Structura

Next-generation code exploration for VS Code
Visualize architecture as interactive, real-time graphs that adapt as you work

⚡ Quick Start • Installation • Features • Usage • Shortcuts • Contributing

New here? → Quick Start Guide — from install to exploring your codebase in 2 minutes.

Note: if extension is not working please click `alt+shift+p` then from options search for `Developer: reload window` and click on it

Why Structura?

Understanding complex codebases shouldn't require mental gymnastics. Structura eliminates the cognitive overhead of navigating large projects by transforming your code into an interactive graph that reveals relationships, dependencies, and architecture at a glance.

The Problem

Mental overhead: Developers spend hours tracing dependencies manually
Lost context: Switching between files breaks your mental model
Hidden complexity: Circular dependencies and dead code lurk unseen
Onboarding friction: New team members struggle to understand architecture

The Solution

Structura provides a living architectural view that updates in real-time as you navigate, combining the keyboard-first efficiency of Neovim with the visual clarity of modern graph interfaces.

Core Innovations

1. Semantic-First Architecture

Structura abstracts language-specific AST nodes into universal intents (imports, exports, definitions, calls), enabling true multi-language support and future AI integration.

JavaScript ImportDeclaration  ─┐
Python Import                  ├─→ "import" intent
Go import statement            ┘

This revolutionary approach not only helps humans understand code faster but also opens possibilities for LLM-powered code intelligence.

Structura uses a single VS Code shortcut to open the graph, then chord shortcuts (Ctrl+Alt+*) once the panel is focused:

Ctrl+Alt+G (Cmd+Alt+G on Mac) — Graph the active tab
Tab / Shift+Tab — Cycle through visible nodes
↑ ↓ ← → — Jump to nearest node in that direction
Ctrl+Alt+E — Expand selected node (depth 1)
Ctrl+Alt+U — Reveal who imports this node (reverse traversal)
Enter — Open selected file in editor
Esc — Deselect / close inspector panel

All shortcuts are also available through the right-click context menu.

3. Intelligent State Management

Structura optimizes for speed through:

Incremental exploration: Navigate through graph history with time-travel commands
Smart caching: Only re-parses changed files
Checkpoint system: State persists in .structura folder
Ignore patterns: Use .structuraignore for fine-grained control within vs code extention configuration

4. Documentation Integration (Planned)

One-to-one mapping between code files and documentation, with future support for:

Integration with documentation tools like CodeRabbit
Agentic AI auto-documentation
Inline doc display in graph tooltips

Features

Current (v0.1.0)

🔍 Automatic Code Analysis - Intelligent AST parsing for deep insights
📊 Interactive Graph Visualization - Pan, zoom, and explore with Cytoscape.js
🎯 Smart Navigation - Click nodes to see connections, double-click to open files
⚡ Real-Time Updates - Graph adapts as you navigate your codebase
⌨️ Keyboard-First - Neovim-inspired shortcuts for maximum productivity
🎨 Semantic Coloring - Nodes colored by intent (imports, exports, definitions, calls)
⚙️ Highly Configurable - Customize base directory, ignore patterns, and more
🚀 Performance Optimized - Handles large codebases efficiently

Supported Languages

✅ JavaScript (.js, .mjs, .cjs)
✅ TypeScript (.ts, .tsx)
✅ JSX (.jsx)
🔜 Python (coming soon)
🔜 Go, Rust, Java (contributors needed!)

