Engram Nexus: SOMA

A VS Code extension that visualizes your Engram memory as an interactive, force-directed knowledge graph.

Engram Nexus connects directly to your local ~/.engram/engram.db and renders your technical decisions, patterns, bug fixes, features, and architectural choices as a living, explorable graph — your developer brain, made visible.

Features

Interactive Knowledge Graph

Observations appear as color-coded nodes connected by semantic and temporal links. Projects cluster into collapsible super-nodes to prevent cognitive overload on large databases. The physics engine organizes your memories into a dense, organic sphere.

Semantic Coloring by Type

Each observation type has a distinct color, fully customizable from VS Code Settings:

Advanced Filtering

Stack multiple filters simultaneously — all filtering happens in SQL/backend, never in the frontend:

• Full-Text Search — Powered by SQLite FTS5 for instant search across all memory content, with LIKE fallback.
• Observation Type Filter — Isolate Decisions, Architecture, Bugfixes, Patterns, Learnings, or Sessions with one click. Color-coded buttons on any side of the panel (or hidden via settings).
• Date Range (Calendar) — Filter observations by a start/end date range. The calendar adapts to panel width: inline on narrow panels, floating overlay on wider ones.
• Focus Mode — Isolate a single project in the graph via the crosshair dropdown, hiding all other projects. Resetting focus restores the full view.
• Collapse/Expand — Double-click a project node (or use the global toggle button) to collapse or expand entire projects at once.

Knowledge Trail (Time Machine)

Select any node and click Show Trail to transform the graph into a top-down chronological tree. Trails group related observations by topic_key (same theme across sessions) or session_id (same work session). Use Copy Entire Trail to generate a markdown-formatted report of the entire decision thread.

Deep VS Code Integration

• Node Details Panel — Click any node to see full metadata: title, type, project, author origin, creation date, and full content.
• Inject Context — One click copies the full observation content to clipboard in a format ready to paste into an AI agent or chat.
• Read-Only — The extension never writes to your database. Zero risk of data corruption.

Adaptive Floating Calendar

The calendar dynamically switches between inline and floating overlay mode based on panel width (configurable threshold, default 380 px). You can move the overlay corner (left/right) with a single button click without touching settings.

Light & Dark Theme Support

Follows VS Code's active theme automatically, with a manual override toggle button in the toolbar. Styled with custom CSS variables (--nexus-bg, --nexus-text, --nexus-accent, --nexus-border) for smooth integration with VS Code's color palette.

Configuration

Open VS Code Settings (Cmd+, → Extensions → Engram Nexus) to customize the extension:

Layout & Behavior

Node Colors

Customize the color of each observation type using hex color values:

nexus.colors.decision         #f59e0b
nexus.colors.architecture     #3b82f6
nexus.colors.bugfix           #ef4444
nexus.colors.pattern          #a855f7
nexus.colors.learning         #22c55e
nexus.colors.feature          #06b6d4
nexus.colors.config           #f97316
nexus.colors.discovery        #10b981
nexus.colors.session_summary  #94a3b8
nexus.colors.manual           #64748b

Color changes apply live without reloading the extension.

Requirements

• VS Code ^1.80.0
• Engram — This extension reads the SQLite database created by the Engram memory system at ~/.engram/engram.db. Engram must be installed and have at least one saved observation for the graph to render.

Architecture

The extension follows a strict separation of concerns:

src/
  backend/
    ipc/messageHandler.ts     — Central IPC router (FETCH_DATA, SEARCH, GET_TRAIL, INJECT_CONTEXT)
    repository/
      engramRepository.ts     — Data access layer (read-only SQLite queries, graph mapping)
      queries.ts              — SQL query builder (Query Object pattern, no inline SQL elsewhere)

webview-ui/src/
  components/
    Graph/NetworkGraph.tsx    — Force-directed graph (react-force-graph-2d)
    Sidebar/NodeDetails.tsx   — Node metadata + Inject Context + Show Trail
    Sidebar/FilterPanel.tsx   — Observation type filter buttons
    Timeline/TimelineView.tsx — Chronological trail view + Copy Entire Trail
    Calendar.tsx              — Date range picker
    SearchBar.tsx             — FTS5 search input
    ui/                       — Reusable primitives (IconButton, CTAButton, MetadataRow, ...)
  hooks/
    useGraphData.ts           — IPC data flow, search/trail triggers
    useGraphSettings.ts       — Settings, theme, layout state
    useSmartCamera.ts         — Force graph camera control (auto-zoom, physics tuning)
    useClickTracker.ts        — Single vs double-click disambiguation (250 ms debounce)

Key design principles:

• Zero Frontend Data Filtering — React renders only. All filters, search, date ranges, and project focus are resolved in SQL.
• O(N) graph links — Anti-hairball: nodes sharing a session or topic are connected as a chain, not a clique, preventing exponential edge growth.
• Read-only database access — No writes, no transactions, no risk.

Release Notes

1.2.0

• Focus Mode — Isolate a single project in the graph via a custom dropdown.
• Global Collapse/Expand — Single button to collapse or expand all projects simultaneously.
• Customizable Node Colors — 10 new nexus.colors.* settings for full color control per observation type.
• Anti-hairball graph topology — Replaced O(N²) clique linking with O(N) chain links, eliminating visual hairballs on large databases.
• UI Component Library — Extracted reusable primitives (IconButton, CTAButton, MetadataRow, PanelHeader, FloatingLabelBox, TimelineItem) to unify interaction patterns across the app.
• Filter Panel positioning — nexus.filterPanelSide now supports top, bottom, left, right, and none.
• Query Object pattern — All SQL extracted from the repository into a dedicated queries.ts module.
• Adaptive tooltip system — All icon buttons have 8-position tooltips that never get clipped by panel edges.
• Light theme support — Calendar and filter bar adapt correctly to VS Code's light theme.

1.1.0

• Knowledge Trail (Time Machine): chronological tree view of related observations.
• Adaptive Floating Calendar with configurable threshold and corner toggle.
• Multiplayer Awareness: visual distinction between local and imported (git-synced) observations.
• "Inject Context" button for instant AI agent integration.

1.0.0

• Interactive force-directed knowledge graph.
• Full-text search via SQLite FTS5.
• Semantic type filters.
• Node details panel.
• Light/dark theme toggle.

0.0.1

• Initial release.
