GDSII Preview

A high-performance GDSII/OASIS file viewer (offer Visual Studio Code extension + Desktop app), featuring multi-thread processing and GPU-accelerated rendering for handling large integrated circuit layouts.

Features

• High-Performance Rendering: View large GDSII layouts smoothly directly within VS Code.

• GDSII & OASIS Support: Open both .gds/.gdsii and .oas files, including full OASIS files support (using CBLOCK compression and/or strict mode) with Rust backend.

• Multi-Engine Support: Choose between WebGL (GPU), Canvas (CPU), or SVG rendering (deprecated, only support legacy Python backend).

• Text Rendering: Displays text labels and annotations within the GDSII layout, with customizable colors.

• Port Visualization:

  • Visualizes ports with orientation arrows and labels.
  • Supports kfactory metadata and standard layer-based ports.
  • Customizable visibility, color, size, and arrow scale.

• Layer Management: Toggle layer visibility, customize layer colors, and reorder layers via drag-and-drop.

• Negative View: Inspect mask polarities with negative view mode.

• Cell Navigation: Inspect different cells within the GDS library.

• Interactive Controls:

  • Floating Toolbar: Draggable toolbar for common view operations.
  • Transformations: Flip (Horizontal/Vertical) and Rotate (CW/CCW) the layout.
  • Pan & Zoom: Smooth navigation with mouse and scroll wheel.
  • Fit View: Quickly center and fit the layout to the screen.
  • Measure Tool:
    • Toggle with the toolbar M button or the M key.
    • Click to create measurements; each pair of clicks adds a new measurement record.
    • Snaps to nearby polygon vertices/edges (vertex snap has higher priority).
    • Hold Shift while placing the 2nd point to constrain to horizontal/vertical.
    • Press Esc to clear the current in-progress measurement.

• Configuration Panel: Quick access to rendering settings and parameters directly within the viewer.

• Performance Optimizations:

  • Parallel Triangulation: Uses Rust backend to parse and process geometry off the frontend thread.
  • Binary Streaming:
    • Python engine: Streams geometry via Base64-encoded binary chunks.
    • Rust engine: Streams geometry as raw binary frames over a local WebSocket (served by the extension) to avoid Base64 overhead.
  • Incremental Rendering: Streams data for all modes (WebGL, Canvas) to provide immediate visual feedback.
  • Viewport Culling: Only renders what is visible on screen.
  • Viewport Streaming (WebGL + Rust): Requests geometry on-demand for the current camera viewport (with a small neighborhood padding) to keep huge layouts responsive and avoid client-side memory blowups.
  • Viewport Polygon Streaming (Measure Snapping, WebGL + Rust): When the Measure tool is enabled, the viewer can request viewport-bounded polygons for snapping even when render viewport streaming is disabled.
  • Dynamic Level of Detail (LOD): Automatically reduces detail during fast interactions to maintain high frame rates.
  • Instanced Rendering: Uses hardware instancing (ANGLE_instanced_arrays) to efficiently render hierarchical designs with thousands of repeated cells.
  • Backend Triangulation (Rust/WebGL): WebGL triangles can be generated in the Rust backend and streamed directly to the webview.

• Advanced Analysis:

  • Net Tracing: Double-click any object to highlight all physically connected polygons (Net Tracing). Works across instances and hierarchy.
    • Hold Shift while double-clicking to union-merge into the existing highlight set.
  • Point Pick (Right-Click): Right-click to highlight the polygon under the cursor (single polygon only; no connected-object expansion).
    • Hold Shift while right-clicking to toggle highlight (remove if already highlighted, else add).
  • Box Select (Right-Drag): Right-click and drag to draw a selection box; polygons fully contained in the box will be highlighted.
    • Hold Shift while box-selecting to union-merge into the existing highlight set.
  • Layer Soloing: Double-click a layer in the sidebar to instantly isolate it.
  • Layer Tutti: Double-click Layer Control in the sidebar to show all layers.
  • Copy to KLayout: After highlighting polygons, press Cmd/Ctrl+C to copy a KLayout paste payload (includes layer info). To paste as shapes, install the macro in klayout/paste_gds_preview_polygons.py.

