👻 VSCode Fantom LSP

Unofficial Language Server Protocol support for Fantom in Visual Studio Code.

🏢 About J2 Innovations & FIN Framework

J2 Innovations is a technology company that created FIN Framework — a cutting-edge open platform for smart buildings, smart equipment control, and IoT systems. FIN powers supervisory & control solutions, microBMS, equipment optimization, and edge-to-cloud connectivity, and is trusted by major OEM partners including Siemens, SageGlass, and Coster Group.

FIN Framework is built on Fantom — a JVM-based, object-oriented programming language. All FIN application code, connectors, and extensions are written in Fantom, making a productive Fantom development environment essential for anyone building on the FIN platform.

This extension was created to improve the day-to-day developer experience when working with FIN Framework and Fantom projects in Visual Studio Code. It brings real-time diagnostics, autocompletion, go-to-definition, hover documentation, and a full debugger — all tailored to the Fantom ecosystem that powers FIN.

This extension brings a rich developer experience to Fantom projects inside VSCode — syntax highlighting, real-time diagnostics, autocompletion, hover docs, go-to-definition, debugging with breakpoints and variable inspection, and more. It is powered by a Fantom LSP server written entirely in Fantom itself (vscodeFantomLsp), automatically deployed into your Fantom installation when the extension activates.

⚠️ This is an unofficial, community-driven project. It is not affiliated with or endorsed by the Fantom language authors or J2 Innovations.

✨ Features

✅ Implemented

Feature	Description
🔍 Go to Definition	Jump to the definition of types, methods, and fields across project files
💡 Auto Completion	Context-aware suggestions triggered on `.` (dot) and keyword prefix
⇥ Tab Completion	Complete identifiers and keywords without reaching for the mouse
🔁 Duplicate `static const` detection	Warns when two or more static const fields share the same string value across the project
🗑️ Unused variable detection	Highlights variables that are declared but never read
🧹 Unused import detection	Warns on `using` statements that are not referenced in the file
🎯 Hover information	Shows type signatures and pod documentation when hovering over a symbol
🚨 Real-time diagnostics	Syntax errors and type errors from the Fantom compiler, debounced while typing
🔗 Cross-file validation	Detects unresolved type references across all project source files
🏗️ Build integration	Runs `fan build.fan` on save and reports compiler errors with clickable file links
🖊️ Syntax highlighting	Full TextMate grammar for `.fan` files
🧩 Remove Unused Imports	Command to remove all unused `using` lines in a file or the whole project
🧩 Remove Unused Variables	Command to remove all unused variable declarations in a file or the whole project
📊 Status bar diagnostics	Live error and warning counts in the VSCode status bar
🐛 Debugger (DAP)	Set breakpoints, step through code, and inspect variables in Fantom programs on the JVM

📋 Requirements

Fantom ≥ 1.0.80 installed locally — Download
Java JDK (not just JRE) available in your PATH or via JAVA_HOME — the debugger needs the jdk.jdi module (JDK 9+)
VSCode ≥ 1.75.0

Don't have Fantom? Run the helper script included in this repo:
./install-fantom.sh
It fetches and unpacks the latest Fantom release for you.

🚀 Installation

From the VSIX (recommended)

Download the latest .vsix from the Releases page.
In VSCode open the Command Palette (Ctrl+Shift+P) → Extensions: Install from VSIX…
Select the downloaded file.

Or install from the terminal:

code --install-extension fantom-language-support-${TAG}.vsix

From Source

# 1. Build the LSP pod (requires Fantom installed and in PATH)
fan build.fan

# 2. Build the debug adapter JAR (requires JDK 11+)
cd vscode-fantom
bash debug-adapter/build.sh

# 3. Install Node.js dependencies and build the extension
pnpm install
pnpm run compile

# 4. Package (optional)
pnpm dlx @vscode/vsce package

⚙️ Configuration

The extension looks for configuration in two places, in priority order:

1. `fan.config.json` (project-level, recommended)

Create a fan.config.json file in the root of your workspace. The extension will offer to create a skeleton automatically on first activation if the file is missing.