Detected Relationships

ES6 imports: import X from 'Y'
CommonJS: require('X')
Dynamic imports: import('X')
Function/class definitions
Function calls and references

Installation

From VS Code Marketplace

Open VS Code
Press Ctrl+Shift+X to open Extensions
Search for "Structura"
Click Install

From Source

# Clone the repository
git clone https://github.com/yourusername/structura.git
cd structura

# Install dependencies and package
npm install
npm install -g vsce
npm run package

# Install the generated .vsix file
code --install-extension structura-0.1.0.vsix

Usage

Opening the Graph

Method 1: Click the Structura icon in the status bar (bottom right)

Method 2: Open Command Palette (Ctrl+Shift+P) and run:

Structura: Show Code Graph

Method 3: Use keyboard shortcut: Ctrl+Alt+G (Mac: Cmd+Alt+G)

Mouse Controls

Click a node → Highlight its connections
Double-click a node → Open the file in editor
Drag → Pan around the graph
Scroll → Zoom in/out

Keyboard Controls

Tab / Shift+Tab → Select next / previous node
↑ ↓ ← → → Jump to nearest node in that direction
Enter → Open selected file in editor
Space → Fit / centre the graph
Esc → Deselect / close node inspector
Ctrl+Alt+E → Expand selected node (depth 1)
Ctrl+Alt+D → Expand deep (depth 2)
Ctrl+Alt+U → Show who imports this node
Ctrl+Alt+F → Focus / zoom to selected node
Ctrl+Alt+P → Pin / unpin selected node
Ctrl+Alt+H → Hide selected node
Ctrl+Alt+[ → Time-travel back
Ctrl+Alt+] → Time-travel forward
1–9 → Show all nodes up to depth N
? → Toggle keyboard shortcut help

Graph Exploration Workflow

Start with current file: Open any file, then activate Structura
Explore dependencies: Click nodes to see what they import/call
Expand selectively: Right-click nodes to expand their connections
Filter as needed: Use the filter bar to focus on specific files or patterns
Navigate freely: Double-click any node to jump to that file

Advanced Features

Ctrl+Alt+[ — Go back in graph exploration history
Ctrl+Alt+] — Go forward in graph exploration history

Refreshing

Press Ctrl+Alt+G again at any time to destroy the current graph and rebuild it fresh from the active editor tab.

Configuration

VS Code Settings

Open Settings (Ctrl+,) and search for "Structura":

`structura.baseDirectory`

Base directory to analyze (relative to workspace root)

{
  "structura.baseDirectory": "./src"
}

`structura.ignorePatterns`

File/folder patterns to exclude from analysis

{
  "structura.ignorePatterns": [
    "node_modules",
    "dist",
    "build",
    ".git",
    "**/*.test.js",
    "**/*.spec.ts"
  ]
}

`structura.maxDepth`

Maximum depth for graph expansion (default: 3)

{
  "structura.maxDepth": 3
}

`structura.autoRefresh`

Automatically refresh graph when files change (default: true)

{
  "structura.autoRefresh": true
}

Keyboard Shortcuts

VS Code (global)

Shortcut	Action
`Ctrl+Alt+G` / `Cmd+Alt+G`	Graph the active editor tab

Shortcut	Action
`Tab`	Select next visible node
`Shift+Tab`	Select previous visible node
`↑` `↓` `←` `→`	Jump to nearest node in that direction
`Space`	Fit / centre entire graph
`Esc`	Deselect all / close node inspector

In-graph — Expansion

Shortcut	Action
`Ctrl+Alt+E`	Expand selected node (depth 1)
`Ctrl+Alt+D`	Expand deep (depth 2)
`Ctrl+Alt+U`	Reveal who imports this node
`1` – `9`	Show all nodes up to depth N

In-graph — Node Actions

Shortcut	Action
`Enter`	Open selected file in editor
`Ctrl+Alt+F`	Focus / zoom to selected node
`Ctrl+Alt+P`	Pin / unpin selected node
`Ctrl+Alt+H`	Hide selected node

In-graph — History

Shortcut	Action
`Ctrl+Alt+[`	Time-travel back
`Ctrl+Alt+]`	Time-travel forward

In-graph — Help

Shortcut	Action
`?`	Toggle keyboard shortcut overlay

Note: All in-graph shortcuts require the graph panel to have focus. Right-click any node for the same actions via context menu.

