ASFX Toolkit

ASFX Toolkit is an open-source VS Code / Cursor extension that supercharges your Salesforce development workflow. It bundles org-aware Apex & SOQL IntelliSense, log management & debugging, org management, source tracking & deployment, data operations, and API exploration — all without leaving the editor, and all driven by the Salesforce CLI you already have.

Works on VS Code 1.80+ and Cursor. Activates automatically in any folder containing an sfdx-project.json; outside SFDX projects it stays completely inert.

Features

🧠 Apex & SOQL IntelliSense

A built-in, JVM-free language server (pure Node, shipped inside the extension) that adds org-aware IntelliSense for Apex and SOQL. It runs alongside the official Salesforce Apex extension and only adds what that engine can't: live schema from your connected org.

SOQL — in .soql files, inline [SELECT … ] queries in Apex, and Database.query('…') strings:

• Object completion after FROM; field completion in SELECT / WHERE / ORDER BY, with type badges.
• Relationship traversal — Account.Owner.Name resolves through __r lookups.
• Child-relationship subqueries — (SELECT … FROM Contacts).
• Type-aware WHERE operators and picklist value completion.
• Rich hover — fields show type, label, length, help text and picklist values; objects show label, key prefix, custom flag, CRUD flags, field/relationship counts and the admin Description (via the Tooling API).

Apex — additive to the Salesforce Apex extension:

• Member completion via declared types — acc. → Account fields, myService. → your class's members.
• new constructor completion — suggests the type being assigned first (Account a = new |).
• SObject type-name completion in declarations, casts, generics and instanceof.
• Outline and syntax diagnostics, go-to-definition (in-file and cross-file), and signature help.
• Find references — every usage of a symbol. A local is confined to the method that declares it, so two methods reusing a name never bleed into each other.
• Annotations and snippets — completion after @ (@IsTest, @AuraEnabled(cacheable=true), @InvocableMethod, HttpGet/HttpPost, …), collection and statement snippets (sysdebug, soqlfor, testmethod, batchable/queueable/schedulable, trigger, asserts, DML), and standard exceptions inside catch (…).
• Code actions — surround with try/catch, System.assert* → Assert.*, generate a constructor, implement a standard interface, generate a test class.
• Inline lint — SOQL/DML in loops, hardcoded record Ids, leftover System.debug, missing sharing declaration.
• Org-aware extras — SOQL bind variables, picklist values, Trigger.new/Trigger.old typing, SOQL date literals, aggregate functions and FIELDS(), plus workspace symbols and polymorphic-aware lookup typing.

Org-aware extras:

• Namespace-optional matching — when your sfdx-project.json defines a namespace, typing Widget__c matches ns__Widget__c (the namespace stays in the inserted code; matching is what's optional).
• Per-document org resolution — nested / multi-package projects each resolve their own default org, so billing/force-app/... uses billing's org.
• Result weighting — auxiliary objects (*History, *Share, *Feed, *ChangeEvent) and standard audit fields sink below the business objects/fields you actually use.
• Schema stubs generated in the background for go-to-definition and to ground AI tooling; refreshed on org switch, pull, and Refresh Metadata.
• Self-healing — if the Salesforce Apex Language Server gets stuck, it's restarted (bounded), with a clear notification if it keeps failing.

LWC → Apex:

• Cmd+click an imported Apex method lands on the class and method itself, not a generated stub.
• Typings come from your @AuraEnabled signatures with real parameter and return types, and are regenerated as those change (lwcApexTypings.autoGenerate).
• Custom Apex types become TypeScript interfaces rather than any, inner classes included.
• A CodeLens on every @AuraEnabled method shows how many LWC components import it; click to peek those call sites.
• Completion and go-to-definition for the other @salesforce/* imports too — label, resourceUrl, messageChannel — and a usage CodeLens on <c-…> component references.
• If a component's IntelliSense is broken — c/* imports, subdirectories, Salesforce modules — Tools → Repair → Repair LWC jsconfig fixes each lwc folder's jsconfig.json. Nothing under Repair ever runs on its own.

Schema is read from your default org via the REST describe API (auth resolved from sf org display); the language server itself stays credential-free. Everything is gated to SFDX projects and individually toggleable — see Settings.