{
  "fanPath": "/opt/fantom-1.0.82",
  "fanTargetBuild": "compile",
  "debounceTime": 1000,
  "enableUnusedImport": true
}

Key	Type	Default	Description
`fanPath`	`string`	`""`	Absolute path to your Fantom installation directory (the folder that contains `bin/fan`). When empty or set to the placeholder value, the extension falls back to the `FAN_HOME` environment variable.
`finPath`	`string`	`""`	Direct path to the `fin` executable (e.g. `/opt/intelliplant/bin/fin`). When set, the debugger prefers this over `fanPath` for launch configurations.
`fanTargetBuild`	`string`	`""`	The build target passed to `fan build.fan <target>` on every save. Leave empty to run the default target.
`debounceTime`	`number`	`2000`	Milliseconds to wait after the last keystroke before running diagnostics. Lower values give faster feedback; higher values are gentler on large projects. Minimum: `100`.
`enableUnusedImport`	`boolean`	`true`	When `false`, unused `using` import warnings are suppressed entirely.

💾 The LSP server restarts automatically whenever fan.config.json is saved.

2. `FAN_HOME` environment variable (global fallback)

If fanPath is not set (or left as the placeholder) in fan.config.json, the extension reads the FAN_HOME environment variable:

# ~/.bashrc / ~/.zshrc
export FAN_HOME=/opt/fantom-1.0.82
export PATH=$FAN_HOME/bin:$PATH

Resolution order (first wins):

fanPath in fan.config.json
FAN_HOME environment variable
Extension shows a warning and does not start

3. VSCode settings (`settings.json`)

Additional settings available through the VSCode UI or settings.json:

Setting	Type	Default	Description
`fantom.javaPath`	`string`	`""`	Full path to the `java` executable. Defaults to `$JAVA_HOME/bin/java`, then just `java` from `PATH`.
`fantom.useBuiltInLspPod`	`boolean`	`true`	Use the `vscodeFantomLsp` bundled with the extension (recommended). Set to `false` only if you have built and installed your own LSP pod.
`fantom.pedanticMode`	`boolean`	`false`	Warn on local variable declarations that lack an explicit type annotation (neither a type on the left side nor an `as` cast on the right).
`fantom.trace.server`	`string`	`"off"`	Trace LSP message traffic: `"off"`, `"messages"`, or `"verbose"`. Useful for debugging the extension itself.

🛠️ Commands

Access these from the Command Palette (Ctrl+Shift+P):

Command	Description
Fantom: Remove Unused Imports in File	Deletes all unused `using` lines in the current file and saves
Fantom: Remove Unused Imports in Project	Deletes unused `using` lines across every `.fan` file in the project
Fantom: Remove Unused Variables in File	Deletes unused variable declarations in the current file
Fantom: Remove Unused Variables in Project	Deletes unused variable declarations across the whole project
Fantom: Create launch.json for Fantom Debugger	Creates `.vscode/launch.json` with default Launch and Attach configurations pre-filled from `fan.config.json`

🏗️ How It Works

VSCode Extension (TypeScript)
        │
        │  stdio (LSP protocol)
        ▼
  vscodeFantomLsp  ─── fan vscodeFantomLsp::Main
        │
        ├── ProjectIndex      (AST index of all .fan sources)
        ├── DiagnosticService (single-file + cross-file analysis)
        ├── CompletionService (dot-completion, keyword suggestions)
        ├── DefinitionService (go-to-definition)
        ├── HoverService      (type signatures, pod docs)
        └── fan build.fan     (real compiler, error reporting)

VSCode Extension (TypeScript)
        │
        │  stdin/stdout (DAP protocol)
        ▼
  fantom-debug-adapter.jar
        │
        │  JDWP / TCP
        ▼
  JVM running your Fantom program

On activation the extension:

Reads fan.config.json (or falls back to FAN_HOME).
Deploys (or updates) vscodeFantomLsp into $FAN_HOME/lib/fan/.
Spawns the LSP server via fan vscodeFantomLsp::Main.
Registers the Fantom debug adapter so it is available immediately in the Run & Debug panel.
The server indexes all .fan sources from build.fan's srcDirs, pre-loads available pods, runs diagnostics, and performs an initial build check — all in the background so the editor stays responsive.

Diagnostics lifecycle

While typing — changes are debounced (debounceTime ms). No analysis runs until typing pauses.
After the debounce window — single-file analysis runs immediately for fast feedback.
On save — a full project re-index, cross-file validation, and fan build.fan all run together.

🐛 Debugger

The extension includes a full Debug Adapter Protocol (DAP) implementation that lets you set breakpoints, step through code, and inspect variables in Fantom programs running on the JVM.

Prerequisite: A JDK (not just a JRE) is required — the debugger uses JDI, which is part of the JDK tools (jdk.jdi module, available in JDK 9+).

