Introduction

Use this extension to send email from your pipeline without a SMTP server. It uses the Microsoft Graph API to send email.

Requirements

To use the extension you need an active business Office 365 license that includes the use of Exchange Online, and Exchange online must be configured.

Create Azure Enterprise Application

Create the App and get the Client ID

• Go to portal.azure.com and login with an administrative account
• Go to Microsoft Entra ID -> App Registrations -> All Applications
• Click on + New Registration
• Name: e.g. AzureDevOpsGraphEmail
• Supported account types: Accounts in this organizational directory only
• Redirect URI: Web
• Click Register and note the Application (Client) ID. This is the Client ID

Get the Client Secret

• Click Certificates & Secrets -> Client Secrets -> New client secret
• Description: e.g. AzureDevOpsGraphEmail
• Expires: Set this to what you prefer, a year is usually sufficient.
• Click Add
• Note the secret value. This is the Client Secret

Assign Permissions to the App

• Go to API Permissions
• Add a Permission -> Microsoft Graph
• Application Permissions
• Mail.Send (Send mail as any user) -> Add Permissions
• Click Grant admin consent for 'Organization'

Get the Tenant Domain

• Now go to Microsoft Entra ID -> Custom domain names
• Check the domain which is primary. This is the Tenant Domain

From email

The email address you're sending from must exist, and it can be a shared mailbox. Emails that are sent are added to the Sent Items folder from the configured mailbox.

Yaml examples

This is an example with a multiline email:

- task: GetShifting.GraphEmail.graph-email-build-task.GraphEmail@0
  displayName: "Send an email with subject Test mail from $(BUILD.DEFINITIONNAME)"
  inputs:
    To: "sjoerd@getshifting.com"
    BCC: "$(BUILD.REQUESTEDFOREMAIL)"
    From: "sjoerd@getshifting.com"
    Subject: "Test mail from $(BUILD.DEFINITIONNAME)"
    Body: |
      <h1>This is a testmail</h1>
      <p>You can use various variables within the body of the email, for example:</p>

      <ul>
      <li> Build ID: $(build.buildid) </li>
      <li> Build Directory: $(agent.builddirectory) </li>
      <li> Build Queued By: $(BUILD.QUEUEDBY) </li>
      <li> Agent Name: $(AGENT.NAME) </li>
      <li> Job Name: $(SYSTEM.JOBDISPLAYNAME) </li>
      <li> Task Name: $(SYSTEM.TASKDISPLAYNAME) </li>
      <li> Build Requested for: $(BUILD.REQUESTEDFOR) </li>
      <li> Commit Message: $(BUILD.SOURCEVERSIONMESSAGE) </li>
      </ul>

      Kind regards, <br>
      $(BUILD.REQUESTEDFOR)
    ClientID: "e5e6ce84-d241-4faf-97e0-d71a171f1adf"
    ClientSecret: "$(ClientSecret)"
    ShowClientSecret: false
    TenantDomain: getshifting.com

This is an example with a single line email:

- task: GetShifting.GraphEmail.graph-email-build-task.GraphEmail@0
  displayName: "Send graph email with subject Testmail from $(BUILD.DEFINITIONNAME)"
  inputs:
    To: "sjoerd@getshifting.com"
    From: "sjoerd@getshifting.com"
    Subject: "Testmail from $(BUILD.DEFINITIONNAME)"
    Body: This is a short testmail
    ClientID: "$(ClientID)"
    ClientSecret: "$(ClientSecret)"
    TenantDomain: getshifting.com

Release Notes

20251124.x.x

• Added yaml examples
• Updated documentation with new links and naming

20220731.x.x

• Added release notes

20220728.x.x

• Added TLS 1.2 support

20191211.x.x

• Initial release

More Resources

• MS Graph - Register App