Architecture

High Level Architecture

Structura follows a layered architecture that separates concerns while enabling seamless language-agnostic code visualization.

Architectural Layers

Layer 1: VS Code Extension Layer (User Interface)

The presentation layer that interacts directly with developers through VS Code's extension API.

Directory Walker - Recursively discovers source files in workspace
Web View Panel - Renders interactive graph visualization using Cytoscape.js
File Watcher - Monitors file system changes for real-time updates
Command Handler - Processes VS Code commands and user interactions
Status Bar - Shows current parsing state and quick actions

Layer 2: Structura Engine (Core Processing Middleware)

The brain of the system implementing the Chain of Responsibility pattern through a configurable pipeline.

Middleware Pipeline:

File Reader → 2. Parser Selector → 3. AST Generator → 4. Graph Builder → 5. Weight Calculator → 6. State Persister

Key Subsystems:

Child Process Manager - Executes parsers in isolated processes
Normalization Pipeline - Normalize → Build → Weight → Persist
Graph Slice Generator - Creates focused subgraphs for visualization
Parser Registry - Manages language-specific parser implementations
Semantic Normalizer - Maps language AST to universal semantic nodes
Graph Builder - Constructs dependency graphs from semantic nodes
Graph Expander - Extracts context-relevant subgraphs using policies
State Storage - Manages graph persistence with checkpointing
Expansion Policies - Configurable rules for graph traversal

Layer 3: Language-Specific Parser Layer

Pluggable parsers that convert source code to abstract syntax trees (ASTs).

Current Support:

JavaScript Parser - Using @babel/parser
TypeScript Parser - Using TypeScript compiler API
Python Parser - Using Python's ast module via child process
[+more] - Extensible through plugin system

Execution Model:

Runs in child processes for isolation and crash protection
Can run in-memory for performance-critical scenarios
Language definitions configure semantic mapping and weights

Layer 4: Semantic Normalizer Foundation

The universal abstraction layer that makes Structura truly language-agnostic.

Core Components:

Expected AST Contract - Language-to-universal node mapping
Keyword Extractor - Identifies semantic keywords from code
Graph Slice Schema - Standardized representation for visualization
Language Definitions - Configurable mappings per language

Low Level Architecture

Structura implements Clean Architecture principles with a focus on SOLID design:

Core Domain Layer (Business Logic)

Graph Models - Graph, GraphNode, GraphEdge domain entities
Semantic Models - SemanticNode, SemanticIntent value objects
Expansion Policies - Business rules for graph traversal
Language Definitions - Domain-specific language configurations

Application Layer (Use Cases)

Processing Pipeline - Orchestrates the parse-normalize-build-weight-persist flow
Graph Operations - Expand, find paths, detect cycles, calculate weights
Parser Coordination - Manages parser execution and result aggregation

Interface Adapters (Ports & Adapters)

Parser Registry - Adapter for language-specific parsers
State Storage - Adapter for persistence (filesystem, memory, cloud)
Visualizer - Adapter for rendering engines (Cytoscape.js, D3.js)
Event System - Adapter for component communication

Infrastructure Layer (Frameworks & Drivers)

VS Code Extension API - Platform-specific integration
File System Access - OS-level file operations
Child Process Management - Process isolation and IPC
External Parser Libraries - Babel, TypeScript compiler, etc.

Key Architectural Patterns

Chain of Responsibility (Middleware Pipeline)

Each processing step (Handler) can process, modify, or pass along data, enabling flexible pipeline composition.

Ports & Adapters (Hexagonal Architecture)

Core business logic remains independent of external systems through defined interfaces.

Strategy Pattern (Language Parsers)

Interchangeable parser implementations following the ILanguageParser interface.

Observer Pattern (Real-time Updates)

File watchers and event listeners enable reactive architecture updates.

Factory Pattern (Component Creation)

Centralized creation of parsers, visualizers, and storage adapters.

