Alamo Engine Tools - Empire at War Edit

Editor support for Star Wars: Empire at War and Forces of Corruption mod development.

• XML and Lua: completions, hover documentation, cross-file diagnostics, navigation, rename
• Story tooling: campaign navigator, story graph, cross-language symbols
• Localisation editor
• Model preview
• Lua debugger

Preview release. Not every feature is complete; behaviour may change between versions. Report problems on the issue tracker.

Requirements

• Visual Studio Code 1.107 or later
• Windows 11 (x64); Windows 10 is unsupported (end of mainstream support October 2025)
• The PG.StarWarsGame.LSP server binary, self-contained; no .NET runtime needed

Getting started

1. Download the server

From the Releases page:

• aet-eaw-edit-x.x.x.vsix - the extension, for manual installs
• PG.StarWarsGame.LSP.Server-x.x.x-win-x64.zip - the language server; extract to a permanent folder, e.g. C:\tools\aet-lsp\

2. Configure the extension

Activation: an open XML or Lua file, or a .pgproj in the workspace. A missing or mismatched server binary is reported with a link to the matching release.

3. Create a mod project file

.pgproj at the root of the mod workspace:

{
  "_type": "aetswg.ModProject",
  "_typeVersion": "aetswg-1.0.0",
  "name": "My Mod",
  "directories": {
    "xml":     ["data/xml"],
    "scripts": ["data/scripts"],
    "art":     ["data/art"],
    "audio":   ["data/audio"]
  },
  "localisation": {
    "type": "CSV",
    "directory": "data/text"
  },
  "projectReferences": []
}

• _type and _typeVersion - the file's format, written and maintained by the extension. A file without them loads as format 1.0.0; a newer format than the extension understands is refused.
• Paths are relative to the .pgproj.
• projectReferences - other .pgproj files whose symbols the mod inherits, e.g. a base game project.
• localisation.type - CSV, DAT, XML or NLS.
• icons (optional) - megaTexture (atlas pair without extension, e.g. data/art/textures/mt_commandbar) and sourceRoots (loose icon folders). Omitted: engine convention.

Upgrading from 0.1.x

Required .pgproj change. Localisation moved from directories to its own node:

   "directories": {
     "xml": ["data/xml"],
     "scripts": ["data/scripts"],
     "art": ["data/art"],
-    "audio": ["data/audio"],
-    "text": ["data/text"],
-    "textResourceType": "Csv"
+    "audio": ["data/audio"]
   },
+  "localisation": {
+    "type": "CSV",
+    "directory": "data/text"
+  },
   "projectReferences": []

A .pgproj in the old shape fails to load with a notification naming this fix.

One .pgproj per workspace. More than one fails to start with a notification listing them all; remove the extras or open the subfolder holding the one you want.

Clear cached indexes. Delete .aetswg next to every .pgproj and %USERPROFILE%\.aetswg\, then run EaWEdit: Restart LSP Server. Both are rebuilt automatically.

XML features

Indexes the full EaW/FoC object graph across the workspace.

• Completions - enum values and named objects from the whole workspace
• Hover - type, description and valid values for tags, enum values and references
• Diagnostics
  • Unknown references
  • Unknown or misspelled tags, with a suggestion
  • Unnamed objects, missing required tags
  • Type mismatches, malformed values, deprecated fields
  • Duplicate declarations
• Engine rules - about 150 checks taken from the game's parser and error messages
  • Numeric ranges
  • Tags required or forbidden together
  • Comparisons between tags of one object
  • Variant-inheritance rules
• Go to definition - F12 / Ctrl+Click, across files
• Find all references - Shift+F12
• Rename - F2, workspace-wide
• Code actions - quick fixes, including creating a missing localisation key
• Code lens - reference counts above every named object
• Auto-close tags - on > (needs editor.formatOnType)
• Linked editing - opening and closing tag renamed together (needs editor.linkedEditing)
• Variant inheritance - Show Effective Object opens the merged XML of a Variant_Of_Existing_Type object

Lua features

Scripts under the declared scripts directories are indexed and checked.

• Completion
• Go to definition
• Rename, including XML objects referenced from Lua
• Code lenses, inlay hints, quick fixes
• Hover and diagnostics (work in progress)

Lua debugger

Work in progress, off by default. Flag: aet-eaw-edit.features.lua.debugger. Requires a debug build of the game with its Lua debug server running; retail builds have none.

