components (3)
▶ Importing Modules (4)
▶ All Call Sites (17)
▶ Recommended Tests (3)
▶ Circular Dependencies (none)

When to use it:

Every time before you modify a function that might be shared
When onboarding — understand the risk profile of key functions
During architecture reviews — identify your highest-risk symbols
Before deploying — validate test coverage for changed functions

8. Detect Entry Points

Command: ArchSetu: Detect Entry Points Scope: Entire workspace (all JS/TS files)

Finds every "door into your application" — the places where execution starts or where the outside world can call into your code. Grouped by type for easy reading.

Entry point types detected:

Type	Examples
HTTP GET/POST/PUT/PATCH/DELETE	`app.get('/login', ...)`, `router.post('/users', ...)`
HTTP USE	`app.use('/api', ...)` — middleware routes
Event	`addEventListener('click', ...)`, `emitter.on('data', ...)`
Export	`export function myFunc()`, `export const handler = ...`
Main	`function main()` — classic app entry point
IIFE	`(async () => { ... })()` — self-running code on file load

Example output:

  ── HTTP GET ─────────────────────────────────────
  /                          src/routes/index.ts  :  line 5
  /api/users                 src/routes/users.ts  :  line 8
  /api/users/:id             src/routes/users.ts  :  line 15

  ── HTTP POST ────────────────────────────────────
  /api/login                 src/routes/auth.ts   :  line 12
  /api/register              src/routes/auth.ts   :  line 34

  ── Export ───────────────────────────────────────
  validateUser               src/utils/auth.ts    :  line 45
  hashPassword               src/utils/auth.ts    :  line 67

  ── Main ─────────────────────────────────────────
  main                       src/index.ts         :  line 1

  Total entry points found: 9

When to use it:

Day one on a new codebase — "where do I even start?"
API documentation — see all your routes in one place
Security review — see every public-facing entry point at a glance

Frameworks supported: Express, Fastify, Hapi, Koa, and any framework that uses app.METHOD() or router.METHOD() syntax.

9. Codebase Health Dashboard

Command: ArchSetu: Codebase Health Dashboard Scope: Entire workspace (all JS/TS files)

Opens a visual panel inside VS Code showing the overall health of your codebase. Think of it like the dashboard in a car — one look tells you if something needs attention.

What the dashboard shows:

Health Score (0–100) A single number that grades your codebase:

70–100 (Green — Healthy): Complexity is low, code is maintainable
40–69 (Orange — Needs Attention): Some complex functions that should be simplified
0–39 (Red — Critical): High complexity throughout, refactoring is strongly recommended

The score is calculated from the average maximum complexity across all files. The lower your complexity, the higher your score.

Key Stats (top row)

Total JS/TS file count
Total function count
Total lines of code
Average complexity score

Complexity Hotspots Table The 5 files with the highest complexity. Shows:

File path
The single most complex function in that file
Complexity score with warning labels

Largest Files Table The 5 files with the most lines. Files over 500 lines get a warning — they are likely doing too many things and are candidates for splitting.

Highest Coupling Table The 5 files that import the most other modules. High import counts mean the file depends on many other parts of the system, making it hard to change in isolation.

When to use it:

Monthly code health check
Before planning a refactoring sprint — see where to focus
When a new developer joins — show them where the rough edges are
After a fast-growth period to see what technical debt has accumulated

Complexity Score Explained

Every function in your project gets a complexity score. Here is how to read it:

Score	Label	What it means
1–5	Low	Simple and easy to understand. One main path through the code.
6–10	Medium	Getting complex. Several branches. Consider adding comments.
11+	High	Hard to follow. Multiple nested conditions, loops, or logic paths. Strong candidate for refactoring into smaller functions.

The score counts:

if / else if statements
for / while / do loops
case in switch statements
catch blocks
&& and || logical operators (short-circuit paths)
Ternary operators ? :

Supported Languages

TypeScript (.ts, .tsx)
JavaScript (.js, .jsx)

Function detection covers:

// 1. Named function declarations
function myFunc() {}
export async function myFunc<T>(arg: T): Promise<void> {}

// 2. Arrow functions
const myFunc = () => {}
const myFunc = async (a: string, b: number) => {}
export const myFunc = (x: number) => x * 2

// 3. Function expressions
const myFunc = function() {}
const myFunc = async function() {}

// 4. Class methods
class MyClass {
  public myMethod() {}
  private async fetchData(): Promise<Data> {}
  static getInstance() {}
}

Getting Started (Development)

# Install dependencies
npm install

# Build the extension
npm run build

# Build and watch for changes automatically
npm run watch

# Type-check without building
npm run lint

Then press F5 in VS Code to launch the Extension Development Host — a new VS Code window with ArchSetu loaded.

Open any JavaScript or TypeScript project folder in that window, open the Command Palette (Ctrl+Shift+P), and type ArchSetu to see all commands.

Tech Stack

TypeScript — the extension itself
VS Code Extension API — for editor integration, output panels, webviews, and QuickPick
ESBuild — fast bundling
Node.js fs module — for reading workspace files
No external runtime dependencies — everything is built-in

Performance Notes

Commands that scan the whole workspace (Cross-File Graph, Dead Code Finder, Entry Points, Health Dashboard, Change Impact Simulator) read every JS/TS file on disk. They show a loading spinner while working.

On small to medium projects (under ~500 files), these commands complete in 1–5 seconds. On very large projects (1000+ files), they may take 10–30 seconds.

node_modules and .d.ts files are always excluded automatically.

Feedback & Suggestions

Found a bug? Have an idea for a new feature? Something not working as expected?

Share your feedback here →

All feedback is read personally. Your input directly shapes what gets built next.

Privacy

ArchSetu performs 100% local, offline analysis.

Zero network requests
Zero telemetry
Zero API keys required
Your source code never leaves your machine

Architecture

ArchSetu is built as a modular Engineering Intelligence Platform:

src/
├── extension.ts          ← thin entry point (activate/deactivate only)
├── types/index.ts        ← all shared TypeScript interfaces
├── parser/               ← function detection engine (regex + brace counter)
├── analysis/             ← reusable analysis modules
│   ├── ComplexityAnalyzer.ts
│   ├── CallSiteAnalyzer.ts
│   └── ChangeImpactAnalyzer.ts
├── commands/             ← one file per VS Code command
├── ui/                   ← webview HTML builders + status bar
└── utils/                ← file I/O, text helpers, editor utilities

Every analysis module is independently reusable by future features. No logic is duplicated across commands.

ArchSetu

Archsetu

ArchSetu

Why ArchSetu is Different

All Commands

Feature Explanations

1. Explain File

2. Show Functions (Jump)

3. List Functions

4. Function Graph (This File)

5. Cross-File Call Graph

6. Find Dead Code

7. Blast Radius Analysis

NEW — Change Impact Simulator

8. Detect Entry Points

9. Codebase Health Dashboard

Complexity Score Explained

Supported Languages

Getting Started (Development)

Tech Stack

Performance Notes

Feedback & Suggestions

Privacy

Architecture