  Install the KLayout paste macro

  This enables “paste from clipboard into the layout window” for the polygons copied from this viewer.

  1. Open KLayout.
  2. Open the Macro Development IDE:
  • Tools → Macro Development...
  3. Load the macro file:
  • In Macro Development, choose Python → Import file
  • Select klayout/paste_gds_preview_polygons.py
  • Make sure it is enabled.
  4. Add a keyboard shortcut:
  • klayout → Preferences...
  • Application → Customize Menu
  • Find the macro entry you just loaded (it may appear under the Main Menu section), and add a shortcut.
  • Recommended shortcut: Ctrl+Shift+V.

  After that, in the KLayout layout window:

  • Use this viewer: highlight polygons → Cmd/Ctrl+C
  • In KLayout: press your shortcut (e.g. Ctrl+Shift+V) to paste as shapes (polygons will be placed onto their original layers).

Rendering Engines

This extension provides three rendering pipelines to suit different needs:

1. WebGL (Default & Recommended)

• Technology: GPU-accelerated rendering using WebGL.
• Pros: Extremely smooth Pan/Zoom performance ("Silky Smooth"). Handles millions of polygons with ease. Supports Instanced Rendering for hierarchical designs.
• Cons: Partial support for Viewport Culling when using instanced rendering.
• Best For: Large, complex layouts (1GB+), hierarchical designs.

2. Canvas

• Technology: HTML5 Canvas 2D Context (CPU-based).
• Pros: Fast initial load. Good compatibility. Full support for Viewport Culling and LOD.
• Cons: Performance drops significantly with high polygon counts.
• Best For: Small cells (~1MB), debugging.

3. SVG (Deprecated, only in legacy Python backend)

• Technology: Scalable Vector Graphics (DOM-based).
• Pros: Perfect vector fidelity at any zoom level. Easy to inspect via DOM tools.
• Cons: High memory usage for very large files (though improved with streaming).
• Best For: Medium-sized layouts (~10MB), high-quality static screenshots.

Extension Settings

This extension contributes the following settings:

• gdsPreview.renderingEngine: Select the rendering backend.

  • webgl (Default): GPU acceleration.
  • canvas: Standard HTML5 Canvas.
  • svg: Legacy vector rendering.

• gdsPreview.useInstancing: (Default: true)

  • Enables hardware instancing for WebGL mode.
  • Greatly improves performance for hierarchical designs (e.g., memory arrays).
  • If disabled, the design is flattened before rendering (legacy behavior).

• gdsPreview.fastModeThreshold: (Default: 10)

  • Controls the aggressiveness of the Dynamic LOD optimization (Only use for Canvas engine).
  • Specifies the minimum pixel size for polygons to be rendered during interaction (panning/zooming).
  • Higher values (e.g., 20, 50) improve interaction fluidity but temporarily reduce detail.

• gdsPreview.labelFontSize: (Default: 12)

  • Font size for text labels in pixels.

• gdsPreview.portFontSize: (Default: 12)

  • Font size for port labels in pixels.

• gdsPreview.portArrowScale: (Default: 1.0)

  • Scale factor for port arrows.

• gdsPreview.maxWorkers: (Default: -1)

  • Controls parallelism.
  • Python engine: Number of Web Workers.
  • Rust engine: Number of Rayon worker threads for triangulation and search.
  • Set to -1 to use all available CPU cores.

• gdsPreview.chunkSize: (Default: 2000)

  • Number of polygons per data chunk streamed from Python.
  • Adjusting this can help balance memory usage and throughput.

• gdsPreview.flowControlStep: (Default: 5)

  • Number of chunks to send before waiting for a signal from the frontend.
  • Helps prevent the extension host from being overwhelmed by data.
  • Set to -1 to disable flow control.
  • Note: This setting applies to legacy stdout/Base64 streaming. In Rust TCP/WebSocket binary streaming mode, stdin is reserved for JSON commands and stdin-based flow control is disabled.

