DevOps for Snowflake CLI

Note: The Snowflake CLI Azure DevOps extension is in Public Preview.

Usage

This extension streamlines installing and using Snowflake CLI in your Azure Pipelines. The CLI is installed in an isolated way, ensuring it won't conflict with your project dependencies. It automatically sets up the input config file within the ~/.snowflake/ directory.

The extension contributes a single build task, ConfigureSnowflakeCLI@0, that enables automation of your Snowflake CLI workflows, such as deploying Native Apps or running Snowpark scripts within your Snowflake environment.

Inputs

`cliVersion`

The Snowflake CLI version to install. For example, 3.11.0. If not specified, the latest released version is used.

`configFilePath`

Path to the configuration file (config.toml) in your repository. The path must be relative to the root of your repository.

`useWorkloadIdentity`

Boolean flag to enable workload identity federation authentication. When set to true, the task will request an OIDC token from Azure DevOps using the specified service connection and configure the Snowflake driver to authenticate with the obtained token, eliminating the need for storing credentials as secrets. Requires connectedServiceName and Snowflake CLI 3.11.0 or later. Default is false.

`connectedServiceName`

The name of an Azure Resource Manager service connection configured with workload identity federation. Required when useWorkloadIdentity is true. The task uses this service connection to request an OIDC token from Azure DevOps.

How to Safely Configure the Pipeline

Use workload identity authentication (OIDC)

Workload identity federation provides a secure way to authenticate with Snowflake from Azure DevOps pipelines without storing credentials as secrets. The task requests an OIDC token from Azure DevOps via the service connection and passes it to the Snowflake driver.

To set up workload identity authentication, follow these steps:

Create an Azure App Registration with a federated credential:

Create an App Registration in Microsoft Entra ID and add a federated credential for your ADO service connection. See the Azure documentation for details.
Create an Azure DevOps service connection:

In your ADO project, create an Azure Resource Manager service connection using Workload Identity Federation. Note the service connection name for the pipeline configuration.
Configure Snowflake:

Create a service user with OIDC workload identity. The claim values for Azure DevOps OIDC tokens follow predictable patterns:
- Issuer (iss): https://vstoken.dev.azure.com/<Azure-AD-Tenant-ID>
- Subject (sub): sc://<ADO-Org-Name>/<ADO-Project-Name>/<Service-Connection-Name>
- Audience (aud): api://AzureADTokenExchange
Use these values to create (or alter) the Snowflake user:
```
CREATE USER <username>
  WORKLOAD_IDENTITY = (
    TYPE = OIDC
    ISSUER = 'https://vstoken.dev.azure.com/<Azure-AD-Tenant-ID>'
    SUBJECT = 'sc://<ADO-Org-Name>/<ADO-Project-Name>/<Service-Connection-Name>'
    OIDC_AUDIENCE_LIST = ('api://AzureADTokenExchange')
  )
  TYPE = SERVICE
  DEFAULT_ROLE = PUBLIC;
```
For more details, see the Snowflake documentation.
Troubleshooting: If authentication fails due to a claim mismatch, you can inspect the actual token claims by adding a debug step to your pipeline:
```
- bash: |
    echo "$SNOWFLAKE_TOKEN" | cut -d. -f2 | tr '_-' '/+' | base64 -d 2>/dev/null | python3 -m json.tool
  displayName: 'Debug: inspect OIDC token claims'
```

Configure the pipeline:

Add a config.toml to your repository (no credentials needed):

[connections.default]
account = "<your_account>"
warehouse = "COMPUTE_WH"
role = "PUBLIC"

Then configure your pipeline YAML:

trigger:
- main

pool:
  vmImage: ubuntu-latest

steps:
- task: ConfigureSnowflakeCLI@0
  inputs:
    configFilePath: './config.toml'
    cliVersion: 'latest'
    useWorkloadIdentity: true
    connectedServiceName: '<your-service-connection-name>'
  displayName: Configure Snowflake CLI with Workload Identity

- script: |
    snow --version
    snow connection test

Alternative authentication methods

The following methods can be used as alternatives to workload identity authentication:

Key-Pair Authentication

To set up Snowflake credentials for a specific connection, follow these steps:

Add config.toml to Your Repository:

Create a config.toml file at the root of your repository with an empty connection configuration. For example:
```
[connections]
[connections.myconnection]
user = ""
database = ""
```
This file serves as a template and should not include any sensitive credentials.
Generate a Private Key:

Generate a key pair for your Snowflake account following this user guide.
Store Credentials in Azure DevOps Pipeline Secrets:

Store each credential (e.g., account, private key, passphrase) in Azure DevOps Pipeline Secrets. Refer to the Azure DevOps documentation for detailed instructions on how to create and manage secrets.
Configure the Snowflake CLI Task:

Add the configFilePath input to the Snowflake CLI task in your pipeline YAML file. This specifies the path to your config.toml file. For example:
```
- task: ConfigureSnowflakeCLI@0
  inputs:
    cliVersion: 'latest'
    configFilePath: 'config.toml'
```
Define the Commands to Execute

Specify the Snowflake CLI commands you want to run. Below is an example that checks the installed version of the CLI and tests the connection:
```
- script: |
    snow --version
    snow connection test
  env:
   ...
```

Map Secrets to Environment Variables in your script:

Use environment variables to map each secret. For example:

env:
  SNOWFLAKE_CONNECTIONS_MYCONNECTION_AUTHENTICATOR: 'SNOWFLAKE_JWT'
  SNOWFLAKE_CONNECTIONS_MYCONNECTION_PRIVATE_KEY_RAW: $(SNOWFLAKE_PRIVATE_KEY_RAW)
  SNOWFLAKE_CONNECTIONS_MYCONNECTION_ACCOUNT: $(SNOWFLAKE_ACCOUNT)

[Optional] Set Up a Passphrase if Private Key is Encrypted:

Add an additional environment variable named PRIVATE_KEY_PASSPHRASE and set it to the private key passphrase. This passphrase will be used by Snowflake to decrypt the private key.
```
  env:
    PRIVATE_KEY_PASSPHRASE: $(PASSPHRASE)  # Passphrase is only necessary if private key is encrypted.
```

[Extra] Using Password Instead of Private Key:

Unset the environment variable SNOWFLAKE_CONNECTIONS_MYCONNECTION_AUTHENTICATOR and then add a new variable with the password as follows:

env:
  SNOWFLAKE_CONNECTIONS_MYCONNECTION_USER: $(SNOWFLAKE_USER)
  SNOWFLAKE_CONNECTIONS_MYCONNECTION_ACCOUNT: $(SNOWFLAKE_ACCOUNT)
  SNOWFLAKE_CONNECTIONS_MYCONNECTION_PASSWORD: $(SNOWFLAKE_PASSWORD)

[Extra] Define config.toml Within the YAML File:

You can create the config.toml file directly within your YAML pipeline using a shell command. Here’s how to do it:

- script: |
    cat <<EOF > config.toml
    default_connection_name = "myconnection"

    [connections]
    [connections.myconnection]
    user = ""
    EOF
  displayName: 'Create Sample File with Multiple Lines'

For more information on setting Snowflake credentials using environment variables, refer to the Snowflake CLI documentation.

Full Example Usage

Configuration File

default_connection_name = "myconnection"

[connections]
[connections.myconnection]
user = ""

YAML Pipeline

trigger:
- main

pool:
  vmImage: ubuntu-latest

steps:
- task: ConfigureSnowflakeCLI@0
  inputs:
    configFilePath: './config.toml'
    cliVersion: 'latest'
  displayName: SnowflakeCliTest

- script: |
    snow --version
    snow connection test
  env:
    SNOWFLAKE_CONNECTIONS_MYCONNECTION_AUTHENTICATOR: 'SNOWFLAKE_JWT'
    SNOWFLAKE_CONNECTIONS_MYCONNECTION_USER: $(SNOWFLAKE_USER)
    SNOWFLAKE_CONNECTIONS_MYCONNECTION_ACCOUNT: $(SNOWFLAKE_ACCOUNT)
    SNOWFLAKE_CONNECTIONS_MYCONNECTION_PRIVATE_KEY_RAW: $(SNOWFLAKE_PRIVATE_KEY_RAW)
    PRIVATE_KEY_PASSPHRASE: $(PASSPHRASE)  # Passphrase is only necessary if private key is encrypted.