🧰 ASFX Workbench

A unified bottom panel (sidebar Tools → ASFX Workbench) that brings Apex execution, ad-hoc SOQL, and debug logs together, each on its own tab, with a shared org selector and trace indicator.

• Execute — run anonymous Apex with org-aware completion; the live debug log and governor limits render side-by-side as it runs. Execute with Cmd/Ctrl+Enter, open the result in an editor, or replay from history.
• SOQL — fire a quick query against the selected org and browse results in a table; export, or jump to the full SOQL Builder & Editor.
• Logs — browse the org's debug logs in a syntax-highlighted viewer that colour-codes USER_DEBUG, execution markers, and limit usage.

🔍 Log Management & Filtering

• Log Viewer: List, download, and open Salesforce debug logs from the sidebar. Works with the Salesforce default extensions' log locations.
• Delete All Logs: Remove logs from the org (Tooling API with CLI fallback) and clear the local cache in one action.
• Smart Filtering:
  • Debug Filter (Cmd+D / Ctrl+D): show only USER_DEBUG statements, errors, and exceptions.
  • SOQL & DML Filter: show only queries (SOQL_EXECUTE) and DML operations.
• Visual Feedback: active-state filter icons in the editor title bar; loading indicators for large logs.
• Live Polling: automatically poll for new debug logs in the background.
• Trace Flags: one-click Quick Trace for the current user; view, manage and delete existing trace flags.

⚡ Apex & SOQL Tools

• Execute Anonymous: Run Apex from the editor (.apex files or selections) or the ASFX Workbench Execute tab, with live debug log, governor limits, and history.
• Rerun Last: Re-run the last executed Apex without re-selecting code.
• SOQL Builder & Editor (ASFXT: Open SOQL Builder & Editor): build and run SOQL with object/field completion and an optional visual builder, view results in an interactive table, edit records inline, save changes back to Salesforce, or discard edits. Export results to CSV / JSON; query history and saved queries are kept per workspace.
• Apex CodeLens: Run a specific test method or an entire test class straight from the code.
• Apex Snippets: Save, organize, run, edit, and delete reusable Apex snippets from the sidebar and overview panel.

☁️ Org Management

• Org Explorer: Manage all connected orgs, scratch orgs, and Dev Hubs from a dedicated view.
• Quick Actions: open in browser, set as default org / Dev Hub, copy username, rename alias, generate scratch-org password, delete/logout.
• Scratch Org Wizard: interactive Create Scratch Org, or Quick Scratch with sensible defaults in one click.

📦 Package Explorer (Dev Hub)

ASFXT: Package Explorer — a second-generation (2GP) package control panel for your Dev Hub (also opens from the inline package action on a Dev Hub in the Org Explorer).

• Browse every 2GP package → its versions, newest first: version number, subscriber (04t) and package (0Ho) ids as click-to-copy chips, released/beta status, created date, and package aliases from sfdx-project.json. A searchable package combobox, a version filter, and Released-only / Latest-per-package toggles keep large packages manageable; results are cached so switching or reopening is instant.
• Install links & commands — per version, copy the Prod or Sandbox install URL, the sf package install command, or a paste-ready sfdx-project.json dependency snippet. Password-protected packages prompt for an installation key.
• Dependencies view — a package's declared dependencies (from sfdx-project.json) resolved to their concrete ids.
• Actions (native confirm + progress): Install into any org, Promote to released, Update or Delete a version, Rename a package. Optional per-version code-coverage column (opt-in, since it's a heavier query).
• Installed in org tab — list packages installed in any org (ASFXT: List Installed Packages, also on org context menus) with upgrade badges when your Dev Hub has a newer released version, plus one-click Upgrade / Uninstall.
• Version report — dependencies + ancestry on demand; export a package's versions to Markdown or CSV.

