Crab Modules for Code Highlighter

🎥 Demo

*Click to watch the demo video*

What Does This Extension Do?

After using Crab Code Highlighter to mark different parts of your code with colors (like Model Layer, Service Layer, API Routes, etc.), this extension exports those highlighted sections into separate folder structures.

Each color/layer gets its own folder with the extracted code preserving the original file structure and line positions - making it easy to understand where each piece came from.

Features

Export by Architecture Layer

• Multi-select export - Choose multiple layers at once (Ctrl/Cmd+click)
• One layer, one folder - Each color exports to exported_layer/<LayerName>/
• Preserves file structure - Maintains your original directory hierarchy
• Positional accuracy - Code stays in its original line positions with proper indentation

Smart Code Extraction

• Empty line preservation - Non-highlighted lines remain empty to show context
• Character-level precision - Respects exact start/end positions of highlights
• Multi-range support - Handles multiple highlights in the same file
• Automatic cleanup - Overwrites previous exports to keep folders fresh

Integration with Code Highlighter

• Reads highlights.json - Works automatically with Code Highlighter's save format
• Metadata support - Uses color names and descriptions from your highlights
• Workspace-aware - Finds highlights.json in your workspace root automatically

Getting Started

Prerequisites

You must have Crab Code Highlighter installed and have highlighted some code first.

Installation

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X or Cmd+Shift+X)
3. Search for "Modules From Highlighter Code"
4. Click Install
5. Make sure you have a highlights.json file in your workspace

Quick Start

1. Highlight your code using Code Highlighter (mark different layers/modules with colors)
2. Right-click anywhere in your editor
3. Select "Export Modules from Color"
4. Choose one or more layers to export (Ctrl/Cmd+click for multiple)
5. Press Enter to confirm
6. Check the output in exported_layer/<LayerName>/ folders

How to Use

Basic Workflow

1. Use Code Highlighter to mark code sections
   ├─ Model Layer (blue)
   ├─ Service Layer (orange)
   └─ API Routes (cyan)

2. Right-click → "Export Modules from Color"

3. Select layers to export:
   ☑ Model Layer
   ☑ Service Layer
   ☐ API Routes

4. Result:
   exported_layer/
   ├── Model_Layer/
   │   ├── src/models/user.js
   │   └── src/models/product.js
   └── Service_Layer/
       ├── src/services/auth.js
       └── src/services/payment.js

Multi-Select Export

You can export multiple layers at once:

1. Right-click → "Export Modules from Color"
2. Ctrl+click (Windows/Linux) or Cmd+click (Mac) to select multiple layers
3. Press Enter
4. Each layer will be exported to its own folder

What Gets Exported?

Example Input (src/auth/login.js):

// Line 1: import express from 'express';
// Line 2: import jwt from 'jsonwebtoken';
// Line 3:
// Line 4: function validateUser(email, password) {  // ← Highlighted (lines 4-8)
// Line 5:   const user = findUser(email);           // ← Highlighted
// Line 6:   return bcrypt.compare(password, user);  // ← Highlighted
// Line 7: }                                          // ← Highlighted
// Line 8:
// Line 9: export default validateUser;

Example Output (exported_layer/Authentication/src/auth/login.js):

function validateUser(email, password) {
  const user = findUser(email);
  return bcrypt.compare(password, user);
}

Notice how:

• Lines 1-3 are empty (not highlighted)
• Lines 4-7 contain the highlighted code in their original positions
• Lines 8-9 are empty (not highlighted)
• Indentation and character positions are preserved

Example Use Cases

Refactoring Monolith to Microservices

1. Highlight different service boundaries with colors
2. Export each service layer separately
3. Use exported code as foundation for new microservices

Extracting Shared Libraries

1. Highlight utility functions and helpers
2. Export to see all utilities in one place
3. Create a shared package from exported code

Code Documentation

1. Highlight specific architectural patterns
2. Export for educational purposes
3. Show team members what code belongs to each layer

Architecture Analysis

1. Highlight by architectural layer (MVC, Clean Architecture)
2. Export to see code distribution
3. Identify overly large or small layers

Output Structure

After export, you'll find:

your-workspace/
├── src/
│   ├── models/
│   ├── services/
│   └── controllers/
├── highlights.json           ← Generated by Code Highlighter
└── exported_layer/           ← Generated by this extension
    ├── Model_Layer/
    │   └── src/
    │       └── models/
    │           ├── user.js   ← Only highlighted code from user.js
    │           └── product.js
    ├── Service_Layer/
    │   └── src/
    │       └── services/
    │           └── auth.js
    └── API_Routes/
        └── src/
            └── controllers/
                └── api.js