How it works

The debug chain

VS Code  ←DAP/JSON-RPC→  fantom-debug-adapter.jar  ←JDWP/TCP→  JVM (your Fantom program)

VS Code communicates with the debug adapter using the Debug Adapter Protocol over stdin/stdout.
fantom-debug-adapter.jar (bundled with this extension) translates those commands into JDI calls. JDI (Java Debug Interface) is available in every JDK.
The JVM exposes a JDWP server socket when started with -agentlib:jdwp=.... The adapter connects to that socket to set breakpoints, read variables, and control execution.

How `.fan` source files map to running code

Fantom compiles .fan files to standard JVM .class bytecode. Two standard attributes enable source-level debugging:

SourceFile — records the short filename (e.g. MyService.fan) in each .class file.
LineNumberTable — maps each bytecode instruction back to its original Fantom line number.

These attributes are always emitted by the Fantom compiler with no special build flags needed.

What is and is not inspectable

Item	Available	Notes
`this` fields	✅	All instance fields shown under the "this" scope
Local variables	✅ (best-effort)	Shown when `LocalVariableTable` is present; otherwise method parameters are shown
Variable types	✅	Proper Fantom type names (`myPod::MyClass`, `sys::List`, etc.)
Variable values	✅	Calls Fantom's `toStr()` — shows the actual value, not `fan.sys.List@123`
Step over / into / out	✅	Works at the Fantom source line level
Line breakpoints	✅	Click the gutter in any `.fan` file
Watch expressions	✅	Supports `varName`, `this.field`, and `a.b.c` chains
Conditional breakpoints	❌	Not yet implemented

Java configuration

The JVM must be started with the JDWP agent to allow debugger connections.

Option A — `config.props` (for `fan` and `fin`)

Edit <fanHome>/etc/sys/config.props:

java.options=-agentlib:jdwp=transport=dt_socket,server=y,suspend=n,address=5005

JDWP option	Meaning
`transport=dt_socket`	Use a TCP socket
`server=y`	JVM opens the server socket
`suspend=n`	Program starts immediately; debugger can attach at any time
`suspend=y`	JVM waits for a debugger before starting — useful for debugging initialization
`address=5005`	TCP port

If you already have other JVM flags on java.options, separate them with a space (not a comma):

java.options=-agentlib:jdwp=transport=dt_socket,server=y,suspend=n,address=5005 -Dfile.encoding=UTF8

Cleanup: Remove the java.options line when done. With suspend=y left in place the program will hang on startup waiting for a debugger.

Option B — `JAVA_TOOL_OPTIONS` environment variable

Works for attach mode when you start the process manually before connecting:

export JAVA_TOOL_OPTIONS="-agentlib:jdwp=transport=dt_socket,server=y,suspend=n,address=5005"
fin

Do not use JAVA_TOOL_OPTIONS with launch mode. In launch mode the JDWP agent is injected via java.options in a temporary shadow config.props, which is scoped to that one JVM and never inherited by child processes. Using JAVA_TOOL_OPTIONS in parallel causes a port conflict and a bind failed: Address already in use error.

Quick start — Attach mode (recommended for FIN)

Step 1. Enable JDWP in <fanHome>/etc/sys/config.props:

java.options=-agentlib:jdwp=transport=dt_socket,server=y,suspend=n,address=5005

Step 2. Start your program normally:

fin
# or: fan myPod::Main

You will see Listening for transport dt_socket at address: 5005 confirming the port is open.

Step 3. Create .vscode/launch.json:

Tip: Run Fantom: Create launch.json for Fantom Debugger from the Command Palette (Ctrl+Shift+P) to generate this file automatically. The extension also offers to create it on first activation when fan.config.json is present and no launch.json exists.

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "fantom",
      "request": "attach",
      "name": "Attach to Fantom / FIN",
      "host": "localhost",
      "port": 5005,
      "sourceDir": "${workspaceFolder}"
    }
  ]
}

Step 4. Press F5 to connect.

Step 5. Click the gutter next to a line in any .fan file to set a breakpoint.

VS Code tip: If gutter clicks don't place breakpoints, add this to settings.json:
"debug.allowBreakpointsEverywhere": true

Launch mode — VS Code starts the process

In launch mode VS Code starts the Fantom/FIN process for you when you press F5. You do not need to touch config.props or start anything manually.

