TreeCraft – Project Structure Visualizer

Generate beautiful, readable visual representations of your project's folder structure directly inside VS Code. TreeCraft traverses your workspace, respects .gitignore, and outputs a tree view with intuitive file/folder icons. You can view the tree in a new editor tab or export it to a folder-tree.txt file at the workspace root.

Features

• Text View generation: Render the project tree in a new untitled document.
• Export to file: Save the generated tree to folder-tree.txt at your workspace root.
• Emoji icons: 📁 for folders and 📄 for files for quick scanning.
• Respects ignores: Skips common directories and patterns (e.g., .git, node_modules, .vscode, .DS_Store, and patterns fr˙om your .gitignore).

Requirements

• VS Code: ^1.74.0
• Node.js: 16.x (matches the dev dependency types)

Installation

From source (recommended for now)

1. Clone this repository.
2. Install dependencies:

   npm install


3. Build the extension (optional; VS Code can compile on debug):

   npm run compile


4. Press F5 in VS Code to launch an Extension Development Host with TreeCraft loaded.

From a VSIX (optional)

• If you have a packaged .vsix, open the Extensions view → ⋯ menu → Install from VSIX... and select the file.

Usage

You can run TreeCraft from the Command Palette or the Explorer context menu.

• Command Palette: Cmd+Shift+P → search for:

  • TreeCraft: Generate Tree (Text View) (folderTreeGenerator.generateTree)
  • TreeCraft: Generate Tree File (folderTreeGenerator.generateTreeToFile)

• Explorer context menu: Right‑click in the Explorer and choose:

  • TreeCraft: Generate Tree (Text View)
  • TreeCraft: Generate Tree File

Example output

Text View and exported file produce the same formatted tree. Example:

└── 📁 my-project
    ├── 📁 src
    │   ├── 📄 index.ts
    │   └── 📄 utils.ts
    ├── 📁 test
    │   └── 📄 app.test.ts
    ├── 📄 package.json
    └── 📄 tsconfig.json

The exported file will be created at your workspace root as folder-tree.txt, and VS Code will open it automatically after generation.

Troubleshooting

• If you see “No workspace folder open”, open a folder or workspace first.
• Very large folders may take longer to render; TreeCraft limits traversal depth by default to keep it snappy.

Commands reference

• folderTreeGenerator.generateTree – TreeCraft: Generate Tree (Text View)
• folderTreeGenerator.generateTreeToFile – TreeCraft: Generate Tree File
• folderTreeGenerator.test – TreeCraft: Test Extension

Made with ❤️ by Abdullah Mia.