With thanks to EvilBobTheBob (@andrewfullard), of Phoenix Rising and EaWX, whose eaw-lua-debugger documented the game's Lua debug server protocol. This debugger was built against that description.

Debug type Empire at War Lua in Run and Debug:

• Breakpoints in Lua files under the project's script directories
• Attach to a running game, or launch it with the mod chain
• Call stack, locals in the Variables view, watches and hovers on plain names
• Debug Console running Lua in the selected or stopped script
• Lua Scripts view: every running script instance with its coroutine threads; break in a script or a thread (the game cannot start a script on request)

F5 in a Lua file attaches with the settings below. launch.json:

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "eaw-lua",
      "request": "attach",
      "name": "Attach to Empire at War (Lua)"
    },
    {
      "type": "eaw-lua",
      "request": "launch",
      "name": "Launch Empire at War (Lua)",
      "program": "${config:aet-eaw-edit.game.executable}"
    }
  ]
}

Launch and the mod chain

• One MODPATH= per project layer: mod first, dependencies after
• The game reads a mod folder as-is, so each layer needs:
  • Its declared directories under its Data/ folder
  • No space in its path
• A layer that does not comply is refused with the reason
• modPaths overrides the chain
• A build step for other layouts is planned (#144)

Lua Scripts view

• Refresh reloads the list
• Expanding a script fetches its threads
• Break actions are greyed out, with the reason in the tooltip, while a script is stopped or a break is already waiting

Limits of the game's debug server, reported rather than hidden:

• Breakpoint conditions, hit counts and log messages are never evaluated; such breakpoints are reported as not set
• The whole game freezes while a script is stopped
• Pause takes effect at the next Lua line of the selected script, or of any attached script
• Locals are the names found in scope at the stopped line
  • Upvalues resolve to the global of the same name
  • Numbers are reported as integers
• Tables show as table: 0x... without children unless aet-eaw-edit.game.unsafeTableExpansion is on
  • The game is reported to crash on member text of 255 bytes or more

Suppressing diagnostics

Every diagnostic carries a stable id aetswg-<group>-<number> (e.g. aetswg-004-0001), shown in the Problems panel's Code column.

Quick fixes

Ctrl+. on a problem offers four scopes, narrowest first, none preselected:

• Suppress ... for this line
• Suppress ... for this <Unit> / function / chapter - only with an enclosing declaration
• Suppress ... in this file
• Suppress ... across the project

Writing directives by hand

A directive may share a longer comment. A scope with no target (an -object directive outside any object, a trailing directive) covers its own line only.

Project-wide suppressions live in .aetswg/suppressions.json, written by the across the project quick fix. Commit that file.

Lists, wildcards, and reasons

Several ids per directive, comma-separated; a note after reason:::

<!-- aetswg:suppress aetswg-010-0002, aetswg-010-0003 reason:: deliberate shadow, cleared with the art team -->

* in place of the number silences a group, e.g. aetswg-004-* for every asset-file check:

Groups classify the problem, not the language: aetswg-001-* covers XML and Lua alike.

When a directive is wrong

• aetswg-013-0001 - an entry that is not an id or wildcard (typo, or missing leading zeros: aetswg-4-1 for aetswg-004-0001)
• aetswg-013-0002 - a directive naming no diagnostic

Only the bad entry is rejected; the rest of the list applies. Silence these with aetswg-013-*.

<Override> is not a suppression

<!-- <Override Name="..."/> --> declares intended shadowing of a lower layer, a claim the server checks. Unaffected by suppression.

Dialog quick fixes require aet-eaw-edit.features.dialog.codeActions; the rest of suppression is always on.

Story mode

Campaigns are followed from CampaignFiles.xml through plot manifests to the Story_*.xml thread files and understood as one graph. Opt-in and in development; see the story flags under feature flags.

