SystemVerilog for Visual Studio Code
SystemVerilog / Verilog support for VS Code, ported from the Sublime Text
SystemVerilog plugin. Supports .v,
.vh, .sv and .svh files.
Quick start
- Install the extension and open a workspace containing HDL files.
- Open the Command Palette and type
Verilog to see the commands.
- For large projects, configure
systemverilog.fileLists and
systemverilog.includeDirs.
- Use Verilog: Configure Settings for a validated settings UI.
Features
- Syntax: Verilog/SystemVerilog TextMate grammar, brackets, comments and folding.
- Navigation: show type (
F10), declaration (Shift+F12) and driver
(Ctrl+F12); the driver jump follows wrapper levels that only pass a signal
along, descends to the module that drives an output, and from an input port walks
up to the parent binding (listing up to maxSignalUsers instantiations); module
hierarchy; find instances; jump to the instantiating module; show module instances
and outline entries. Ctrl+Click on an instance port name (.clk (sig))
jumps to the driver for an output or to the modules using an input, equivalent
to the hover links.
- Hover: links to module, interface, class and member definitions; port
direction with driver and signal-user links (an input links to the modules that
actually use the signal, skipping the levels that only forward it); a Go to
port declaration link jumps to where the port is declared in the module
definition; configurable direction colors. Hovering a numeric literal
(
8'd123, 'h7B, 123) shows the same value as Dec/Hex/Bin/Oct Verilog
literals with one-click copy per form and a Copy all link; signed
literals show the negative decimal, and reals, time literals and x/z values
are left alone. Off by default; enable systemverilog.numberFormatHover.
- Instance port direction badges: when enabled, a small
in/out/inout/ref
label is shown before each .port ( name in module instantiations, colored by
portDirectionColors. Toggle with systemverilog.portDirectionDecoration.
- Completion: adaptive
always / always_ff / always_comb snippets; dot and
:: completion; missing-port completion inside module/interface instantiations
(type . in the port list to list ports not yet bound); enum/vector case
completion; system tasks, directives, UVM functions and keyword snippets.
Declarations visible in the current scope also complete -- module, interface and
class members (properties, methods), module and interface ports and instance
names, module, interface and package parameters, signals and variables, typedefs,
enum members, function and task names, function-local variables (including
out-of-body task Class::method() locals), and members of packages pulled in
with import pkg::*; identifiers appearing anywhere in the current file are also
offered as fallback completions. These symbol rows are ranked above the snippets,
and no declarations are offered inside comments or string literals.
- Editing: alignment, reindent, module instantiation with parameter prompts
and auto-connect,
.* expansion, FSM template generation, block move/select.
- Linting: find unused and undeclared signals.
- Filelist generation: Verilog: Generate Filelist scans the folder that
contains the current file (recursively), writes
filelist.f with every
Verilog/SystemVerilog file as <prefix>/<relative/path> where <prefix> is
the path header you type in the prompt, and opens the result.
- Indexing: background workspace index, refreshed on file changes; filelists
and include directories keep large projects fast.
Commands
Most commands are in the Command Palette under Verilog. Common navigation and
editing commands are also in the editor context menu. Block boundary commands are
keybinding-only.
| Command |
Default key |
| Verilog: Show Signal/Variable Type |
F10 |
| Verilog: GoTo Declaration |
Shift+F12 |
| Verilog: GoTo Driver |
Ctrl+F12 |
| Verilog: Show Module Hierarchy |
|
| Verilog: Find Instance |
|
| Verilog: Go to Instantiating Module |
|
| Verilog: Show Module Instances |
|
| Move to Block Boundary |
Ctrl+M |
| Select Block Boundary |
Ctrl+Shift+M |
| Verilog: Instantiate Module |
Ctrl+F10 |
| Verilog: Toggle .* |
Ctrl+Shift+F10 |
| Verilog: Alignment |
Ctrl+Shift+A |
| Verilog: Reindent |
Alt+Shift+A |
| Verilog: Insert FSM template |
|
| Verilog: Find Unused Signals |
|
| Verilog: Linting |
|
| Verilog: Configure Settings |
|
| Verilog: Generate Filelist |
|
Configuration
All settings are under systemverilog.*. Verilog: Configure Settings provides
the full UI and can validate filelists, include directories and indexed files.
fileLists and includeDirs describe one project's compile command, so the panel
saves them to the workspace (.vscode/settings.json) and other projects keep their
own lists. Port hover colors are a display preference and stay in user settings.
| Setting |
Purpose |
fileLists |
Restrict indexing to files referenced by one or more filelists. Supports -f/-F, -incfile, +incdir+, -I, comments, quoted paths and environment variables. |
includeDirs |
Extra directories searched for `include directives. Supports *, ? and ** wildcards such as rtl/*/include. |
vExt / svExt / vhExt / svhExt |
File extensions indexed for each language/header type. |
hoverMaxSize / portDirectionColors |
Limit automatic hover by file size; set port direction colors. |
numberFormatHover |
Hover a numeric literal to see Dec/Hex/Bin/Oct conversions with copy links (default false). |
portDirectionDecoration |
Show in/out/inout/ref badges before instance port names (default true). |
maxSignalUsers |
How many modules the Go to modules using ... hover link lists (default 5, max 20). |
autoconnect / fillparam / paramOneline / instOneline |
Module instantiation and parameter behavior. |
instancePrefix / instanceSuffix / declStart / declEnd |
Generated instance names and auto-declaration location. |
clkName / rstName / rstNName / disableAutocomplete |
Snippet clock/reset names and smart completion toggle. |
maxLineLength / paramPortAlignment / alignCommaSemicolon / alignmentIgnoreTick |
Alignment behavior. |
debug |
Log index and command details to the SystemVerilog output channel. |
Leave fileLists empty to index the whole workspace. Includes are resolved from
the including file's directory first, then from the configured include directories.
A file whose entire content is the path of another file (a checked-in link to a
generated source) is followed transparently when it is reached through a filelist
or an `include, so navigation and hover land in the real file.
Building
npm install
npm run compile
npm test
npm test covers the parser, beautifier, filelists, directory globbing, instance
lookup, port completion, scope symbols, the completion provider and activation.
Compile before testing. The activation test simulates the published environment,
where node_modules is not shipped.
License and attribution
Derived from the Sublime Text SystemVerilog plugin by TheClams, licensed under the
Apache License 2.0. See NOTICE and LICENSE.
| |