Each exported folder:

• Mirrors your original structure
• Contains only highlighted code for that layer
• Preserves line numbers and indentation
• Can be committed to Git for team collaboration

Requirements

• VS Code version: 1.60.0 or higher
• Code Highlighter extension must be installed
• highlights.json must exist in workspace root
• Workspace/folder must be open (not single files)

Commands

Access via Command Palette (Ctrl+Shift+P or Cmd+Shift+P):

Context Menu

• Right-click in editor → "Export Modules from Color"

Keyboard Shortcuts

Add custom keybindings in your keybindings.json:

[
  {
    "key": "ctrl+alt+e",
    "command": "highlight-modules-viewer.showColorPicker"
  }
]

How It Works

1. Reading highlights.json

The extension reads the highlights.json file created by Code Highlighter:

{
  "files": {
    "src/auth/login.js": {
      "#3B82F650": [
        {
          "startLine": 4,
          "startCharacter": 0,
          "endLine": 7,
          "endCharacter": 1,
          "name": "Authentication",
          "description": "Auth logic, JWT, sessions"
        }
      ]
    }
  }
}

2. Processing Each File

For each file with highlights:

1. Creates an array matching the original file's line count
2. Fills in only the lines that are highlighted
3. Preserves exact character positions and indentation
4. Leaves non-highlighted lines empty

3. Creating Output Structure

1. Creates exported_layer/<LayerName>/ folder
2. Recreates the original directory structure inside
3. Writes files with extracted code
4. Overwrites previous exports (always fresh)

Known Issues

• Large files: Files with 10,000+ lines may take a few seconds to process
• Overlapping highlights: If multiple colors overlap on the same lines, later colors may overwrite earlier ones in exports
• Memory: Very large workspaces (1000+ files) may require extra memory
• Line shifts: If you edit code after highlighting but before exporting, line positions may be incorrect

Troubleshooting

"No highlights.json file found"

• Make sure Code Highlighter is installed
• Highlight some code first (it creates the file)
• Check your workspace root folder

"No highlight colors found"

• Use Code Highlighter to add some highlights
• Make sure the highlights.json file isn't empty
• Try reloading the window (Ctrl+Shift+P → "Reload Window")

Exported code is in wrong position

• This happens if you edited the file after highlighting
• Re-highlight the sections with Code Highlighter
• Then export again

Multiple layers export to same folder

• Each layer should get its own folder: exported_layer/<LayerName>/
• If they're merging, check that your layer names are different
• Special characters in layer names are replaced with underscores

Related Extension

Crab Code Highlighter
The companion extension that creates the highlights this extension exports. You need both for the full workflow!

Support the Project

If Modules From Highlighter Code helps your workflow, consider supporting its development:

Other Ways to Support:

• ⭐ Star both repositories - Code Highlighter & Modules From Highlighter Code
• 🐛 Report bugs - Help make it better
• 💡 Suggest features - Share your workflow ideas
• 📢 Share with your team - Spread the workflow
• ✍️ Write a review - Share on VS Code Marketplace

Your support helps dedicate time to new features and improvements!

Contributing

Found a bug or have a feature request?
Open an issue: Crab Modules for Code Highlighter Issues
/issues)

Want to contribute code?

1. Fork the repository
2. Create your feature branch (git checkout -b feature/AmazingFeature)
3. Commit your changes (git commit -m 'Add some AmazingFeature')
4. Push to the branch (git push origin feature/AmazingFeature)
5. Open a Pull Request

Release Notes

1.0.0 (Initial Release)

• ✨ Multi-layer export with multi-select
• 📁 Preserves original file structure
• 📍 Positional code extraction with line preservation
• 🔄 Automatic export folder cleanup
• 🎨 Full integration with Code Highlighter
• 🚀 Fast processing for large codebases

Contact

Developer: Emanuel Conte (AmazingCrab)
Email: amazingcrab@proton.me Ko-fi: ko-fi.com/amazingcrab

Questions about the workflow or want to collaborate? Reach out!

Links

• Repository: github.com/AmazingCrab/Extension-for-VsCode-Crab-Modules-for-Code-Highlighter
• Crab Code Highlighter: github.com/AmazingCrab/Extension-for-VsCode-Crab-Code-Highlighter
• Report Issues: GitHub Issues
• Support: Ko-fi

License

This project is licensed under the MIT License - see the LICENSE.md file for details.

MIT License - Copyright (c) 2025 Emanuel Conte (AmazingCrab)