What happens when you press F5

The adapter picks a free TCP port automatically (defaults to 5005, falls back to any free ephemeral port if 5005 is already in use — e.g. by a running FIN server).
A temporary shadow FAN_HOME is created in /tmp/fantom-debug-home-*/:
- Every top-level entry from your real FAN_HOME is symlinked except etc/ and var/.
- etc/sys/config.props is rewritten: java.options from the original is stripped (prevents double-JDWP conflicts) and a fresh JDWP agent line for the chosen port is injected. debug=true is also added so any pods rebuilt with preLaunchRebuild emit full local variable info.
- var/ is a real directory with only sub-directories symlinked — lock files like vm.lock are created fresh, completely isolated from any running FIN server.
Your executable is launched with FAN_HOME pointing to the shadow directory.
The adapter attaches JDI to the JDWP port and is ready for breakpoints.
When you press Stop (or close the session), the entire process group is killed with SIGKILL and the shadow directory is deleted.

Because JDWP is injected via java.options in the shadow config.props — not via JAVA_TOOL_OPTIONS — it affects only the launched JVM and is never inherited by child processes or the running FIN server.

Step 1. Create `fan.config.json` (if not already present)

{
  "fanPath": "/path/to/fantom"
}

Step 2. Create `.vscode/launch.json`

Plain fan launcher (explicit mainClass required):

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "fantom",
      "request": "launch",
      "name": "Launch Fantom",
      "fanExe": "/path/to/fantom/bin/fan",
      "mainClass": "myPod::Main",
      "sourceDir": "${workspaceFolder}"
    }
  ]
}

fin launcher (already embeds its entry point — mainClass must be empty):

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "fantom",
      "request": "launch",
      "name": "Launch FIN",
      "fanExe": "/path/to/intelliplant/bin/fin",
      "mainClass": "",
      "sourceDir": "${workspaceFolder}"
    }
  ]
}

Why "mainClass": ""?
The fin script wraps fanlaunch Fan finStackHost "$@" — the pod name is hardcoded inside the script. Passing an extra finStackHost::Main argument after -noAuth confuses FIN's argument parser. Leave mainClass empty and rely on the script's built-in entry point.

fin with -noAuth:

{
  "type": "fantom",
  "request": "launch",
  "name": "Launch FIN (no auth)",
  "fanExe": "/path/to/intelliplant/bin/fin",
  "mainClass": "",
  "launcherArgs": ["-noAuth"],
  "sourceDir": "${workspaceFolder}"
}

With local variable support (preLaunchRebuild rebuilds your pod with debug=true before each session):

{
  "type": "fantom",
  "request": "launch",
  "name": "Launch FIN (full debug)",
  "fanExe": "/path/to/intelliplant/bin/fin",
  "mainClass": "",
  "launcherArgs": ["-noAuth"],
  "sourceDir": "${workspaceFolder}",
  "preLaunchRebuild": true
}

preLaunchRebuild runs fan build.fan in sourceDir using the shadow FAN_HOME (which has debug=true) so the rebuilt pod contains LocalVariableTable bytecode attributes. Without this, only method parameters are visible in the Variables panel — local variables like room11, room12 are invisible. Set it to true the first time you debug and whenever you do a clean build; afterwards you can set it back to false to skip the overhead.

Step 3. Press F5

The Debug Console shows the exact command being run:

[Fantom Debug] Launching: /path/to/fin -noAuth

If you see unexpected extra tokens after your arguments, check the mainClass field — it must be "" for fin.

Step 4. Set breakpoints and click the gutter in any `.fan` file

VS Code tip: If gutter clicks don't work, add to settings.json:
"debug.allowBreakpointsEverywhere": true

Step 5. Stop debugging

Press the Stop button (red square) or Shift+F5. The launched process and all its children are terminated immediately via SIGKILL on Linux/macOS.

Launch configuration reference

`launch`

Key	Type	Default	Description
`fanExe`	string	auto-detected	Path to `fan` or `fin`. Auto-filled from `fan.config.json` (`finPath` first, then `fanPath/bin/fan`)
`mainClass`	string	`""`	Fantom class to run, e.g. `myPod::Main`. Leave empty for `fin` — `fin` already embeds its entry point; passing an extra class name after launcher args confuses its argument parser.
`launcherArgs`	string[]	`[]`	Arguments inserted between the executable and `mainClass`, e.g. `["-noAuth"]` → `fin -noAuth`. These are passed to the launcher script itself, before the Fantom pod name.
`args`	string[]	`[]`	Arguments appended after `mainClass` — passed to the Fantom program's `main()` method.
`sourceDir`	string	`${workspaceFolder}`	Root directory searched for `.fan` source files (used for source ↔ JVM class mapping).
`debugPort`	number	`5005`	Preferred JDWP port. If the port is already in use the adapter automatically picks a free ephemeral port.
`noDebug`	boolean	`false`	Launch without attaching the debugger (plain run).
`preLaunchRebuild`	boolean	`false`	Run `fan build.fan` in `sourceDir` before launching, using a shadow `FAN_HOME` with `debug=true`. This makes local variables (beyond method parameters) visible in the debugger. Only needed after a clean/release build.

