dotConnect Universal

Universal .NET Connector for Major Databases with ORM Support

dotConnect Universal offers universal access to data of different databases for the Microsoft .NET Framework. It supports most of major database servers, including Microsoft SQL Server, Microsoft Access, Oracle, DB2, MySQL, PostgreSQL, SQLite, InterBase, and Firebird. Other servers can be accessed through their ADO.NET, OLE DB and ODBC providers.

dotConnect Universal is based on ADO.NET technology and can be used in the same way as the SQL Server .NET Data Provider. The main feature of dotConnect Universal is an access to multiple database servers at the same code. With dotConnect Universal it is possible to avoid writing conditional code for different providers or using ADO.NET interfaces directly. dotConnect Universal implements full support of design-time development and integration with IDE, which allows to reduce development time greatly.

dotConnect Universal doesn't implement database specific access layer for all databases, it uses native ADO.NET providers and depends on their functionality. The Professional Edition of dotConnect Universal includes bundled data providers for Oracle, MySQL and PostgreSQL (see diagram below). For all other servers you need a native data provider.

dotConnect Universal provides functionality for connecting to a database, executing commands, and retrieving results. These results can be processed directly or placed in an ADO.NET DataSet for further processing in disconnected state. While in the DataSet, data can be exposed to the user, combined with other data from multiple sources, or passed remotely between tiers. Any processing performed on the data in the DataSet can then be reconciled with the database.

The following diagram illustrates dotConnect Universal architecture. The green area represents some of dotConnect Universal components. The lime area unites bundled providers in the Professional Edition. The rest of the diagram objects represent data access elements inside and outside of the .NET Framework.

Supported providers

Provider	Description
dotConnect for Oracle	dotConnect for Oracle provides direct access to Oracle database server with or without the Oracle Call Interface (OCI). The data provider supports Oracle Client software version 8.0 and later.
dotConnect for MySQL	dotConnect for MySQL is a data provider for direct access to MySQL database server for the Microsoft .NET Framework. The data provider can access MySQL server either using native MySQL network protocol directly or through MySQL client library.
dotConnect for PostgreSQL	dotConnect for PostgreSQL is a data provider for direct access to PostgreSQL database for the Microsoft .NET Framework. The data provider uses native message-based protocol for communication with PostgreSQL database server.
dotConnect for SQLite	dotConnect for SQLite is a data provider for direct access to SQLite database for the Microsoft .NET Framework.
.NET Framework Data Provider for SQL Server	The .NET Framework Data Provider for SQL Server uses its own protocol to communicate with SQL Server. It is lightweight and performs well because it is optimized to access a SQL Server directly without adding an OLE DB or Open Database Connectivity(ODBC) layer.
.NET Framework Data Provider for OLE DB	The .NET Framework Data Provider for OLE DB uses native OLE DB through COM interop to enable data access.
.NET Framework Data Provider for ODBC	The .NET Framework Data Provider for ODBC uses native ODBC Driver Manager through COM interop to enable data access.
.NET Framework Data Provider for Oracle	The .NET Framework Data Provider for Oracle enables data access to Oracle data sources through Oracle client connectivity software. The data provider supports Oracle client software version 8.1.7 and later.
Microsoft Access Provider	The provider for MS Access enables data access to Microsoft Access data sources through OLE DB. Recommended for single-tier applications using Microsoft Access databases.
Oracle Data Provider for .NET	The Oracle Data Provider for .NET enables data access to Oracle data sources through Oracle client connectivity software. The data provider supports Oracle client software version 9.2 and later.
IBM DB2.NET Data Provider	The DB2 .NET Data Provider allows your .NET applications to access Version 8 DB2 Universal Database on Windows, UNIX, and Linux-based computers, and Version 6 and Version 7 of DB2 Universal Database for OS/390 and z/OS via DB2 Connect.
Firebird ADO.NET Provider	The .NET Data Provider for Firebird 1.x, 2.0, and InterBase 7.5 databases. Available for .NET Framework 2.0 only.

Compatibility

The following table show which version of this package to use with which version of frameworks.

Frameworks	Version support
.NET	8, 7, 6, 5
.NET Core	3, 2, 1
.NET Framework	4.8, 4.7, 4.6, 4.5

More information here

License

See pricing options for ordering.

Trial Limitations

The dotConnect Universal Evaluation License lets you try dotConnect Universal Trial Edition for a period of 30 days. You may not use applications developed using Trial versions of the Software for any commercial purposes.