Data Flow

VS Code Extension (UI)
        ↓
File Watcher + Directory Walker
        ↓
Parser Registry → Language Parser → AST Analysis
        ↓
Semantic Normalizer → Universal Semantic Nodes
        ↓
Graph Builder → Dependency Graph
        ↓
Weight Calculator → Weighted Graph
        ↓
State Storage ← → Graph Expander → Contextual Subgraph
        ↓
Visualizer (Cytoscape.js) → Interactive Visualization

Design Principles

SOLID Compliance - Each component has single responsibility, open for extension
Language Agnostic - Core works with any language through semantic normalization
Real-time Reactive - Updates propagate instantly as code changes
Performance First - Smart caching, incremental updates, parallel processing
Extensible Core - Plugin system for new languages, visualizers, and analyzers

Project Structure

structura/
├── src/
│   ├── core/
│   │   ├── Directory.ts
│   │   ├── FileWatcher.ts
│   │   ├── TSParser.ts
│   │   ├── Visitors.ts
│   │   ├── Walker.ts
│   ├── extension.ts
│   ├── utilities # source code utilties
│   ├── parsers/
│   │   ├── executor.ts               # ParserExecutor (spawns child processes)
│   │   ├── registry.ts               # ParserRegistry (manages parsers)
│   │   ├── contract.ts               # TypeScript interfaces for JSON contract
│   │   └── validator.ts              # Validates parser output
│   ├── graph/
│   │   ├── builder.ts
│   │   ├── expander.ts
│   │   └── weights.ts
│   ├── storage/
│   │   └── filesystem.ts
│   └── ui/
│       ├── panel.ts
│       └── visualizer.ts
│
├── parsers/                          # Native language parsers
│   │
│   ├── javascript/                   # JavaScript/TypeScript parser
│   │       └── parse                 # Executable entry point
│   │
│   ├── python/                       # Python parser
│   │     └── parse                 # Executable: #!/usr/bin/env python3
│   │
│   ├── go/                        # Go parser
│   │    └── parse                 # Compiled binary
│   │
│   ├── rust/                         # Rust parser
│   │    └── parse                 # Compiled binary
│   │
│   └── java/                         # Java parser
│         └── parse                 # Launch script
│
├── definitions/                      # Language semantic mappings
│   ├── javascript.json
│   ├── python.json
│   ├── go.json
│   ├── rust.json
│   └── java.json
│
├── test
│   ├── extension.test.ts
│   ├── unit # unit tests
│   ├── e2e # integration tests
├── scripts/
│   ├── build-parsers.sh              # Build all parsers
│   ├── test-parsers.sh               # Test all parsers
│   └── package-parsers.sh            # Package parsers for distribution
│
├── package.json                      # Extension manifest
├── tsconfig.json
└── README.md

Development

Prerequisites

Node.js v25.2.1 and npm
VS Code 1.80+

Setup

# Clone repository
git clone https://github.com/yourusername/structura.git
cd structura

# Install dependencies
npm install

# Open in VS Code
code .

Running the Extension

Press F5 to launch Extension Development Host
Open any project folder
Activate Structura via status bar or Command Palette

Building

# Compile TypeScript
npm run build

# Watch for changes
npm run watch

# Run tests
npm run test

# Package extension
npm run package

Contributing a Parser

To add support for a new language:

Create language definition in definitions/[language].json
Implement ILanguageParser interface
Register parser in ParserRegistry
Add tests

See CONTRIBUTING.md for detailed guidelines.