🛠️ Development Tools

• Source Operations: smart Push (diff deploy for source-tracked orgs, sequential package deploy otherwise), Push (Force), Pull, contextual Deploy/Retrieve for the open file, and Reset Source Tracking.
• Flexible Metadata Deploy Flow (ASFXT: Deploy Metadata):
  • Select paths/files, pick a test level, target any org — the panel always deploys exactly the components you picked (source-tracking conflicts are overridden).
  • Deployment History: every deploy persisted with status, duration, test results and timestamp — browse, search and re-run in one click.
  • Named Test Suites: save groups of test classes with a preset and reload them instantly.
  • Pre-Deploy Quality Gate: scans Apex before deploy for leftover System.debug() (warning), hardcoded record IDs (error), SOQL/DML in loops (error), and TODO/FIXME (info) — review, then abort or deploy anyway.
  • Test Coverage Display: post-deploy per-class coverage, colour-coded (≥75% green / ≥50% amber / <50% red) with overall average.
  • Auto file detection via a debounced FileSystemWatcher; Deployment Presets for reusable configs.
• Test Runner: run local tests easily.
• Ignore Helpers: add files/folders to .gitignore or .forceignore from explorer context actions.
• Custom Editors: friendly UIs for Permission Sets (.permissionset-meta.xml) and Scratch Org Definitions (project-scratch-def.json).
• Explorer tidy: ASFXT: Toggle Hide Apex -meta.xml Files hides/shows the *.cls-meta.xml / *.trigger-meta.xml sidecar files via files.exclude (workspace-scoped, persisted).

✅ Apex Test Coverage

Org-wide Apex coverage surfaced three ways, all sharing one auto-refreshing store — it updates after a coverage test run (this extension's Run Apex Tests with Coverage profile or the Salesforce extension's, detected via a watcher on .sfdx/tools/testresults/), on panel refresh, and on focus.

• Explorer badges — each .cls/.trigger shows its coverage % (toggle with ASFXT: Toggle Apex Coverage % Badge); the exact covered/total lines are always on hover.
• Coverage panel (ASFXT: Apex Coverage) — overall org %, a classes-below-75% count, and a worst-first, searchable table with a below-threshold filter; click a row to open the class. Includes Refresh and Clear results (deletes local .sfdx/tools/testresults and resets the display).
• Line highlights (ASFXT: Toggle Apex Coverage Line Highlights) — opt-in, persisted covered/uncovered line decorations in the open class that stay live while enabled.

🗺️ Object & Process Visualizers

Two graphs for understanding an org, both under Tools.

ASFXT: Object Visualizer — an ERD of the objects you pick and their relationships, with fields inline. Filter, search, and pull in the objects that live in your SFDX project in one click.

ASFXT: Process Visualizer — what actually happens when a record changes, in order.

• Pick the objects first, then build, so the graph stays readable instead of rendering the whole org.
• An execution-order spine: before triggers → validation rules → after triggers → flows → workflow rules, with each automation on the phase it runs in.
• Full call chains — Contact → before update → (trigger → ClassA → ClassB → field is set). Apex bodies are scanned for calls and field writes; test classes are left out.
• Automations sharing a phase are grouped in a labelled box with a single edge onward, instead of a fan of crossing lines.
• Scheduled and autolaunched flows link to the objects they operate on with a dotted edge.
• Labelled edges, collision-free layout, re-layout on filter, search that navigates to each hit, and right-click to open any component in the org.

🔄 Data Migration Wizard

ASFXT: Data Migration Wizard — move entire Salesforce object trees from one connected org to another, with no CSV and no manual ID management.

1. Source & Target — choose what the run produces (Org → Org, or an Apex script / CSV / JSON file), pick orgs, write a root SOQL query, and name it or load a saved preset.
2. Object Tree — child relationships are described lazily into a checkable tree (unbounded depth); per object, choose fields and an external ID / upsert key. Fields the target org can't accept, and ones it assigns itself (Owner, Record Type, audit), are listed as excluded with the reason rather than silently dropped.
3. Overview — lookups that can't be preserved are reported before you start, with the objects to add to fix them. Then run, with per-object progress.

Referential integrity is preserved by remapping every lookup to the record the run created — a source Id never reaches the target. Self-references (Account.ParentId) are re-linked after insert. Objects are ordered topologically, so junction objects land after both parents.

Undo. An upsert runs as query-then-write, so the rows it overwrites are read first and can be restored. The results table lists every record created and every record overwritten — old value beside new, Ids linking into their own orgs — each with a checkbox, so you can revert the whole run or just part of it. Reverting restores overwritten rows and deletes created ones, children before parents. Opt into Revert on failure to have that happen automatically when any record fails.