`attach`

Key	Type	Default	Description
`host`	string	`localhost`	Hostname or IP of the running JVM
`port`	number	`5005`	JDWP port to connect to
`sourceDir`	string	`${workspaceFolder}`	Root directory searched for `.fan` source files

Source file mapping

When the JVM reports a stopped location it provides only the short filename (e.g. MyService.fan) and the JVM class name (e.g. fan.myPod.MyService). The adapter searches sourceDir in this order:

<sourceDir>/<podName>/fan/<File.fan> — standard Fantom pod layout
<sourceDir>/<podName>/<File.fan>
<sourceDir>/fan/<File.fan> — single-pod workspace
Full recursive walk under sourceDir — fallback for non-standard layouts

Set sourceDir to the root of your source tree. For a multi-pod workspace this is typically ${workspaceFolder}.

Building the debug adapter from source

The debug adapter JAR is pre-built and bundled at vscode-fantom/bundled-debug/fantom-debug-adapter.jar. To rebuild (requires JDK 11+, no Maven needed):

cd vscode-fantom
pnpm run build-debug-adapter
# or directly:
bash debug-adapter/build.sh

This downloads Gson, compiles all Java source files, and packages a self-contained fat JAR.

🐛 Troubleshooting

Symptom	What to check
"Extension idle" on startup	The workspace has no `build.fan`, no `.fan` files, and no `fan.config.json`. Add one.
"fanPath not configured and FAN_HOME is not set"	Set `fanPath` in `fan.config.json` or export `FAN_HOME` in your shell profile.
"fan executable not found"	Make sure `bin/fan` (or `bin/fan.bat` on Windows) exists in your Fantom directory.
No completions / wrong completions	Check that your file is inside the `srcDirs` listed in `build.fan`. Files outside srcDirs are not indexed.
Build errors not appearing	Set `fanTargetBuild` in `fan.config.json` to match your build target (e.g. `"compile"`).
Diagnostics too slow / too fast	Tune `debounceTime` in `fan.config.json` (default 2000 ms).
LSP server crashes	Open the Fantom Language Server output channel in VSCode and look for error messages. Enable `fantom.trace.server: "verbose"` for full protocol traces.
Debug adapter JAR not found	Run `bash vscode-fantom/debug-adapter/build.sh` to build it. Requires JDK 11+.
Breakpoints never hit	Confirm JDWP is enabled on the JVM (see Java configuration above). Check the port matches between `config.props` and `launch.json`.
Variables show `<not found>`	The variable is out of scope or the frame is no longer active. Check the Call Stack panel to select the correct frame.
Local variables not shown (only method params)	Rebuild your pod with `debug=true`: either set `"preLaunchRebuild": true` in `launch.json`, or manually build with `debug=true` in `etc/sys/config.props`.
Program hangs on startup	You left `suspend=y` in `java.options`. Change to `suspend=n` or remove the line.
`bind failed: Address already in use`	Port 5005 is taken by the running FIN server's own JDWP listener. In launch mode the adapter picks a free port automatically. In attach mode use a different port. Do not set `JAVA_TOOL_OPTIONS` when using launch mode.
`-noAuth` or other launcher flags ignored	Set `"mainClass": ""` in `launch.json` when using `fin`. The `fin` script already embeds its entry point; a non-empty `mainClass` is appended after your flags and confuses FIN's argument parser.
FIN process keeps running after Stop	Ensure you are using the latest JAR (rebuild with `bash debug-adapter/build.sh`). Launched sessions are always force-killed on disconnect.

🤝 Contributing

Contributions are welcome! The LSP server lives in src/fan/ and is written in Fantom. The VSCode extension glue code is in vscode-fantom/src/.

# Run Fantom tests
fan build.fan test

# Run extension grammar tests
cd vscode-fantom && pnpm run test:grammar

📜 License

Academic Free License 3.0

👻 Happy coding with Fantom!

Fantom Language Server

Andrea Giusti