• Campaign Editor view
  • Campaigns, factions, galactic plot threads, the faction's battles in play order with their own plot files and the script their manifest attaches beneath them, and the faction's attached Lua scripts
  • Suspended threads marked
  • Click opens the file; a battle opens its graph
• Story graph - one panel per campaign faction at the galactic level, and one per battle
  • Auto-laid-out event flow with AND/OR junctions and cross-file portals
  • Battles as sub-graphs: the galactic graph shows each tactical mission as one portal that opens the battle's own panel; the battle graph shows the galactic events that link it in and listen for its outcome as portals back, each opening the galactic panel on that event. In Simulation a pick on the portal selects the battle's decision beside the dock instead - fight, auto-resolve, won or lost - and the portal's arrow opens the battle's graph into Simulation. The command palette lists the battles after their faction
  • Node colour by lifecycle: inactive, waiting, armed, fired, disabled
  • Unreachable events dimmed; schema-untested types dashed
  • Filters: name, branch, lifecycle, plot state, the incoming or outgoing chain of one event - inside the panel's scope; the chain runs through a battle's portal
  • Engine links (dash-dot): the links the game makes that no prerequisite writes - a speech or movie to the listener that waits for it to end, a tutorial dialog to the listener for its Continue button, a battle to the galactic listeners for its outcome and for the summary dialog closing. Drawn so a sequence the game plays in order reads in order; never a prerequisite
  • Thread lanes on the galactic graph (Empire at War's acts); disabled inside a battle, which is one plot
• Params by name - every event and reward slot carries a label from the schema ("Planets", "Flash id", "Required result"); the description with its legend and ranges is the tooltip, and a missing-param warning quotes the same name after the slot
• Colour key - flyout keying node, border and edge styles, including per-branch hues on zoomed-out nodes
• Editing (Edit mode)
  • Drag a prerequisite between events
  • Drop event and reward types from the palette
  • Edit names, params, branch, perpetual and dialog in place
  • Staged and applied on save as one workspace/applyEdit; minimal edits; inserted tags in the engine's order
• Simulation (Simulation mode, flag tools.storySimulator)
  • The campaign runs forward in 1 s ticks by the engine's own event rules: push-based arming, campaign-wide trigger rewards, resets, disables, timers from arming, flag comparisons with the engine's defaults, speech and movie completions owed to the next tick
  • The world is a fact table seeded from the campaign XML - planets and owners, units, tech, credits - written only by rewards and by the author; nothing moves, builds or fights on its own
  • Every trigger the game would decide is a decision for the author: capture a planet, build or destroy a unit, win or lose a battle, send a script event, or assume the trigger met; pickers list what fits the facts first and accept any name
  • Battles run as their own session, as the game plays them: the galactic simulation arms the galactic listeners only. Entering a battle - from its portal, its row in the dock, or the decision that waits on it - opens its panel into Simulation on its own clock, seeded with the galaxy's flags and world, and the galaxy stands still until it resolves. Won or lost, from either panel: the battle's own listeners fire, the flags it wrote cross into the galaxy, and the galactic outcome listeners fire. A rewind replays the outcome as one step without replaying the battle
  • A Continue_Tutorial listener is a decision only while a tutorial dialog shows: the dialog's Continue button is what raises it, a TUTORIAL_DIALOG reward puts the dialog up and continuing closes it. A flag poll that already holds is the clock's work, not a wait: the story is not waiting for input while a chain behind a flag write is still landing
  • Rule out: a decision the author knows will not come in this run (the defeat listener of a battle to be won, say) leaves the list from its flyout. The listener stays armed, as in the game; the Ruled out group at the end of the decisions reverses the call, and the listener firing after all clears it
  • A linked battle waits for its choice, as the game's pending-battle panel does: a LINK_TACTICAL reward makes the battle pending and holds gameplay time - the story keeps running (pushes, flag polls, scripts, generic and GUI events), only STORY_ELAPSED timers stand still. The decision sits on the battle's portal: Fight opens the battle's panel straight into its session, Auto-resolve leaves won or lost and the flag picks to you. A FORCE_CLICK_GUI on the left choice button fights by itself, as the tutorial does, and on the right one auto-resolves. The battle_end_closed listener is the battle's to raise, not a decision, while one is pending or running; a loss that links the same mission again is a new attempt
  • Campaign scripts run as their PGStateMachine: a fired event enters the state, its OnEnter thread sleeps and sends Story_Event ids back into the graph, drawn as state nodes and links
  • Dock header: the tick and what stopped the clock; content: decisions, world, flags, scripts, each row opening beside the dock; foot: the transport - restart, one tick back, play, one tick, run until the story reaches a new decision, a breakpoint or nothing more can happen - with a pace of pulse, step or a custom rate. The clock is never held back by open decisions: a real campaign has hundreds of armed listeners from tick 0
  • Canvas: the flow along the edges, fire counts, gate meters on armed timers and flag checks, breakpoint marks; lenses for the path taken, the flow tints and the script states
  • Trace panel: every transition with its tick, node, cause and source; filter by text or t12 for one tick; copy
  • Breakpoints on any event and on every clock or flag gate; rewind to any tick replays the same answers
• Large campaigns - lightweight overview when zoomed out, real nodes only for the visible part; 1000+ events stay responsive
• Campaign diagnostics
  • Dangling or cyclic prerequisites
  • Duplicate event names
  • Prerequisites, reset and disable targets the engine cannot see because they live in another plot file
  • Two events of one name in one plot file
  • Events that can never fire
  • Suspended plots nothing activates
  • Problems bar can follow the branch filter; jumping to a hidden problem lifts it
• Cross-language symbols
  • Event names, flags and AI-notification ids indexed across XML and Lua
  • Go to definition from Prereq tokens and STORY_AI_NOTIFICATION ids to the Lua Story_Event("...") call
  • F2 renames across threads and scripts
• Dialog scripts (.txt scripts declared in the .pgproj)
  • Diagnostics
  • Inlay hints with the localisation text of TEXT and TITLE lines
  • Go to definition on speech, movie and sound arguments