Roadmap

Phase 1: MVP (Current - v0.1.0)

[x] JavaScript/TypeScript parsing
[x] Interactive graph visualization
[x] Basic keyboard navigation
[x] Real-time file tracking
[x] State persistence

Phase 2: Intelligence (v0.2.0 - Q2 2025)

[ ] LLM-powered edge descriptions
[ ] Circular dependency detection
[ ] Dead code identification
[ ] Architecture anti-pattern warnings
[ ] Smart refactoring suggestions

Phase 3: Multi-Language (v0.3.0 - Q3 2025)

[ ] Python support
[ ] Go support
[ ] Rust support
[ ] Java support
[ ] Generic parser framework

Phase 4: Enhanced UX (v0.4.0 - Q4 2025)

[ ] Full Vim-style navigation
[ ] Advanced filtering
[ ] Graph export (PNG, SVG, Mermaid)
[ ] Custom themes
[ ] Share graph views

Phase 5: Documentation (v0.5.0 - Q1 2026)

[ ] File-to-doc mapping
[ ] Auto-generate docs from graph
[ ] JSDoc/docstring integration
[ ] Documentation coverage heatmap

Phase 6: Collaboration (v0.6.0 - Q2 2026)

[ ] Git integration
[ ] Team annotations
[ ] Code review mode
[ ] Shared graph exploration

Contributing

We welcome contributions! Structura is designed for both user and contributor joy.

Areas We Need Help

Parser Development: Add support for Python, Go, Rust, Java
Testing: Write tests for edge cases and real-world codebases
Documentation: Improve guides and examples
Performance: Optimize for larger codebases
UI/UX: Design improvements and new features

How to Contribute

Important : checkout Parsers

Fork the repository
Create a feature branch (git checkout -b feature/amazing-feature)
Make your changes
Add tests
Commit with clear messages (git commit -m 'Add Python parser')
Push to your fork (git push origin feature/amazing-feature)
Open a Pull Request

See CONTRIBUTING.md for detailed guidelines.

Technology Stack

Runtime: Node.js
Language: TypeScript
Extension API: VS Code Extension API
AST Parsing:
- JavaScript/TypeScript: @babel/parser, TypeScript Compiler API
- Python (planned): Python ast module via child process
Graph Theory: Cytoscape.js
UI: HTML, CSS, Webview API
Future: Tree-sitter for universal language support

Performance

Structura is optimized for speed and responsiveness:

Incremental parsing: Only re-parses changed files
Smart caching: Avoids redundant AST generation
Parallel processing: Utilizes multiple CPU cores
Lazy loading: On-demand graph expansion
Virtual rendering: Handles 10,000+ node graphs smoothly

Benchmarks (Target)

Parse 1,000-file codebase: < 30 seconds
Load graph visualization: < 1 second
Expand node: < 100ms
Switch files: < 50ms
Memory usage: < 200MB for 10,000 nodes

FAQ

Q: Does Structura work with monorepos?

A: Yes! Configure structura.baseDirectory to target specific packages, or use multiple instances.

Q: Can I use Structura with large codebases (10,000+ files)?

A: Yes, Structura uses smart caching and incremental parsing. Initial analysis may take a few minutes, but subsequent updates are fast.

Q: Does Structura require internet access?

A: No. Structura works entirely offline. LLM features (planned) are optional and require API keys.

Q: How does Structura compare to [other tool]?

A: Structura is unique in its semantic-first, language-agnostic approach and keyboard-first UX. Most tools are language-specific or mouse-dependent.

A: Export features (PNG, SVG, Mermaid) are planned for v0.4.0.

Q: Is there a CLI version?

A: Not yet, but it's on the roadmap for CI/CD integration and automated documentation.

Support

Issues: GitHub Issues
Discussions: GitHub Discussions
Email: support@structura.dev
Twitter: @StructuraDev

License

MIT License - see LICENSE for details.

Acknowledgments

Structura stands on the shoulders of giants:

Neovim - Keyboard-first philosophy
Cytoscape.js - Graph visualization
Babel - JavaScript parsing
VS Code - Extensibility platform
Tree-sitter - Future language support

Special thanks to all contributors who make Structura better every day.

Built with ❤️ by developers, for developers
_{Making code exploration delightful, one graph at a time}

Get Started • Star on GitHub • Follow Updates

Structura - Code Graph Exploration & Analyzation

Ahmed Rakan