• gdsPreview.viewportStreaming: (Default: false)

  • (WebGL + Rust) Streams geometry on-demand based on the current viewport instead of streaming the entire design.
  • Best for extremely large layouts where full streaming would be too slow or memory-heavy.

• gdsPreview.viewportPaddingFactor: (Default: 0.25)

  • Extra neighborhood margin around the current viewport.
  • Interpreted as a fraction of max(viewportWidth, viewportHeight) in world units.
  • Higher values reduce visible pop-in while panning, at the cost of fetching more geometry per request.

• gdsPreview.viewportDebounceMs: (Default: 80)

  • Debounce interval (ms) for viewport geometry requests during pan/zoom.
  • Higher values reduce request frequency (less CPU/network churn) but increase latency.

• gdsPreview.maxSteps: (Default: 5000)

  • The max steps for connected objects finding algorithm.
  • Adjusting this can help cut off heavy finding problems.

• gdsPreview.pythonPath: (Default: python)

  • Path to the Python executable used for parsing GDSII files.
  • Required when engineType is set to python.
  • Useful if you have multiple Python installations or use a virtual environment.

• gdsPreview.engineType: (Default: rust)

  • Choose which backend engine to use for GDS file processing.
  • rust (Default): Experimental Rust-based backend with faster performance.
  • python: Original Python-based backend using gdstk.
  • The Rust backend provides better performance but is still experimental. Switch to Python if you encounter issues.

Backend Engines

This extension supports two backend engines for processing GDSII/OASIS files:

Rust Backend (Default & Recommended)

• Status: Experimental, actively developed
• Performance: Significantly faster than Python for large files
• Compatibility: Cross-platform (Windows, Linux, macOS) with automatic binary downloads
• Dependencies: None (standalone binary)
• Formats: Supports both GDSII and OASIS (including CBLOCK-compressed OASIS)
• Best For: Large files, production use (once stable)

Rust Streaming Notes

• In Rust + WebGL mode, geometry may be streamed as binary frames over a local WebSocket.
• When streaming in true incremental mode, the total number of chunks may be unknown up-front (the UI will show per-chunk progress without a total).
• When using TCP/WebSocket streaming, stdin is reserved for JSON commands (e.g. viewport updates, search). Stdin-based flow-control is disabled in this mode.

Python Backend

• Status: Stable, original implementation
• Performance: Good for most files
• Dependencies: Requires Python 3 and gdstk library
• Best For: Maximum compatibility, debugging, or if Rust backend encounters issues

To switch between backends, change the gdsPreview.engineType setting in VS Code:

1. Open VS Code Settings (File → Preferences → Settings)
2. Search for gdsPreview.engineType
3. Select either rust or python
4. Close and reopen the GDS file to apply the new backend

Desktop Application

A standalone desktop version of GDS Preview is available for Windows, Linux, and macOS.

macOS Installation Note

The macOS desktop application is not notarized by Apple. If you encounter a "damaged" error when trying to open it:

"GDSII Preview" is damaged and can’t be opened. You should move it to the Trash.

Please run the following command in your terminal to clear the quarantine attribute:

xattr -cr "/Applications/GDSII Preview.app"

(Replace /Applications/GDSII Preview.app with the actual path to the app if you installed it elsewhere).

Requirements

For Rust Backend (Default)

• No external dependencies required
  • The Rust backend is a standalone binary that will be automatically downloaded for your platform.

For Python Backend

• Python 3: Required when using the Python backend (gdsPreview.engineType: python).
• gdstk: Python library for GDSII manipulation.
  • The extension will attempt to automatically install gdstk if it is missing (pip install gdstk).
  • You can also install it manually using pip install gdstk.
• klayout: Python library (klayout.db) required for advanced port extraction (e.g., kfactory metadata).
  • The extension will attempt to automatically install missing dependencies.
  • You can also install them manually using pip install gdstk klayout.

Known Issues

• WebGL mode requires a graphics-capable environment.
• Very large files may take a moment to parse before the first render appears.