Presets save per project (config/asfx/migrations, committable) or globally. Loading one re-describes against the org, so fields, relationships and upsert keys are real — anything the org no longer has is reported rather than assumed.

Export instead of migrate. The same selection and the same rules can produce a file. The Apex output is an Anonymous Apex script that resolves lookups through the parent's external Id where there is one, upserts on that key so it is safe to re-run, and splits into parts that each fit the Execute Anonymous window.

Large datasets use REST pagination (no CLI row limits) with WHERE IN chunked at 500; writes go through SObject Collections in batches of 200 with partial success. Writing into a production org is confirmed first.

📂 Data Export / Import

ASFXT: Data Export / Import — a full data panel:

• Export any SOQL query to CSV or JSON in your workspace, openable in one click.
• Import a CSV with preview and auto-guessed SObject: Insert, Update (needs Id), Upsert (single external-ID field or a 2–3 column composite key resolved client-side), or Delete by Id. Live progress, per-record errors, and a results summary.

Auth is resolved automatically from sf org display.

🔌 REST API Explorer

ASFXT: REST API Explorer — a built-in Salesforce REST client with zero auth setup.

• Request builder: org selector with auto Authorization: Bearer injection; GET/POST/PATCH/PUT/DELETE; relative or full URLs with {version} substitution; headers and JSON body editors; 10 quick templates (List/Describe SObjects, SOQL, CRUD, Composite, Limits, SOSL); request history.
• Response viewer: colour-coded status badge with timing, resolved URL, pretty syntax-highlighted JSON, response headers table, copy-body.

All calls are made server-side (Node https) — no CORS issues.

🩺 Org Health Dashboard

ASFXT: Org Health — a sortable, filterable dashboard of your org's limits (API requests, storage, async Apex, streaming events, and more), each with used/max, remaining, and a colour-coded usage bar so you can spot what's running hot at a glance.

⚙️ System & Setup

• Project Validation: checks for sfdx-project.json; features and views hide outside SFDX projects.
• Output Logging: detailed logs in the ASFX Toolkit output channel (suppressed during deploys, opened on errors).
• Interpreted error panel: any failed CLI or command operation — push, pull, deploy, retrieve, test run, scratch org — opens one panel with the exact Salesforce message, a plain-language cause and fix where it's recognised, a click-through to the offending file, and the original payload on demand. The full payload still goes to the log; the panel never replaces the record.
• Configurable: see Settings.

Keyboard Shortcuts

Settings

All settings live under the adure-sfx-toolkit.* namespace.

Apex & SOQL IntelliSense

Logs, traces, deploy & API

Requirements

• A Salesforce DX project (sfdx-project.json in the workspace).
• The Salesforce CLI (sf) installed and authenticated to your orgs — used for auth and several operations.
• The official Salesforce Apex extension is recommended (ASFX Toolkit's Apex IntelliSense runs alongside it); SOQL features work without it.

Telemetry

The extension collects anonymous usage telemetry to understand how many people use it and which features are valuable, so development can be prioritized. We collect:

• Extension activation and an anonymous, randomly generated install id
• Which commands and panels are used, with execution duration and success/failure
• Coarse error categories (e.g. auth, network, cli) — never raw messages
• Key feature actions: running a SOQL query, sending a REST request, exporting/ importing data, running a migration, executing anonymous Apex
• Deploy / test outcomes as categorical flags and counts

We never collect access tokens, usernames, org ids, record ids, file paths, SOQL/Apex text, query results, or any personal data.

To opt out, set adure-sfx-toolkit.telemetry.enabled to false. Telemetry also honors VS Code's global telemetry.telemetryLevel setting — disabling either turns it off.

💜 Support / Sponsor

Adure SFX Toolkit is free and open source, built and maintained in our spare time. If it saves you time, please consider sponsoring its development. Sponsorships fund ongoing maintenance, new features, and faster bug fixes — and are hugely appreciated. ⭐ Starring the repository and leaving a Marketplace review helps too.

Open Source

Contributions, issues, and feature requests are welcome — see the GitHub repository.

Bundled open-source components are listed in THIRD-PARTY-LICENSES.md.

Feedback

Found a bug or have a suggestion? Please file an issue on the GitHub repository.
