Agmen Stream Inspector for Redis

A free and open-source Visual Studio Code extension for inspecting, searching, monitoring, exporting, and replaying Redis Streams directly from your editor.

Every feature is available to every user. The extension does not require an account, activation key, subscription, or external entitlement service.

Features

Search and filter

• Full-text search across stream messages with field-level filtering
• JSON path traversal for nested payloads using dot notation, such as data.user.name
• Case-insensitive matching with optional exact-match mode
• Find the most recent N messages from selected streams
• Ascending and descending scan modes with configurable page size
• Search across multiple streams simultaneously

Advanced conditional search

• Combine multiple field conditions with AND/OR logic
• Equals, Not Equals, Contains, and Exists operators
• Nested groups with independent combinators for complex queries
• Apply the basic field match first, then the advanced group with AND semantics
• Built-in examples and help in the filter editor

Real-time monitoring

• Watch streams in real time with a configurable polling interval
• Display new messages automatically as they arrive
• Retain a bounded result buffer in Find and Watch modes to avoid unbounded host/webview memory growth
• Efficient polling through Redis XREAD

Connection management

• Multiple connection profiles with Dev, Test, and Prod labels
• Color-coded environments
• SSH tunnels with password or private-key authentication
• SSH trust-on-first-use confirmation with persisted SHA256:... host fingerprints and mismatch blocking
• Redis and SSH passwords stored through VS Code SecretStorage
• Connection testing before save
• Keyboard-accessible profile reordering

Message tools

• Pretty-printed JSON with syntax highlighting
• Find within a message with Ctrl+F
• Automatic decoding of JSON strings containing embedded JSON
• Resizable results and message-viewer panels
• JSON and CSV export
• Replay individual messages or all results to another Redis server with XADD
• Confirmation before large replay operations

Getting started

Install a VSIX

1. Build or download the .vsix file.
2. In VS Code, run Extensions: Install from VSIX... from the Command Palette.
3. Select the VSIX and reload VS Code when prompted.

Open the inspector

• Click Agmen Stream Inspector in the Activity Bar.
• Press Ctrl+Shift+R, or Cmd+Shift+R on macOS.
• Run Agmen Stream Inspector: Open from the Command Palette.

Connect and search

1. Select + Add in the Connection section.
2. Enter a name and Redis URL, such as redis://localhost:6379.
3. Optionally configure authentication or an SSH tunnel.
4. If you use SSH, test the tunnel. On first use the extension will show the bastion fingerprint and ask whether to trust and save it.
5. Save the connection.
6. Fetch the available streams, select one or more, configure the search, and select Find or Watch.

Commands

Settings

Connection URL format

The extension accepts standard Redis URLs:

redis://[[username:]password@]host[:port][/db]
rediss://[[username:]password@]host[:port][/db]

The default Redis port is 6379. Use rediss:// for TLS-encrypted connections. For simple endpoints, use host, host:port, [ipv6], or [ipv6]:port. Ambiguous forms such as host:6379:6380 are rejected.

For a server accessible only through SSH, enable SSH Tunnel in the connection editor, enter the bastion details, and choose password or private-key authentication. On first use the extension shows the presented bastion host fingerprint, asks whether to trust it, and saves the accepted SHA256:... fingerprint to the profile. Future connections fail closed if the fingerprint changes.

Workspace trust

The extension is disabled in untrusted workspaces. It opens outbound Redis and SSH connections and can replay messages to target Redis servers, so it does not run in VS Code restricted mode.

Development

Prerequisites

• Node.js 20 or later
• VS Code 1.85 or later

Setup and verification

git clone https://github.com/cristianofx/agmen-stream-inspector-vscode-oss.git
cd agmen-stream-inspector-vscode-oss
npm ci
npm run lint
npm run typecheck
npm run typecheck:webview
npm run test:unit
xvfb-run -a npm run test:vscode   # Linux
npm run build
npm audit

Press F5 in VS Code to open an Extension Development Host. To produce an installable extension package, run:

npm run package

Tagged releases also generate a CycloneDX SBOM and SHA256SUMS.txt through .github/workflows/release.yml.

Project structure

src/
  extension.ts              # Extension activation and commands
  core/
    models/                 # Search, filter, connection, and result models
    services/               # Redis search, watch, discovery, and SSH services
  providers/                # Extension-host webview providers
  services/                 # Connection profile storage
  webview/                  # Browser-side UI and message protocol
test/
  suite/                    # Mocha unit tests

Technology

• TypeScript
• ioredis
• ssh2
• esbuild
• VS Code Webview API and SecretStorage
• Mocha

Security and governance

• See SECURITY.md for private vulnerability reporting.
• See CONTRIBUTING.md for the contributor workflow and release checklist.
• See SUPPORT.md for support expectations.

License

Agmen Stream Inspector is available under the MIT License. See the LICENSE file included with the source and extension package.
