AcuMate Extension Documentation

Description

AcuMate is a Visual Studio Code extension designed specifically for working with the Acumatica ERP platform's Modern UI. This extension streamlines development tasks, providing tools to improve productivity, consistency, and ease of use when working with Acumatica.

Settings

The AcuMate extension provides a range of settings to configure its behavior. Each of these settings can be customized through your VS Code settings.json file.

Parameters

Features

The AcuMate extension for Visual Studio Code offers a range of powerful features for developers working with Acumatica, especially focused on TypeScript and HTML integration. These features enhance productivity, improve code accuracy, and streamline the development process for Acumatica's Modern UI.

TypeScript Features

1. IntelliSense Enhancements

   • Provides IntelliSense for available views within the Acumatica graph, helping users navigate and select relevant views.
   • Filters out service views, such as selector views or those containing #Cache, to ensure only essential views are shown.
   • PXView hover cards surface backend metadata (display name, type, default control) for PXFieldState members as soon as acuMate.useBackend is enabled, keeping data definitions close at hand.

2. Terminal Commands

   • Create Screen: Easily create a new screen by specifying the screen name, graph, primary view, and the number of files to generate.
   • Create Screen Extension: Quickly create an extension for an existing screen by specifying the screen name, extension name, and optionally, a feature switch.
   • Quick Application Build Commands: Simplifies the build process by providing easy-to-use commands, reducing the need to remember multiple commands.

3. Additional IntelliSense Suggestions

   • Create View: Simplifies view creation with options for naming, specifying whether it’s single or a collection, and adding viewInfo, graphConfig, or treeConfig decorators.
   • Create Field: Allows quick creation of fields with options for field settings and relevant decorators.

4. Snippets

   • Event Hook Creation: Quickly add event hooks to TypeScript code with built-in snippets.

5. Graph Metadata Assistance

   • When acuMate.useBackend is enabled, AcuMate queries the connected site for the list of available graphs and surfaces them as completions inside the @graphInfo decorator's graphType value.
   • The same metadata powers TypeScript diagnostics, warning when a graphType string does not match any graph returned by the backend so you can catch typos before running the UI.
   • The @featureInstalled("FeatureName") decorator gains backend-driven IntelliSense as you type the feature name and raises diagnostics when a missing/disabled feature is referenced, helping ensure feature-gated screens follow the site configuration.
   • Validates @linkCommand("ActionName") decorators on PXFieldState members, ensuring the referenced PXAction exists on the backend graph (case-insensitive comparison).
   • While editing a @linkCommand("...") decorator, AcuMate now surfaces completion items sourced from the backend action list so you can insert the exact action name without leaving the editor.
   • Screen extension TypeScript files (under .../extensions/...) automatically reuse the parent screen's @graphInfo metadata so backend validations, completions, and linkCommand checks keep working even when the extension file lacks its own decorator.
   • Hovering PXView field declarations displays the backend field’s display name, raw name, type, and default control. Hovering PXView properties shows cache type/name metadata, and hovering PXActionState members surfaces their backend display names so you can confirm bindings at a glance.
   • Fields whose names contain a double underscore (e.g., __CustomField) are treated as intentionally custom and are skipped by graphInfo diagnostics to avoid noise while prototyping.

HTML Features

1. HTML Validation Against TypeScript + Client Metadata

   • Confirms view.bind and <using view=""> references resolve to real PXView/PXViewCollection properties, including inherited and mixin-provided bindings.
   • Verifies <field name="..."> entries against the PXView resolved from the surrounding markup and ignores deliberate unbound replace-content placeholders.
   • Validates state.bind attributes point to PXAction members, and qp-field control-state.bind values follow the <view>.<field> format with existing fields.
   • Enforces <qp-panel id="..."> bindings by making sure the id maps to an existing PXView, and reuses that view context when checking footer <qp-button state.bind="..."> actions so dialogs only reference actions exposed by their owning view.
   • Requires qp-panel nodes and all qp-* controls to define id attributes (except for qp-field, qp-label, and qp-include) so missing identifiers and misbound panels are caught before packaging.
   • Enforces Acumatica-specific constructs: required qp-include parameters, rejection of undeclared include attributes, and qp-template name checks sourced from ScreenTemplates metadata.
   • Guards <qp-template name="record-*"> usages so record templates only validate when the markup sits inside a <qp-data-feed> container, matching runtime restrictions.
   • Leverages client-controls config schemas to inspect config.bind JSON on qp-* controls, reporting malformed JSON, missing required properties, and unknown keys before runtime.
   • Parses customization attributes such as before, after, append, prepend, move, and ensures their CSS selectors resolve against the base screen HTML so misplaced selectors surface immediately instead of at publish time.
   • Integrates these diagnostics with ESLint + VS Code so warnings surface consistently in editors and CI.

