RVBuildHelper VS Code Extension

An automated development environment orchestrator and high-fidelity script runner for two workspace profiles: RVRite Standalone and RVRite Integrated. Driven by an elegant, responsive React-based webview dashboard utilizing VS Code Native Aesthetics, Tailwind CSS, and optimized terminal virtualizations.

🚀 Key Features

Dual Mode Orchestration:
- Flow A (RVRite Standalone): Auto-compiles workspace assets via ./init.sh -cbm and provisions custom Nginx reverse proxy layouts pointing to http://rvrite.local.
- Flow B (RVRite Integrated): Auto-checks local MongoDB databases, lists running Docker microservices, starts PM2 ES Review Hub instances, and compiles with the correct sequential build options.
60FPS Log Buffer Streaming: Implements a custom debouncing algorithm (16ms batches) on backend subprocess streams (child_process.spawn) to prevent webview thread flooding, keeping your CPU cool.
100k+ Line Virtual Log Terminal: Integrates react-window inside the dashboard console, enabling effortless 60fps scrolling even with massive script compile logs.
WSL Paths Translation Engine: Detects Windows runtimes and translates NTFS drives (e.g. C:\Users\...) to POSIX WSL mount-paths (e.g. /mnt/c/Users/...) seamlessly.
Secure Sudo Portals: Safely spawns password-sensitive operations (like booting MongoDB via systemctl) inside native VS Code terminals, bypassing process stdin security blocks.
ANSI Terminal Color Decoder: Parses standard shell color directives in real time using ansi-to-html.
Keyboard Accelerators: Esc cancels active processes instantly; Ctrl+R restarts failed or completed steps.

🛠️ Requirements & Installation

System OS: Linux, macOS, or Windows (requires Windows Subsystem for Linux - WSL2).
Dependencies:
- Docker Desktop (or equivalent command CLI).
- MongoDB (local service name: mongod).
- PM2 daemon (npm install -g pm2).
- Nginx installed and configured for reverse-proxy overrides.

Manual Installation

Compile the .vsix archive:
```
npm run build
npm run package
```
Install the package in VS Code:
- Open VS Code and press Ctrl+Shift+P
- Select Extensions: Install from VSIX...
- Select the generated rvbuildhelper-0.0.1.vsix file.

⚙️ Path Configuration Walkthrough

When launching the dashboard for the first time, you will be prompted to enter the absolute paths to your development directories:

Configuration Field	Target Validation Marker	Purpose
RVRite Source Directory	Must contain `./init.sh`	Core standalone code workspace
Nginx Server Setup Directory	Must contain `./make_nginx_server.sh`	Reverse proxy mapping scripts
Review Work Directory	Must contain `./build_script.sh`	Flow B integration scripts
ES Review Hub Directory	Must contain `server.js`	Express PM2 server codebase
Dockerfile Path (Optional)	Absolute path to Dockerfile	Parsed to discover target container images
Docker Identifiers (Optional)	Comma-separated labels (e.g. `redis, postgres`)	Docker status matcher overrides

📋 Workspace Flows

Flow A: Build RVRite Standalone

graph TD
    Start[Click Standalone Mode] --> PathCheck{Paths Configured?}
    PathCheck -- Yes --> Init[1. Spawn ./init.sh -cbm]
    PathCheck -- No --> Config[Open Settings Panel]
    Init -- Exit 0 --> Nginx[2. Spawn ./make_nginx_server.sh with input '1']
    Nginx -- Exit 0 --> Success[Show URL: http://rvrite.local]

Flow B: Build RVRite Integrated

graph TD
    Start[Click Integrated Mode] --> CheckMongo{MongoDB Active?}
    CheckMongo -- No --> Warning[Show Warn: Boot Mongo Service]
    CheckMongo -- Yes --> CheckDocker{Required Docker Containers Running?}

    CheckDocker -- No --> FlowB2[Flow B.2: Build Script Option 1 -> PM2 Hub]
    CheckDocker -- Yes --> FlowB1[Flow B.1: PM2 Hub -> Build Script Option 2]

    FlowB2 --> Success[Show URL: http://review.local]
    FlowB1 --> Success

🛠️ Diagnostics & Troubleshooting

Docker Connection Fails: Verify that Docker is running (docker info). If using Windows, make sure Docker Desktop integration with your default WSL2 distribution is enabled in settings.
MongoDB Starting Prompt: Clicking "Start MongoDB" will spawn a VS Code terminal executing sudo service mongod start (or WSL equivalent). Enter your user password directly inside the secure VS Code editor terminal.
WSL Path Errors: The extension translates drive mappings automatically. If paths fail to resolve, double-check that you can access the path using cd inside your WSL shell directly.

🧪 Development & Architecture

Built with strict TypeScript compile standards:

Backend extension host bundle: Compiled via esbuild.
Webview dashboard bundle: Built via Vite + React + Tailwind CSS.
Testing: Virtual process lifecycle mocking validated via Vitest.
Linting: Custom rules checking explicit type checking parameters.

📄 License

MIT. Developed for advanced RVRite workspace integration workflows.