Dependency and base-game files are read-only. Node positions, events and junctions, portals and script states alike, persist per campaign faction in .aetswg/story-layout.json.

Model preview

Flag: aet-eaw-edit.features.tools.modelPreview (on by default).

• Alamo Model Preview editor for .alo models and .ala animations; the file only, no XML
• Preview Assembled Unit (command and GameObject code lens) - the unit as the game builds it
  • Hardpoints on their attachment bones
  • Movable turrets
  • Firing arcs
  • Team colour
• Model lens
  • Model tree with per-part visibility
  • LOD and ALT levels
  • Skeleton, cameras, info inspector
  • Scene and light settings
• Animation lens
  • Clip library by family, action and take
  • The game's loop rule: idle repeats, death does not
  • Transport, playback speed
• Gameplay lens
  • Attacker weapons and abilities against the unit
  • Shields and hardpoint health
  • Destroy and repair hardpoints, with damage smoke and death clone
  • Damage log naming the armour type per hit
• Particles - effects, groups and emitters of a particle system
• Saved shots - captures kept in a set
• Handoff - Open in AloViewer and Open in Particle Editor via aet-eaw-edit.tools.aloViewerExecutable and aet-eaw-edit.tools.particleEditorExecutable
• Shaders - Set Up Base Shader Sources fetches Petroglyph's published shader sources into aet-eaw-edit.shaders.directory; never redistributed
• Game models - require aet-eaw-edit.lsp.source.baseGameDirectory and, for Forces of Corruption, expansionDirectory
• Energy pool - behind aet-eaw-edit.features.preview.energyPool, off on purpose: the engine implements it, the shipped game disables it
• Not covered - sounds and animation SFX maps; AloViewer remains the tool for those

Encyclopedia preview

Flag: aet-eaw-edit.features.tools.encyclopedia (on by default). Read-only.

• Preview Encyclopedia Popup (command and GameObject code lens) - the in-game tooltip card
  • Icon, name, class line
  • Encyclopedia_Text wrapped as the game wraps it
  • Ship names from the game's tables
  • Faction switch
• Language - aet-eaw-edit.lsp.localisation.language (the game's language, not the extension's)
• Icons - from the mega texture
  • Game icons baked into the baseline
  • A project's own mt_commandbar (.pgproj icons) replaces them wholesale
  • Missing everywhere: error
  • In sources but not in the mega texture: warning to rebuild

Localisation editor

Flag: aet-eaw-edit.features.tools.localisation. Localisation Editor activity bar view, files grouped into Text files and Credits files; one grid tab per file, splittable side by side.

• Editing - staged edits, count on Save, one all-or-nothing write; refused if the file changed on disk
• Validate - without writing; duplicate and empty keys are errors in text files, expected in credits files
• Rows - right-click menu: add and delete; reorder on credits files
• Add language - from the game's language list, for formats that hold more than one
• Fill language - from another language or from the game's own translations
• Inherited rows - hidden by default, Inherited toggle shows them; Reset to inherited value on overridden rows
• Filter - plain text, wildcard (*, ?) or regex; scoped to keys, one language or everything
• Columns - language columns chosen from the header gear; empty languages hidden at first
• Export to DAT and Convert to another format - from the file's context menu; conversion keeps the original
• New project - initialise from the EaW + FoC baseline, or import existing files

Saves rewrite changed rows only; untouched rows keep quoting, comments and line endings.

