AiLang for Visual Studio Code

Visual Studio Code language support for AiLang .aos, .aiproj, and AiSVG .aisvg files.

This extension is intentionally a thin editor adapter:

• syntax highlighting through TextMate grammars
• bracket/comment/editor configuration
• Explorer file nesting for AiSVG code-behind files
• snippets for common AiLang and AiSVG node forms
• future commands that call the AiLang CLI for check/format/run

It must not define AiLang or AiSVG semantics. Semantic authority remains in AiLang/AiVectra and the normative specs in the main repositories:

• SPEC/IL.md
• SPEC/EVAL.md
• SPEC/VALIDATION.md
• SPEC/AISVG.md

Features

Current scaffold:

• .aos and .aiproj file association
• .aisvg file association for AiSVG view documents
• *.aisvg.aos code-behind files remain AiLang/AOS files because they end in .aos
• VS Code Explorer nests *.aisvg.aos under the matching *.aisvg file
• highlighting for core AiLang node kinds from the current IL spec
• highlighting for common AiSVG node kinds such as AiSVG, Group, Path, Rect, Circle, LinearGradient, and Stop
• highlighting for XML-like SVG tags and attributes in .aisvg files
• nested AiLang/AOS highlighting inside {{ ... }} regions in AiSVG files
• highlighting for common attributes such as name, value, target, path, package, sdk, params, async, fill, stroke, viewBox, d, transform, and gradient stop attributes
• highlighting for strings, numbers, booleans, null, comments, dotted syscall/call targets, SVG dimensions, and color literals
• language configuration for brackets, comments, surrounding pairs, and folding markers
• snippets for Program, Import, Export, Let, Fn, Call, If, Return, Project, Include, plus common AiSVG document/node forms

AiSVG file pairing

AiSVG uses a view/code-behind pairing:

MainView.aisvg
└── MainView.aisvg.aos

• MainView.aisvg is the AiSVG view file.
• MainView.aisvg.aos is the AiLang/AOS code-behind file for that view.
• The VS Code Explorer should display the code-behind file nested under the matching view file.
• The code-behind file is not a separate AiSVG document type; it is AiLang/AOS attached to an AiSVG view.

The extension contributes this default file nesting rule:

{
  "explorer.fileNesting.patterns": {
    "*.aisvg": "${capture}.aisvg.aos"
  }
}

AiSVG embedded expressions

AiSVG files may embed AiLang/AOS expressions using {{ ... }}. The extension delegates those embedded regions to the existing AiLang TextMate grammar for editor highlighting only.

Example:

AiSVG(width=800 height=600 viewBox="0 0 800 600") {
	Defs {
		LinearGradient(id="sky" x1="0%" y1="0%" x2="0%" y2="100%") {
			Stop(offset="0%" stopColor="#8fd3ff")
			Stop(offset="100%" stopColor="#ffffff")
		}
	}

	Rect(x=0 y=0 width=800 height=600 fill="url(#sky)")

	Text(x=40 y=80 fontSize=32 fill="#1f2937") {
		{{ Call(target=weather.currentSummary) }}
	}
}

Architecture rule

The extension may recognize tokens for editor presentation, but validation, formatting, evaluation, and diagnostics must come from the AiLang toolchain.

Good future behavior:

VS Code command -> ailang check -> Problems panel
VS Code command -> ailang fmt -> replace document text
VS Code command -> ailang run -> terminal output

Bad behavior:

VS Code extension implements semantic validation itself
VS Code extension decides module resolution rules
VS Code extension formats using separate semantic rules

Development

Install dependencies:

npm install

Package locally:

npx vsce package

Run the extension from VS Code:

1. Open this repository in VS Code.
2. Press F5 to launch an Extension Development Host.
3. Open a .aos or .aisvg file.

File types

• .aos — AiLang source files
• .aiproj — AiLang project manifest files
• .aisvg — AiSVG view documents
• .aisvg.aos — AiLang/AOS code-behind files for matching .aisvg view documents

License

MIT
