PAMD file support

PAMD file support

Abstergo##

|
1 install
| (0) | Free
Custom editing, compilation, linting, and DOCX export for PyAct .pamd documents.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

📝 PAMD File Support for VS Code

A native Jupyter-like experience for Markdown generation.

Writing .pamd files is great, and writing them in Visual Studio Code should feel purpose-built. This extension provides a dedicated PAMD editor with a controlled cell-based interface and PyAct actions.

✨ Features

  • Custom PAMD Editor: Opens .pamd files in a dedicated editor with exactly one Markdown cell and as many Python code cells as you need, without VS Code's native notebook controls.
  • One-Click Compile: Use the Compile button to instantly compile your document.
  • Instant Live Preview: The moment your document compiles, the extension automatically opens a rich Markdown preview to the side!
  • Export to Word (DOCX): Click the Word icon in the top right of the editor to instantly convert your file into a native Microsoft Word Document.
  • Project Commands: Compile Markdown, force a no-cache build, lint the project, or clear .pamd-cache directly from the editor.
  • Diagnostics: Compilation and lint failures are published in VS Code's Problems panel.
  • Custom Theme: Use PyAct: Configure PAMD Editor Theme to override individual Monaco token colors.
  • Monaco Syntax Highlighting: Python and Markdown cells use the embedded Monaco editor for full language tokenization, including strings, numbers, comments, variables, and keywords.
  • PAMD Markdown Highlighting: Markdown headings, lists, quotes, links, emphasis, inline code, fenced code, HTML comments, and PAMD tags such as <ctx>, <glb>, <tmp>, and <pagebreak/> are highlighted inside the custom editor.
  • Context Completions: Inside <ctx> tags, suggestions are collected from keys returned by context(), including nested paths such as project.author. Suggestions appear automatically while typing; press Ctrl+Space to reopen them manually.
  • Automatic Context Tags: Typing <ctx> inserts </ctx> and places the cursor between the tags, ready for a context key.
  • Stable Editing: Typing does not rebuild the webview, so the active cell keeps focus and the document does not jump to the top.
  • Custom Toolbar: Compile, No Cache, DOCX, Lint, and Clear Cache are available directly inside the PAMD editor.
  • Configurable Python: Select the interpreter through pyact.pythonPath, including a virtual-environment executable.
  • Configurable Output: Set pyact.outputDirectory to write generated files into a project-relative directory.
  • CSS Auto-Discovery: If you have a style.css file next to your .pamd file, the Export to Word tool automatically applies your custom CSS rules to the final DOCX!
  • Streamlined Workflow: We've removed the clutter. No "Select Kernel" prompts, and no accidental cell deletions. Just pure, focused writing.

🚀 Getting Started

  1. Install the PyAct CLI: The extension uses the PyAct engine under the hood. Make sure you have it installed on your system:
    pip install pyact-cli

  2. Install this Extension: Search for "PAMD" in the VS Code marketplace and install it.
  3. Open a .pamd file: It will automatically open in the custom PAMD editor.
  4. Use Compile: Watch your Python code generate a stunning Markdown document instantly.

⚙️ Settings

{
  "pyact.pythonPath": "python",
  "pyact.autoPreview": true,
  "pyact.outputDirectory": "",
  "pyact.showToolbar": true,
  "pyact.editorTheme": {}
}

The extension invokes python -m pyact.cli without a shell, so paths and arguments containing spaces are handled safely.

Syntax highlighting is provided by the Monaco editor bundled with the extension, so it works without a network connection. The editor uses the active VS Code theme family and keeps each cell independently resizable.

Use PyAct: Configure PAMD Editor Theme to open the setting. Add token names to pyact.editorTheme; configured values override the built-in palette and apply to open PAMD editors.

All configurable tokens are:

Python / shared token Markdown token PAMD token
keyword markdown-heading pamd-tag
constant markdown-quote pamd-tag-content
variable markdown-list pamd-control
variable.language markdown-code-fence
function markdown-code
class-name markdown-bold
annotation markdown-italic
namespace markdown-link
import-name markdown-entity
number
string
string.escape
operator
delimiter
comment

Example:

"pyact.editorTheme": {
  "keyword": "#C586C0",
  "constant": "#569CD6",
  "variable": "#9CDCFE",
  "variable.language": "#569CD6",
  "function": "#DCDCAA",
  "class-name": "#4EC9B0",
  "annotation": "#DCDCAA",
  "namespace": "#4EC9B0",
  "import-name": "#9CDCFE",
  "number": "#B5CEA8",
  "string": "#CE9178",
  "string.escape": "#D7BA7D",
  "operator": "#D4D4D4",
  "delimiter": "#D4D4D4",
  "comment": "#6A9955",
  "markdown-heading": "#569CD6",
  "markdown-quote": "#6A9955",
  "markdown-list": "#C586C0",
  "markdown-code-fence": "#DCDCAA",
  "markdown-code": "#CE9178",
  "markdown-bold": "#DCDCAA",
  "markdown-italic": "#DCDCAA",
  "markdown-link": "#4FC1FF",
  "markdown-entity": "#B5CEA8",
  "pamd-tag": "#4FC1FF",
  "pamd-tag-content": "#DCDCAA",
  "pamd-control": "#C586C0"
}

Each value can also be an object with foreground and fontStyle, for example { "foreground": "#4EC9B0", "fontStyle": "bold" }.

For development-time theme remapping, edit THEME_TOKEN_MAP in src/pamdEditorHtml.ts. For example, 'markdown-heading': 'keyword' makes Markdown headings use the theme's keyword color, while 'pamd-tag': 'namespace' makes PAMD tags use the namespace color. The left side is a Monaco token and the right side is the logical VS Code theme token whose resolved color should be reused.

After changing the extension source, run npm run compile, reload the VS Code window, and reopen the .pamd file.

Happy writing!