Credits files

Ordered lists that may repeat a key. Rows are addressed by position, so duplicates, spacer rows and order survive editing.

• Line kinds, offered as tiles to drag into the table:
  • HEADER - label
  • CENTER - name
  • [TBL] - blank spacer
• Open Credits Preview to the Side and Play Credits Crawl Full Screen play the staged rows as the game does

Detection: engine naming (credits*), or in the .pgproj:

"localisation": {
  "type": "CSV",
  "directory": "data/text",
  "credits": {
    // "convention" (default), "explicit" (only the files listed), or "none"
    "detection": "convention",
    "files": ["rolls.csv"]
  }
}

One format per project: a CSV project's credits file is a .csv. "type": "DAT" projects edit compiled .dat files directly (language from the file name, sort order preserved). Set Localisation Project Format changes the format from the editor.

Commands

Command Palette (Ctrl+Shift+P). Commands of a flagged feature are greyed out until the flag is on.

Flag column: the feature-flag id without its common prefix.

Settings reference

Language server

Game installation and external tools

Never searched for; used only once set.

Schema

The EaW/FoC XML schema: the newest compatible release, resolved on server start and cached per release; a local copy for offline or pinned use.

Baseline

Snapshot of all vanilla EaW and FoC objects and localisation keys, downloaded once to %USERPROFILE%\.pg-swg-lsp\baselines\ and refreshed on new versions. Powers reference validation and the Inherited toggle.

Development

Localisation editor

Lua debugger

Read only with aet-eaw-edit.features.lua.debugger on; a launch.json attribute overrides the setting of the same meaning.

Diagnostics

Encyclopedia preview

The game sizes the popup's glyphs from the display it runs on, and wraps its body text by character count rather than by measured width - so the card's proportions follow the screen it is drawn for.

Story simulation

Feature flags

Every feature has a flag. Work-in-progress features default to off. A flag the language server reads restarts it on change; editor-side flags apply at once.

XML:

Lua:

Story mode:

Story dialog (.txt files under directories.storyDialog only):

Tools:

What this extension downloads

Three data sources; nothing else is sent or received. No telemetry.

Troubleshooting

No diagnostics. aet-eaw-edit.lsp.enabled must be true and aet-eaw-edit.lsp.executable must point to PG.StarWarsGame.LSP.Server.exe; then EaWEdit: Restart LSP Server.

"LSP server failed to start". Windows may have blocked the downloaded executable: Properties > Unblock on PG.StarWarsGame.LSP.Server.exe, then restart the server. Otherwise Show Output in the notification.

Version mismatch. Server and extension must match; download the matching server from the releases page.

Features work in some files only. Only directories listed in the .pgproj are indexed; add the paths to directories.xml or directories.scripts.

"Found multiple .pgproj files under ...". One .pgproj per workspace root: remove the extras or open the subfolder, then restart the server.

"'directories.text'/'directories.textResourceType' were removed". Pre-0.2.0 .pgproj; see Upgrading from 0.1.x.

Localisation views missing. aet-eaw-edit.features.tools.localisation = true; the server restarts on the change.

A command or code action is missing. Its feature flag is off; see the Flag column of the commands table.

"The Lua debugger is disabled". aet-eaw-edit.features.lua.debugger = true. The debug type is always registered so launch.json validates; sessions start only with the flag on.

"The game did not answer on 127.0.0.1:1234 within 60 s". Debug build with luadebug run in its console required; retail builds never answer. A second game instance listens on 1235: set aet-eaw-edit.game.luaDebugPort or port. Remote machine: allow UDP to that port.

Breakpoint: "The file is under none of the configured script roots". The file is outside every project layer's script directories; move it, or add its root to sourceRoots.

Launch refused: layer not runnable. Declared directories under Data/ and no space in the path, or pass the folders via modPaths. See Lua debugger.

Raw server output. aet-eaw-edit.lsp.debug.traceServer = messages; EaWEdit output channel.

No diagnostics at all, for any file. aet-eaw-edit.lsp.debug.logLevel = Debug, then restart the server and read aetswg-*.log in the workspace root: it records whether XML document sync was registered and whether each didOpen reached the handler. At the default level neither line is written.

Acknowledgements

EvilBobTheBob (@andrewfullard), of Phoenix Rising and EaWX, for eaw-lua-debugger - the Python client that documented the game's Lua debug server protocol. The Lua debugger here was built against that description.

Issues

AlamoEngine-Tools/pg-starwarsgame-lsp/issues