2. Go To Definition inside HTML

   • Navigate directly from view.bind attributes to the corresponding PXView declaration and backing view class.
   • Jump from <field name="..."> elements to the exact field property on the resolved PXView, even when the HTML attribute is still being typed.
   • Follow customization attribute selectors (e.g., before="#toolbar .actions") into the base screen HTML snippet so extension authors can confirm the target fragment without leaving VS Code.

3. Context-Aware HTML Completions

   • Offers IntelliSense suggestions for available view.bind values sourced from the PXScreen metadata.
   • Provides field name suggestions that automatically scope to the closest parent view binding, so only valid fields appear.
   • Attribute parsing tolerates empty values (view.bind="") to keep suggestions responsive while editing.
   • Template name completions automatically filter out record-* entries unless the caret is inside a <qp-data-feed>, keeping suggestions aligned with validation rules.

   Logging & Observability

   • All extension subsystems log to a single AcuMate output channel, making it easy to trace backend requests, caching behavior, and command execution without hunting through multiple panes.
   • Every AcuMate command writes a structured log entry (arguments + timing) so build/validation flows can be audited when integrating with CI or troubleshooting user reports.
   • Backend API calls, cache hits/misses, and configuration reloads emit detailed log lines, giving immediate visibility into why a control lookup or metadata request might have failed.

4. Backend Field Hovers

   • Hovering over <field name="..."> or <qp-field name="..."> immediately shows backend metadata (display name, type, default control type, originating view) sourced from the same data that powers TypeScript hovers.

Suppressing Diagnostics

• Any HTML warning emitted by the validator can be silenced on a per-line basis by inserting <!-- acumate-disable-next-line htmlValidator --> immediately above the element that triggered the message. The directive only applies to the following line, keeping the rest of the document validated as usual.
• To switch off the validator for an entire HTML file, add <!-- acumate-disable-file htmlValidator --> anywhere in the document (commonly at the top). All HTML diagnostics in that file stay muted until the comment is removed.
• GraphInfo warnings inside TypeScript files respect both // acumate-disable-next-line graphInfo and // acumate-disable-file graphInfo, so you can either silence a single property or disable the validator for the entire file.
• HTML and TypeScript diagnostics expose lightbulb quick fixes for both directive forms: Suppress with acumate-disable-next-line inserts the scoped directive above the offending line, while Suppress file with acumate-disable-file drops the file-wide directive at the top of the document automatically.

Scaffolding Workflows

• Create Screen Wizard walks through selecting the screen ID, backend graph, views, primary view, PXActions, view types (entity/grid/tree), and filtered field lists before generating .ts + .html files. Finished screens automatically run Prettier (if enabled) and organize imports.
• Create Screen Extension Wizard validates that the active VS Code editor is inside a screen folder, prompts for the extension name, reuses the parent graph metadata, then repeats the view/action/type/field selection flow to generate extension .ts + .html files beneath extensions/. The same Prettier + organize imports automation applies.

Commands

The AcuMate extension provides several commands to streamline development tasks. Each command is accessible through the command palette in VS Code, categorized under "AcuMate."

Available Commands

Quality & CI

1. Automated Tests
   • Run npm test locally to compile, lint, and execute the VS Code integration suites (metadata, HTML providers, validator, scaffolding, build commands).
   • The GitHub Actions workflow in .github/workflows/ci.yml performs npm ci + npm test for every pull request (regardless of branch) and on pushes to main, using a Node 18.x / 20.x matrix to catch regressions before and after merges.
2. Project Screen Validation
   • Inside VS Code, run AcuMate: Validate Screens (HTML) to queue the validator against all HTML files beneath src/screens (or any folder you input). A cancellable progress notification tracks the run, and results are aggregated in the AcuMate Validation output channel so you can inspect warnings without breaking your workflow.
   • For TypeScript coverage, run AcuMate: Validate Screens (TypeScript) to traverse the same folder structure, execute collectGraphInfoDiagnostics for each screen .ts, and summarize backend metadata mismatches in the output channel (requires acuMate.useBackend = true). This command is also cancellable so you can stop long-running validations instantly.
   • From the CLI, run npm run validate:screens (HTML) or npm run validate:screens:ts (TypeScript) to execute the same scans headlessly via the VS Code test runner. Override the roots with SCREEN_VALIDATION_ROOT or TS_SCREEN_VALIDATION_ROOT environment variables when needed. Both scripts log summaries instead of failing on warnings, ensuring automated runs focus on catching crashes.
